MIDAS
DShop
Drawing Auto-Generation Module for MIDAS/Gen
MIDAS/DShop Configurations 1) Drawing Generation Module - Auto-placement of reinforcement bars reflecting constructibility - Convenient edit functions for RC reinforcement information - Offset adjustment functions based on member types
2) Drawing Generation Module - Drawing construction and edit functions identical to AutoCAD - Drawing functions for (Slab / Beam / Column / Brace / Wall / Foundation) - Variety of symbol generation functions
- Import Analysis & Design results from MIDAS/Gen - Rebar Placement Spec. checking functions - Auto-generation of Grid Lines and Grid Mark & Dimension creation/edit function
- Rebar auto-placement by reflecting constructibility - Reinforcement Edit function for (Beam, Column, Brace, Wall & Footing) - Auto-grouping & Group editing functions based on member types
- General Notes Creation/Edit - Member Offset Edit functions - Drawing Production Environment selection functions
- Drawing Style & Member Mark Location selection functions - Drawing Form Insertion function - Drafting & Editing functions Copyright 2008 MIDAS Information Technology Co.,Ltd.
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
1. MIDAS Draw GUI composition
MIDAS DShop
Pull Down Menu Bar
Toolbar
Main View Menu
Floor View
MIDAS
Gen
MIDAS
Integrated Design System for Building and General Structures
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
2. MIDAS/Dshop Features MIDAS/Gen design results used to auto-generate structural drawings (General Notes / Plans / Sections / Member Schedule Drawings)
Reinforced concrete, Structural steel & RC/SS composite construction ed Drawings saved into DWG / DXF / DGN file formats MIDAS/Draw consists of Drawing Generation Module & Drawing Edit Module Drawing Generation Module
Auto-placement of reinforcement bars reflecting constructibility Convenient edit functions for RC reinforcement information Offset adjustment functions based on member types Drawing Edit Module
Drawing construction and edit functions identical to AutoCAD Drawing functions for (Slab / Beam / Column / Brace / Wall / Foundation) Variety of symbol generation functions
MIDAS
Gen
MIDAS
MIDAS DShop
Integrated Design System for Building and General Structures
3. Import Analysis & Design results from MIDAS/Gen Rebar Placement Method 1
Use rebar diameters, numbers & spacing designed by MIDAS/Gen Rebar Placement Method 2 Use reinforcement quantity designed by
MIDAS/Gen rearranged for constructibility
4. Rebar Placement Spec. checking functions RC reinforcement spec check Wall reinforcement spec check Structural steel check RC/SS reinforcement spec check
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
5. Auto-generation of Grid Lines and Grid Mark & Dimension creation/edit function Grid Mark Creation / Edit Addition & Deletion functions
Rearrangement of order & Grid number edit functions
Dimension Creation / Edit Addition & Deletion functions
6. Rebar auto-placement by reflecting constructibility Rebar placement specs by (Beam, Column, Brace, Wall & Footing)
Rebar placement reflecting constructibility Check for clear spacing of rebar Specify rebar placement method for constructibility Specify rebar diameters by stories &
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
7. Reinforcement Edit function by (Beam, Column, Brace, Wall & Footing) Member data Edit functions (RC, SS & SRC) Change in reinforcement reflected by & groups
8. Auto-grouping & Group editing functions by member types Auto-grouping function for having identical data (section size, rebar quantity, rebar diameter, spacing & number of rebar)
-editing function for auto-grouped results
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS
MIDAS DShop
Integrated Design System for Building and General Structures
9. General Notes Creation / Edit Generation of reference, structural types, materials, rebar / steel splices, foundation conditions, etc.
Key Plan & Key Section insertion functions
10. Member offset Edit functions Offset-Move for Beam, Column, Brace, Wall & Footing
Offset-Move by & groups
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
11. Drawing Production Environment selection functions Layer, Text Style, Dimension Style & Symbol selection functions
Symbol (Member Mark, Rebar Designation & Grid Mark) selection functions
Saving & reloading the selected environment
12. Drawing Style & Member Mark Location selection functions Member Mark located anywhere on Section / Plan View Point selected freely Column Center Composite Plan generated
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
13. Drawing Form Insertion function Drawing Size, Drawing Scale & Line Type Scale assigned
-defined Drawing Form
14. Drafting & Editing functions Drafting & Editing functions identical to AutoCAD Variety of functions for drafting by member units Many functions related to drafting symbols
MIDAS
Gen
DShop
MIDAS
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15. Auto-generation of B.O.M (Bill Of Material) B.O.M Summary Table FL
Concrete Volume Reinforced Bars Mechanical Splices Construction Forms Steel
ROOF
7F
- Total Length per Material
6F
- Paint Area - Weight
5F
Concrete(㎥)
Reinforced Bars(t)
245㎏/㎠
280㎏/㎠
#3
#4
#7
Mechanical Splices(EA)
Form(㎡)
Steel (t)
Beam
7.9
0.0
0.27
0.00
0.63
0
65.7
0.00
Column
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Beam
15.3
2.8
0.54
0.18
1.60
0
145.0
26.95
Column
6.2
0.0
0.65
0.00
0.73
0
62.4
0.00
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Beam
11.8
2.8
0.42
0.13
1.12
0
115.8
24.61
Column
6.5
34.0
1.32
0.00
2.15
0
298.4
9.17
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
9.3
0.0
0.17
0.26
0.00
0
46.6
0.00
Beam
13.2
2.8
0.47
0.13
1.22
0
127.1
24.05
Column
6.5
34.0
1.37
0.00
2.62
0
298.4
9.17
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
9.3
0.0
0.17
0.31
0.00
0
46.6
0.00
Steel Shapes Summary Table Steel Shape
Material
Total Length(m)
Paint Area(㎡ Inner
Outer
Weight(t)
H 100x50x5/7
SS490
12.60
0.00
4.74
H 250x125x6/9
SS490
105.62
0.00
102.18
3.12
H 300x150x6.5/9
SS490
421.60
0.00
491.03
15.48
H 300x300x10/15
SS490
452.30
0.00
791.12
42.54
H 350x175x7/11
SS490
14.58
0.00
19.86
0.72
H 396x199x7/11
SS490
75.00
0.00
115.99
4.25
H 400x200x8/13
SS490
40.90
0.00
63.66
2.70
H 450x200x9/14
SS490
125.92
0.00
207.91
9.56
H 506x201x11/19
SS490
52.00
0.00
91.50
5.36
H 582x300x12/17
SS490
34.80
0.00
79.76
4.77
H 594x302x14/23
SS490
135.60
0.00
314.58
23.67
H 596x199x10/15
SS490
170.80
0.00
329.68
16.16
H 606x201x12/20
SS490
194.80
0.00
380.68
23.32
1,836.53 m
0.00 ㎡
2,992.70 ㎡
151.77 t
Summary
0.12
Remarks
)
Remarks
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15-1. Drawing Production - General Notes
?
? ?
? ?
記事
年 月 日 作製 年 月 日 年 月 日 年 月 日
設計No.
工事名?
? 面名?
縮尺
? 面番?
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-2. Drawing Production - Foundation Plan (w/ seismic Ties)
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-3. Drawing Production - 1st Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-4 . Drawing Production - 3rd Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-5. Drawing Production - Typical Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-6. Drawing Production - Sectional Elevation X2-X3 Line
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-7. Drawing Production - Sectional Elevation Y5-Y7 Line
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-8. Drawing Production - Girder Schedule
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-9. Drawing Production - Column Schedule
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15-10. Drawing Production - Beam Schedule
? ?
? ?
記事
年 月 日 作製 年 月 日 訂正 年 月 日 年 月 日
設計N o.
工事名?
? 面名?
縮尺
? 面番?
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-11. Drawing Production - Column Center Composite Plan
MIDAS DShop
Drawing Auto-Generation Module For MIDAS/Gen
www.midas.com
DShop
Drawing Auto-Generation Module for MIDAS/Gen
MIDAS/DShop Configurations 1) Drawing Generation Module - Auto-placement of reinforcement bars reflecting constructibility - Convenient edit functions for RC reinforcement information - Offset adjustment functions based on member types
2) Drawing Generation Module - Drawing construction and edit functions identical to AutoCAD - Drawing functions for (Slab / Beam / Column / Brace / Wall / Foundation) - Variety of symbol generation functions
- Import Analysis & Design results from MIDAS/Gen - Rebar Placement Spec. checking functions - Auto-generation of Grid Lines and Grid Mark & Dimension creation/edit function
- Rebar auto-placement by reflecting constructibility - Reinforcement Edit function for (Beam, Column, Brace, Wall & Footing) - Auto-grouping & Group editing functions based on member types
- General Notes Creation/Edit - Member Offset Edit functions - Drawing Production Environment selection functions
- Drawing Style & Member Mark Location selection functions - Drawing Form Insertion function - Drafting & Editing functions Copyright 2008 MIDAS Information Technology Co.,Ltd.
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
1. MIDAS Draw GUI composition
MIDAS DShop
Pull Down Menu Bar
Toolbar
Main View Menu
Floor View
MIDAS
Gen
MIDAS
Integrated Design System for Building and General Structures
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
2. MIDAS/Dshop Features MIDAS/Gen design results used to auto-generate structural drawings (General Notes / Plans / Sections / Member Schedule Drawings)
Reinforced concrete, Structural steel & RC/SS composite construction ed Drawings saved into DWG / DXF / DGN file formats MIDAS/Draw consists of Drawing Generation Module & Drawing Edit Module Drawing Generation Module
Auto-placement of reinforcement bars reflecting constructibility Convenient edit functions for RC reinforcement information Offset adjustment functions based on member types Drawing Edit Module
Drawing construction and edit functions identical to AutoCAD Drawing functions for (Slab / Beam / Column / Brace / Wall / Foundation) Variety of symbol generation functions
MIDAS
Gen
MIDAS
MIDAS DShop
Integrated Design System for Building and General Structures
3. Import Analysis & Design results from MIDAS/Gen Rebar Placement Method 1
Use rebar diameters, numbers & spacing designed by MIDAS/Gen Rebar Placement Method 2 Use reinforcement quantity designed by
MIDAS/Gen rearranged for constructibility
4. Rebar Placement Spec. checking functions RC reinforcement spec check Wall reinforcement spec check Structural steel check RC/SS reinforcement spec check
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
5. Auto-generation of Grid Lines and Grid Mark & Dimension creation/edit function Grid Mark Creation / Edit Addition & Deletion functions
Rearrangement of order & Grid number edit functions
Dimension Creation / Edit Addition & Deletion functions
6. Rebar auto-placement by reflecting constructibility Rebar placement specs by (Beam, Column, Brace, Wall & Footing)
Rebar placement reflecting constructibility Check for clear spacing of rebar Specify rebar placement method for constructibility Specify rebar diameters by stories &
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
7. Reinforcement Edit function by (Beam, Column, Brace, Wall & Footing) Member data Edit functions (RC, SS & SRC) Change in reinforcement reflected by & groups
8. Auto-grouping & Group editing functions by member types Auto-grouping function for having identical data (section size, rebar quantity, rebar diameter, spacing & number of rebar)
-editing function for auto-grouped results
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS
MIDAS DShop
Integrated Design System for Building and General Structures
9. General Notes Creation / Edit Generation of reference, structural types, materials, rebar / steel splices, foundation conditions, etc.
Key Plan & Key Section insertion functions
10. Member offset Edit functions Offset-Move for Beam, Column, Brace, Wall & Footing
Offset-Move by & groups
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
11. Drawing Production Environment selection functions Layer, Text Style, Dimension Style & Symbol selection functions
Symbol (Member Mark, Rebar Designation & Grid Mark) selection functions
Saving & reloading the selected environment
12. Drawing Style & Member Mark Location selection functions Member Mark located anywhere on Section / Plan View Point selected freely Column Center Composite Plan generated
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS
Gen
MIDAS DShop
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
13. Drawing Form Insertion function Drawing Size, Drawing Scale & Line Type Scale assigned
-defined Drawing Form
14. Drafting & Editing functions Drafting & Editing functions identical to AutoCAD Variety of functions for drafting by member units Many functions related to drafting symbols
MIDAS
Gen
DShop
MIDAS
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15. Auto-generation of B.O.M (Bill Of Material) B.O.M Summary Table FL
Concrete Volume Reinforced Bars Mechanical Splices Construction Forms Steel
ROOF
7F
- Total Length per Material
6F
- Paint Area - Weight
5F
Concrete(㎥)
Reinforced Bars(t)
245㎏/㎠
280㎏/㎠
#3
#4
#7
Mechanical Splices(EA)
Form(㎡)
Steel (t)
Beam
7.9
0.0
0.27
0.00
0.63
0
65.7
0.00
Column
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Beam
15.3
2.8
0.54
0.18
1.60
0
145.0
26.95
Column
6.2
0.0
0.65
0.00
0.73
0
62.4
0.00
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Beam
11.8
2.8
0.42
0.13
1.12
0
115.8
24.61
Column
6.5
34.0
1.32
0.00
2.15
0
298.4
9.17
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
9.3
0.0
0.17
0.26
0.00
0
46.6
0.00
Beam
13.2
2.8
0.47
0.13
1.22
0
127.1
24.05
Column
6.5
34.0
1.37
0.00
2.62
0
298.4
9.17
Brace
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Slab
0.0
0.0
0.00
0.00
0.00
0
0.0
0.00
Wall
9.3
0.0
0.17
0.31
0.00
0
46.6
0.00
Steel Shapes Summary Table Steel Shape
Material
Total Length(m)
Paint Area(㎡ Inner
Outer
Weight(t)
H 100x50x5/7
SS490
12.60
0.00
4.74
H 250x125x6/9
SS490
105.62
0.00
102.18
3.12
H 300x150x6.5/9
SS490
421.60
0.00
491.03
15.48
H 300x300x10/15
SS490
452.30
0.00
791.12
42.54
H 350x175x7/11
SS490
14.58
0.00
19.86
0.72
H 396x199x7/11
SS490
75.00
0.00
115.99
4.25
H 400x200x8/13
SS490
40.90
0.00
63.66
2.70
H 450x200x9/14
SS490
125.92
0.00
207.91
9.56
H 506x201x11/19
SS490
52.00
0.00
91.50
5.36
H 582x300x12/17
SS490
34.80
0.00
79.76
4.77
H 594x302x14/23
SS490
135.60
0.00
314.58
23.67
H 596x199x10/15
SS490
170.80
0.00
329.68
16.16
H 606x201x12/20
SS490
194.80
0.00
380.68
23.32
1,836.53 m
0.00 ㎡
2,992.70 ㎡
151.77 t
Summary
0.12
Remarks
)
Remarks
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15-1. Drawing Production - General Notes
?
? ?
? ?
記事
年 月 日 作製 年 月 日 年 月 日 年 月 日
設計No.
工事名?
? 面名?
縮尺
? 面番?
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-2. Drawing Production - Foundation Plan (w/ seismic Ties)
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-3. Drawing Production - 1st Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-4 . Drawing Production - 3rd Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-5. Drawing Production - Typical Floor Framing Plan
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-6. Drawing Production - Sectional Elevation X2-X3 Line
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-7. Drawing Production - Sectional Elevation Y5-Y7 Line
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-8. Drawing Production - Girder Schedule
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-9. Drawing Production - Column Schedule
MIDAS
Gen
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
Integrated Design System for Building and General Structures
MIDAS DShop
15-10. Drawing Production - Beam Schedule
? ?
? ?
記事
年 月 日 作製 年 月 日 訂正 年 月 日 年 月 日
設計N o.
工事名?
? 面名?
縮尺
? 面番?
MIDAS
Gen
Integrated Design System for Building and General Structures
MIDAS
DShop
Drawing Auto-Generation Module For MIDAS/Gen
MIDAS DShop
15-11. Drawing Production - Column Center Composite Plan
MIDAS DShop
Drawing Auto-Generation Module For MIDAS/Gen
www.midas.com
Related Documents 3m3m1z
Midas Drawingshop 4ae52
August 2020 0
Akhil Midas 1j2263
February 2022 0
Midas Surveyor 6p2x2u
May 2023 0
Test Midas 1z68t
December 2019 34
Cuestionario Midas 22y4
November 2019 101
Midas Catalogue 3t3z3f
November 2021 0More Documents from "Kapil Dev Bansal" 5b2n46
Midas Drawingshop 4ae52
August 2020 0
(##)water Fuel Engine Cum Lpg 5g2j2d
November 2019 36
Application Of Hplc In Pharmaceutical Industries 313764
October 2019 23
Icici 3.docx 691i4g
October 2021 0
Shivaji Bhosle z578
December 2019 56
