KKS Classification System

0 0 - T A A - B E B - 1 0 0 0 0 0

dms-7677A01\0.000 PROJECT ORG\040 Project manual\KKS Guidline\editable Version

REV: - 0 2

02

PACKAGE “P” POWER PLANT RAS AL KHAIR POWER AND DESALINATION PLANT – PHASE 1 Subject: Doc No.:

Page 2 of 50

KKS Classification System 0

0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

Chapter Index 1 2

Purpose and fields of application .................................................................................................. 4 Types of Code .............................................................................................................................. 5 2.1 Types of code and breakdown levels .................................................................................... 5 2.2 Prefix Symbols and Breakdown Symbols for Types of Code ................................................ 7 2.3 Format of Breakdown Levels ................................................................................................. 8 Read from left to right no data characters may be omitted. Special guidelines apply to data characters G, F0 and A3. ................................................................................................................... 8 2.4 Classifying Code Elements.................................................................................................... 8 2.5 Numbering Code Elements ................................................................................................... 9 2.6 Notation of Codes ................................................................................................................ 10 3 General Establishments.............................................................................................................. 10 3.1 Total Plant G........................................................................................................................ 11 4 Establishments for the allocation of Process-Related Codes ..................................................... 12 4.1 System Code ....................................................................................................................... 13 4.1.1 Prefix Number F0 .......................................................................................................... 13 4.1.2 System Classification F1 F2 F3 ...................................................................................... 15 4.1.3 System Numbering FN .................................................................................................. 17 4.2 Equipment Unit Code ..........................................................................................................18 4.2.1 Equipment Unit Classification A1A2 .............................................................................. 18 4.2.2 Equipment Unit Numbering AN ..................................................................................... 19 4.2.3 Additional Code A3 ....................................................................................................... 22 4.3 Component Code ................................................................................................................23 4.3.1 Component Classification B1B2 .................................................................................... 23 4.3.2 Component Numbering BN ........................................................................................... 27 4.3.3 s ....................................................................................................................... 27 4.4 Rules governing the identification of s in the field of mechanical engineering ........ 27 4.5 Rules governing the identification of mechanical (process) systems which supply the main process ........................................................................................................................................... 28 4.6 Rules governing the identification of system-interfacing analog signal processing ............. 28 4.7 Rules governing the classification and numbering of signals and signal applications in breakdown level 3 .......................................................................................................................... 28 4.8 Rules governing KKS designations for Electrical Systems .................................................. 30 4.8.1 ..... Electrical Systems ………...……………………………………………………………30 4.8.2 .... Space heaters for Motors ……...……………………………………………………………30 5

Establishments for the allocation of Point of Installation Identifiers ............................................ 29 5.1 Use of data characters in point of installation identification ................................................. 31



Page 3 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

5.2 Prefix Number F0 ................................................................................................................. 31 5.3 Installation Unit Classification F1 F2 F3 ................................................................................ 31 5.4 Numbering of installation units FN........................................................................................ 33 5.5 Installation units according to installation spaces ................................................................ 34 5.5 Withdrawable Units for Motor Control Centre(MCC) ........................................................... 34 6 Establishments for the allocation of location identifiers .............................................................. 36 6.1 Use of data characters in location identification .................................................................. 37 6.2 Structure Code F0, F1 F2 F3 and FN ...................................................................................... 37 6.2.1 Subdivision of Structures into Floor Level Numbering ( Floor Counting ) .................... 38 6.3 Room Code ......................................................................................................................... 39 6.3.1 Room Identification by Numbering ............................................................................... 40 7 Piping Identification and Attributes ............................................................................................. 41 7.1 Piping Identification Code ....................................................................................................41 7.2 Pipeline attributes ................................................................................................................ 41 8 Cables and Cable Raceways Identification ................................................................................ 42 8.1 Cable Numbering System .................................................................................................... 42 8.1.1 Classifying Element (NNAAA) ...................................................................................... 42 8.1.2 Numbering Element (NNNN) ........................................................................................ 42 8.1.3 Example of cable No. ................................................................................................... 44 8.2 Cable Raceway Numbering System .................................................................................... 44 8.2.1 Classifying Element (NN AAAN) .................................................................................. 44 8.2.2 Numbering Element (ANN AN) ..................................................................................... 45 9 Annexes ...................................................................................................................................... 46



Page 4 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

1 Purpose and fields of application This KKS classification system describes the demand on power plant identification and states the definition of the VGB KKS-Identification System for Power Stations more precisely to conduce to a consistent processing of Ras Al Khair Power & Desalination Plant Phase 1. This guideline shall not replace the effective VGB KKS-Identification System. The basis for classification is: VGB KKS-Identification System for Power Stations VGB-B 105 E 7th Edition 2010 (Index E) Published by VGB PowerTech Service GmbH Verlag technisch-wissenschaftlicher Schriften Postbox 10 39 32, D-45039 Essen. The Water and Power Plants identification codes to be used and the associated text explanations are specified in the edition of the KKS Identification System for Water and Power Plants, specifically issued for Ras Al Khair Phase 1 Power and Desalination Project: Annex 1: RAZ KKS Function Key Annex 2: RAZ KKS Equipment Unit Key Annex 3: RAZ KKS Component Key Annex 4: Abbreviation Catalogue for CP and SPP 2

References: RAZ KKS Denomination of buildings and structures RAZ KKS Room Numbering

If it will become necessary to add or modify certain identification codes in the course of the project, the identification codes in question shall be named to and reviewed by the parties of the project. Such additions and modifications result in a revision of the KKS index which shall be submitted for Owner review.



Page 5 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

2 Types of Code The generally accepted format of KKS classification and the content of data position are described in the VGB KKS-Identification System for Power Stations, 7th edition 2010. In this chapter the structure (content and body) is shown according to KKS Identification System.

2.1 Types of code and breakdown levels In consideration of the various requirements placed on the identification of plants, sections of plants and items of equipment in power stations, KKS has three different types of code: Process-Related Code Process-related identification of systems and items of equipment according to their functions in mechanical, civil, electrical and Instrumentation and Control (I & C) engineering. Point of Installation Code Identification of points of installation of electrical and Instrumentation and Control equipment in installation units (e.g. in cabinets, s, consoles). Location Code Identification of locations in structures, on floors and in rooms and also of fire areas. These three types of code use the same identification scheme, which is subdivided into four breakdown levels. Originally the titles of the breakdown levels were based on the process-related code: Breakdown level Title of breakdown level

0

1

2

3

Total plant

Function

Equipment Unit

Component

The titles of the breakdown levels of the three types of code will henceforth be as follows: Serial no. of Breakdown level

Process-related Identification

Point of installation Identification

0

1

2

3

Total Plant

System Code

Equipment Unit Code

Component Code

Total Plant

Installation Unit Code

Installation Space Code



Location Identification

Page 6 of 50


0

-

T

A

A

-

B

E

Total Plant

B

-

1

0

0

0

0

0

Structure Code


-

0

2

-

0

Room Code

2


Page 7 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

2.2 Prefix Symbols and Breakdown Symbols for Types of Code The types of code are distinguished in accordance with DIN 40719, Part 2, by means of prefix and breakdown symbols. Breakdown Level

0

1

2

3

Equipment Unit Code

Component Code

Process-related Identification

=

Total Plant

System Code

Point of installation Identification

+

Total Plant


Location Identification

+

Total plant

Structure Code

Prefix symbol

●


Room code

Breakdown symbol

The prefix symbols are necessary because in some applications the same code letters are used on breakdown level 1 for different types of code (System, Installation and Structure Code); consequently confusion is possible if prefix symbols are not entered. The prefix symbols may be omitted if the information contents of the codes remain unambiguous. The „full stop“ (“ • “) breakdown symbol for point of installation identification is necessary for positive distinction between types of code and therefore must always be written.

Example: Process-related code: Point of installation code:

MSF #71 Brine Recycle Pump Motor Switchgear Address


= 71GDG41 AP101 + 71BBC01•


Page 8 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

2.3 Format of Breakdown Levels The code consists of breakdown levels. The individual breakdown levels are differently formatted. They are made up of classifying and numbering code elements. The latter consist of data characters occupied by alpha (“A”) and numeric (“N”) symbols. Breakdown Level

0

Designation of Data character

G

F0

F1F2F3

FN

A1 A2

AN

A3

B1B2

BN

A or N

N(N)

AAA

NN

AA

NNN

A

AA

NN

Type of data Character

1

2

3

A = Alpha characters (Roman letters except I and O, and special symbols) N = Numerical characters (Arabic numerals) The breakdown levels and the data characters within the breakdown levels denote progressively smaller entities from left to right.

2.4 Read from left to right no data characters may be omitted. Special guidelines apply to data characters G, F0 and A3.Classifying Code Elements The code elements F1, F2, F3, A1 , A2 and B1, B2 have a classifying function.

Main groups F1 Groups F2 Subgroups F3 Main groups A1 Subgroups A2 Main groups B1Subgroups B2


Page 9 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

The classifying coding letters and designations are established on a non-project-specific basis in the KKS keys, as follows:

  

Function Key, for F1 / F1 F2 / F1 F2 F3 on breakdown level 1 Equipment Unit Key, for A1 / A1 A2 on breakdown level 2 Component Key, for B1 / B1 B2 on breakdown level 3

The terminology of the key may be modified on a project-specific basis but only provided that the contents are not altered. Such modifications are subject to agreement between the parties to the project. “Blocked” coding letters are reserved for future technologies and new systems engineering configurations.

2.5 Numbering Code Elements The code elements F0, FN, AN, A3 and BN (and optional G) have a numbering function.

These numbering code elements are subject to agreement on a project-specific basis and between the parties to the project as regards numbering systems and direction of numbering. For this project, the following principles are applied for.

    

Numbering starts anew when one of the preceding code elements changes. Numbering is grouping (e.g. 71, 72, 73 …). Numbering need not be continuous. Numbering conventions, once established, may not be altered, not even in the event of changes made in the progress of planning. Redundant zeros must be written



Page 10 of 50


0

-

T

A

A

-

B

E

B

-

1

0

0

0

0

0

-

0

2

-

0

2

2.6 Notation of Codes The notation to be applied for Ras Al Khair Power Plant Project Phase 1 Power and Desalination Project are as follows: Level

0

1

2

3

NNAAANN

AANNNA

AANN

=

11MAB10

AP001

KP01

=

71GDC21

AP101

With Blank Spaces Example Power Plant: IP Turbine #11 Pump #01 of Unit #001 Example Desalination Plant: MSF #71 B/H Condensate Pump:

NOTE: Breakdown level 0 (overall plant) shall not be used. NOTE: For Desalination Plant Breakdown level 3 will be used for Instrumentation and Control (I & C), if necessary. NOTE: The data character A3 is only written if required.

3 General Establishments 1) Changes to KKS designations: Changes to KKS designations are only possible as long as the content of the new designations stays the same. 2) Rules governing numbering systems and direction of numbering for all numbering code elements: The principles established in the Guidelines for KKS Application apply. An applicationspecific logic will be established for the specific engineering disciplines. 3) Rules relating to breakdown level 0: Breakdown level 0 (overall plant) shall not be used. 4) Rules on spacing for code notation: In all cases where the code is needed in the scope of operations management and associated documentation, the small spacing shall be used as defined in the Guidelines for KKS Application, with the restriction that breakdown level 0 shall not be used and the prefix number F0 of breakdown level 1 shall be used as a 2-digit data character. The space between the first two data characters shall be omitted. Example: For Process Related Code For Location Code
