PROJECT : PROJ. NO.: CLIENT: UNIT :
DATE : BY : REV : DOC NO.:
02-Jan-03 S. Rahimi A
Salt Balance (Two Stage Desalter)
Salinity Calculation Chloride Conc. In feed Chloride in washing water Mixing Efficiency Outlet Oil Salt Content Minimum Desalter Feed water Feed Salinity Washing Water Salinity Feed Salinity Washing Water Salinity
mg/lit mg/lit % PTB % mg/lit mg/lit lb/BBL lb/BBL
136170 244 100 18 4 224393 402 78.49 0.14
Oil Flow Rate Water Percent Total water Flow Rate Mixed Water Flow Rate Salt Content Salt Content Salt Content
BOPD Vol% BWPD BWPD lb/day lb/BBL PTB
1 FEED Stream 218336 2 4456 4456 349751 78.49 1601 89 1601.89
Calculation Summary Oil Flow Rate Fresh Water Consumption 1st stage Internal Recirculation 2nd stage Internal Recirculation Package Recirculation Package Reject Reject salt Concentration
m3/hr m3/hr m3/hr m3/hr m3/hr m3/hr mg/lit
1446.5 4.9 23.4 51.5 4.9 33.0 198941
Salt Balance Calculation Parameter
www.chemwork.org
Unit
2 Stream to Stage 1 218336 4.00 8733 8733 607756 69.59 2783 58 2783.58
8 Reject Stage 1 218336 3.90 8515 8515 592547 69.59 2713 92 2713.92
10 1st stage Int. Recirc. 218336 1.62 3538 3538 246180 69.59 1127 53 1127.53
12 Package Reject 218336 2.28 4977 4977 346367 69.59 1586 39 1586.39 0.00
3 Out of Stage 1 218336 0.1 219 219 15209 69.59 69 66 69.66
7 Fresh Water 218336 0.34 740 740 104 0.14 0 48 0.48
4 Stream to Stage 2 218336 4.00 8733 8733 139550 15.98 639 15 639.15
6 Reject Stage 2 218336 3.90 8515 8515 136058 15.98 623 16 623.16
9 11 2nd stage Recycle to Int. Recirc. 1st stage 218336 218336 3.56 0.34 7775 740 7775 740 124237 11825 15.98 15.98 569 02 569.02 54 16 54.16 0.00
5 Out of Stage 2 218336 0.1 219 219 3492 15.98 15 99 15.99
