Principles of shiphandling 0
More Next Blog»
Create Blog Sign In
Principles of shiphandling Defines Shiphandling and Maneuvering. Also describes the Basic movement of a ship and talks about the factors and forces affecting shiphandling. Ads by Google ► Cruise Ship ► Games ► Ship a Boat ► Simulator
Ship handling
Pivot point
Basic Propeller Types
Sunday, November 13, 2011
Principles of ship Handling Ship Handling and Maneuvering is defined as the art of proper control of a ship while underway, especially in harbours, around docks and piers. It is one of the skills that any ship handler finds very satisfying when well accomplished. The most basic thing to be understood in ship handling is to know and anticipate how a ship behaves under all circumstances and what orders should be given in order to make the ship behave and move exactly the way you want her to. The difference between the ships’s heading and the actual direction of movement of the ship should also be constantly attended to as this is essentially important at slow speeds and when there is wind and current.
HDFC™ Home Loan Online
EMI of just Rs 841* per lakh. Check Eligibility, Instant Approval
Three basic ship motions: 1. Longitudinal motion (forward or astern). 2. Lateral motion (sideways). 3. Rotational or turning motion.
Vessels also have other behaviors worth noting when her maneuvering equipment is in operation. Depending on the type of propeller, a ship with a single propeller when run ahead from stop cants to either port or starboard; when put astern from stop the stern cants at a fast rate to port or starboard. When a ship has headway and the rudder is put over to one side, the bow turns to the same side where the rudder is turned. Thrusters on the other hand move the vessel’s end sideways. Thrusters, depending on its design increase its effectiveness as the vessel slows down.
Followers
this site with Google Friend Connect
(1)
Factors and forces that commonly constitute a change in a vessel’s behavior while being maneuvered: External Factors/forces: Already a member? Sign in
1. Tide.
http://principlesofshiphandling.blogspot.in/
Blog Archive
1/3
4/1/2016
Principles of shiphandling 2. Sudden change in wind velocity and direction (gust). 3. Set and drift.
▼ 2011 (1) ▼ November (1) Principles of ship Handling
4. Proximity of other vessels. 5. Depth of harbours.
About Me
Internal Factors/forces under the control of the Ship handler:
My Photo
1. Engine power. 2. Speed.
Filgen D Yurong
3. Effect of the type of propeller.
View my complete profile
4. Rudder movement and type. 5. Thrusters. 6. Anchors and mooring lines. 7. Tugboats.
Effects of external forces: The effects of external forces may become advantageous or disadvantageous to the ship handler. It is best that these effects are foreseen beforehand so that necessary steps to counter or make use of them during the maneuver are made. As some experts put it; “ the art of ship handling involves the effective use of the forces under one’s control to overcome the effects of external forces”. Among the external forces, the effects of the wind and current are the most important. These forces greatly affect the movement of the ship. When there is wind blowing on one side of a high sided ship moving ahead, she will not move along the line of the intended course line but rather drift towards the lee side of the ship. Likewise, if a current is acting on one side of a ship, she will behave in the same manner, that is, she will be moving diagonally in the direction where the current is setting although her heading is on the course steered. To attain the desired track we make allowance for set to compensate for a current and allowance for leeway to compensate for the wind. Always bear in mind that currents affect ships more than the wind and allowances made to compensate for these factors are called set because generally it is not possible to separate the difference. If a ship steers a course of 270 degrees, and the current is setting north, she will deviate considerably towards the north from the course line. The angular difference between the ship’s heading and the course made good is called the drift angle.
The set, drift and drift angle can be estimated graphically or by http://principlesofshiphandling.blogspot.in/
2/3
4/1/2016
Principles of shiphandling
mathematical calculation. This drift angle is applied opposite to the set of the current in order that the ship will progress along the intended course line. The factors affecting the drift angle depend on the load condition of the ship, the speed of the ship,the velocity of the wind or rate of the current and their direction relative to the ship’s fore and aft line. Then there is also the effect to the ship’s speed if the wind or current is ahead or astern. Other Variable factors affecting ship handling. 1. Human factor A delay in time between your given order and
the execution of the order will affect how you intend to move your ship. This is caused by human factors because the individuals you are ordering may have different responses depending on their training and ability to perform the job, or that orders have to be relayed by an officer to the helmsman, which is a bad practice that should be avoided so that the conning officer should be able to give his orders directly to the helmsman. 2. Sudden breakdown or failure of the ship’s equipment. 3. Mode of communication failure from bridge to engine room or
viceversa, or to the fore and aft stations. 4. Language problems between nationalities. 5. Ship’s Momentum.
Posted by Filgen D Yurong at 9:04 AM
No comments:
Recommend this on Google
Home Subscribe to: Posts (Atom)
Application Forms For Jobs
Customize & Print Government Forms (Free) Fast w/ GetFormsOnline Now!
Start
Convert 50+ Files On-line Free All in One Converter!
Simple template. Powered by Blogger.
http://principlesofshiphandling.blogspot.in/
3/3
