Industrial Training Tnb Distribution 9TH March 2015 – 31 may 2015 MOHAMAD SYAFIQ BIN ABDULLAH EE089872 MAY 2015
CONTENT
Self introduction
Industrial training objectives
Company profile
Training activity
SELF INTRODUCTION
Name : Mohamad Syafiq Bin Abdullah
Date of birth : 17 November 1993
ID number : EE089872
Age : 21
Hometown : Kepala Batas, Pulau Pinang
Institution : Universiti Tenaga Nasional (UNITEN)
Course : Bachelor of Electrical and Electronics Engineering (Hons.)
INDUSTRIAL TRAINING OBJECTIVE
To provide the students to the world of work so that they can relate theoretical knowledge with application in industry
To build and increase creative and positive thinking when overcoming engineering problems.
To improve my soft skills such as communication, management and team-work.
Enhancing the potential of the student to with the situation that they encounter.
Company profile The TNB a public listed company with responsibilities: • To generate, transmit, distribute and sell energy to customer throughout Peninsular Malaysia. • To plan, install, operate and maintain electricity installation for the generation, transmission and distribution of electricity. To achieve the above objectives, the company owns and operates power plants and the National Grid and installed for this purpose, customer service center, call management center, substations and istrative offices throughout Peninsular Malaysia. TNB`s core activities are in generation, transmission and distribution of electricity which are being handled by its subsidiaries: • • •
TNB Generation Sdn Bhd TNB Transmission Network Sdn Bhd TNB Distribution Sdn Bhd
TNB Vision: To be among the leading corporation in energy and related business globally. TNB Mission: We are committed to excellence in our product and service.
INDUSTRIAL TRAINING SCHEDULE 9 MARCH 2015 UNTIL 31 MAY 2015
DATE
DEPARTMENT
AMOUNT OF DAY
MAIN ACTIVITY
REPORT
PROJECT PLANNING
09/03/2015 05/04/2015
PLANNING & CONSTRUCTION
28
CABLE
EN NORAZMI BIN ARIFFIN
SUBSTATION OVER HEAD
06/04/2015 03/05/2015
04/05/2015 28/05/2015
METERING
28
METER SERVICE
EN MOHD FADZLI BIN MOHD TAHIR
SUBSTATION OPERATION & MAINTENANCE
28
OVER HEAD CABLE FAULT FINDER
EN. AZLI HILMI BIN FAUDZI@MD RAWI
consturction department
In construction department, they responsible to construct substation and overhead pole. Usually, contractor will do the initial work like dig hole for ing, places the switchgear or transformer, place the pole and the other work.
Apart from that, TNB also responsible to shut down the substation that involved in the construction before the contractor start doing their job to avoid accident from happening.
The important work in construction job is ing cable to make sure that the new substation will get the supply to operate . Furthermore ing cable is done when there is breakdown which happened because the cable is damaged.
Type of cable
Paper Insulated Lead Cable (PILC)
Cross Linked Polyethylene (XLPE)
PILC
Amp
XLPE
Amp
25
90
150
320
70
160
240
400
120
230
500
550
185
290
300
380
Cable
ing cable
There two types of ing cable that are:
Straight through t
Termination t
Termination t
straight through t
Breakdown of cable
Low Voltage Overhead Lines
Presently all new lines are constructed using aluminum.
Copper conductors are used only for repair of copper lines.
Advantages of Aluminum :
cheaper than copper
lighter and easier to handle
less scraper value, not prone to theft
Disadvantages of Aluminum :
softer than copper and required careful handling
oxidizes easily making connections more difficult
Conductor rating ABC
Amp
BARE
Amp
1X16+25
80
3/132
120
3X16+25
80
7/122
170
3X95+70
190
7/122
170
3X185+120
300
Poles For LV Overhead Line Four types of poles are used in the TNB :
Wood Poles
Pre-stressed Spun Concrete poles
Reinforced Concrete Poles
The functions of poles are:
To conductors and accessories such as fuses and cable boxes
The safety clearance from the ground, building are maintained
The standard lengths are:
10 meter -
for HT cable (HV)
High Voltage Cable
The 11kV supply that feeds into switchgear comes in the XLPE cable (HV cable).
In one cable, have three cores (R, Y, B) which is connected to the three terminals of incoming feeder of the switchgear.
From the switchgear, the supply goes to the HV side of the transformer through XLPE cable
Switchgear
Transformer
Feeder Pillar
Planning department
This department is responsible to estimation the project include in deg, planning in all new project requested by s and modified system available depends on situation.
This department also responsible to calculate maximum demand, cable size, calculate load, and determine suitable transformer size and switchgear for consumer
Estimating the project
Estimation of substation project involves working out the cost of the following
Land
Salaries
Materials
Contract
Transport
Overhead
SITE VISIT Site visits are essential before planning starts. The following can be obtained from site visits. a) Sources of supply b) Types of loads c) Site information on:
Trees
Ground conditions and terrain
Other services on site such as telephone lines and water mains.
Drains, stream, ponds etc
MAKING A Site visit
Metering unit
Type Of Metering Used To Consumer :
a) Ordinary power consumer meter (OPC meter)
Metering
b) Large Power consumer meter (LPC meter)
Ordinary Power Consumer (OPC)
1. Electromechanical single phase 2. Electronic single phase 3. Electromechanical three phase 4. Electronic three phase
Large Power Consumer (LPC)
1. Electromechanical three phase (LV) 2. Electronic three phase (LV) 3. Electromechanical three phase (HT) 4. Electronic three phase (HT)
Type of metering There are three types of metering 1. Single phases metering (OPC meter).
The current value uses in fuse about 10-50 A.
Use two wire connected from supply to meter board consumer
Having one cut out and one neutral link
2. Three phase metering (OPC meter)
The current value uses in fuse about 10-60 A.
Used four wire connected from supply to meter board consumer
Having one neutral link and three cut out
3. Large power consumer meter (LPC meter).
Use digital electronic meter
Use current transformer
Component of meter a) The devices at meter board are
Cut out
Neutral link
Meter
