Inspection Test Plan 3y5e21

For Approval

A

IFA

2012-08-17

For Approval

C.H.Jang

J.S.Jeon

H.J.Jo

Rev

Purpose

Issue Date

Description

Prepared by:

Reviewed by:

Approved by:

Owner:

HAJR Electricity Production Company Contractor:

Sub Contractor:

NK TECH CO., LTD. Project:

Qurayyah Independent Power Project Document Title:

Inspection and Test Plan (ITP) Document No.: QIPP-MPN025-G00-3002 Owner’s Document No.:

QIPP-MPN025-G00-3002

INSPECTION AND TEST PLAN ITEM

:

1

QIPP-MPN025-G003002

DATE PAGE

17. AUG. 2012 2 OF 3

SERVICE GAS SYSTEM(N2) INSPECTION ITEM & APPLICABLE CONTROL PROCEDURE

NO.

DOC.NO.

APPLICABLE CODE & PROCEDURE

VERIFICATION DOCUMENT

INSPECTION LEVEL REMARKS NKT

SCT

TEST REPORT

H

R

Surface Preparation and

PAINT REPORT

H

R

Painting Procedure

Genetian Blue (RAL 5010)

R R R R

. N2 GAS CYLINDER

CODE: KS B ISO9809 / Mn STEEL

1) HYDRO TEST

Hydrostatic Test Procedure TEST PRESSURE :250 barg

2) SHOT & PAINT

2

. MANIFOLD PIPE'S (N2)

CODE : ASTM A106

1) MATERIAL I.D

APPREVED DWG'

MILL CERTIFICATE

2) FIT-UP

WPS NO: NK-GT.FC-04-002

WELDER VERIFICATION

3) WELDING VISUAL

WPS NO: NK-GT.FC-04-002

WELDER VERIFICATION

4) NDT

MT:100%

NDT CERTIFICATE

R H H H

5) HYDRO TEST

Hydrostatic Test Procedure

TEST REPORT

H

W

TEST PRESSURE : 230 barg 6) VISUAL & DIMENSION INSP.

APPROVED DRAWING

DIMENSION CHECK SHEET

H

R

7) PAINT INSPECTION

Surface Preparation and

PAINT INSPECTION REPORT

H

W

H

R

Painting Procedure 3

. CYLINDER RACK / REDUCING SKID 1) MATERIAL I.D

APPROVED DRAWING

2) VISUAL & DIMENSION & Welding INSP. APPROVED DRAWING

DIMENSION CHECK SHEET

H

R

3) PAINT INSPECTION

PAINT REPORT

H

R

MAKER'S STANDARD TEST REPORT

R

R

Painting Procedure

- HOT-DIP GALVANIZED 4

. VALVE, FLEXIBLE HOSE

CODE : APPROVED DRAWING

& INSTRUMENTS 1) RECEIVING INSPECTION

H: HOLD W: WITNESS

R: REVIEW

APPROVED DRAWING

- : Not Applicable

S/V: SUB VENDOR

NKT: NK TECH CO.,LTD.

SCT:SAMSUNG C&T

INSPECTION AND TEST PLAN ITEM NO.

5

:

QIPP-MPN025-G003002

DATE PAGE

17. AUG. 2012 3 OF 3

SERVICE GAS SYSTEM(N2) INSPECTION ITEM & APPLICABLE CONTROL PROCEDURE

APPLICABLE CODE & PROCEDURE

VERIFICATION DOCUMENT

INSPECTION LEVEL REMARKS NKT

SCT

. PACKING INSPECTION PACKING & SHIPPING CONDITION

6

DOC.NO.

. DOCUMENTATION

Handling & Shipping Procedure

PACKING LIST

H

W

Inspection & Test Procedure

QALIITY VERIFICATION

H

R

DOCUMENT LIST

H: HOLD W: WITNESS

R: REVIEW

- : Not Applicable

S/V: SUB VENDOR

NKT: NK TECH CO.,LTD.

SCT:SAMSUNG C&T
