QUARTUS II INTRODUCTION USING VERILOG DESIGN

A TYPICAL FPGA CAD FLOW Design Entry Synthesis Functional Simulation No

Design correct? Yes

Fitting (Place and Route)

Timing Analysis and Simulation No

Timing requirements met? Yes

Programming and Configuration

QUARTUS II DEVELOPMENT SYSTEM  Fully-integrated Design Tool  Multiple Design Entry Methods

 Logic Synthesis  Place and Route  Simulation (functional and timing)  Timing and Power Analysis

 Device Programming and Configuration

Design Entry (1 of 2) The desired circuit is specified by:  A schematic diagram  A hardware description language, such as: Verilog VHDL  AHDL…

Design Entry (2 of 2)

Design Entry by a schematic diagram

Design Entry by a hardware description language

Synthesis 





The entered design is synthesized into a circuit that consists of the logic elements (LEs) provided in the FPGA chip. LE is the smallest unit of logic of Altera’s FPGA. It’s compact and provides advanced features with efficient logic ultilization. This course doesn’t cover the architecture of Altera’s FPGA

LE logic element

Fitting (placement and routing) 

The placement of the LEs defined in the netlist into the LEs in an actual FPGA chip, also choose routing wires in the chip to make the required connections between specific LEs

Timing Analysis 

Analyze the propagation delays along the various paths in the fitted circuit

Timing Simulation 

The fitted circuit is tested to both its functional correctness and timing

Programming and Configuration 

The design circuit is implemented in a physical FPGA chip by programming the configuration switches that configure the LEs and establish the required wiring connections

Quartus II Project Management 



What is a Project ? - A logic circuit or subcircuit - A project is: + checked for design entry errors + compiled + simulated (functional or timing) + analyzed for timing + used to generate programming file Quartus II works on one project at a time and keeps all information for that project in a single directory (folder).

Quartus II Project –New Project Select File > New Project Wizard

1

New Project Wizard help us create a new project and preliminary project settings, including the following: • Project name and directory • Name of the top-level design entity • Project files and libraries

2

• Target device family and device

• EDA tool settings You can change or add the settings of the project with the Settings command (Assignment menu)

Quartus II Project – Directory, Name, TopLevel Entity • You can choose any directory name if you prefer. If we have not yet created the directory of the project, Quartus II asking if it should create the desired directory. • The project must have a name, which is usually the same as the top-level design entity

Quartus II Project – Add Files To specify existing files should be included in the project. Click Next if we do not have any existing files. 3

Quartus II Project – Family and Device Settings To specify the type of device in which the designed circuit will be implemented. In case of DE2 board, we choose: • The target device family is Cyclone II

• The device is EP2C35F672C6 which is the FPGA used on DE2 board

Quartus II Project – EDA Tools Settings

4

To specify any thirdparty tools that should be used. EDA is means Electronic Design Automation, a commonly used term for CAD software for electronic circuits.

Quartus II - Summary

5

Design Entry using Verilog – An example

module light(x1,x2,f);

input

x1,x2;

output

f;

assign

f = (x1&~x2)|(~x1&x2);

endmodule

Design Entry using Verilog – Quartus II Text Editor (1 of 6) Select File > New to get the right figure, then choose Verilog HDL File, and click OK

3 1

2

4

Design Entry using Verilog – Quartus II Text Editor (2 of 6) Quartus II open the Text Window Editor. The default name of design file is Verilog1.v. The first step is to specify a name for the file that will be created. Select File > Save As

Design Entry using Verilog – Quartus II Text Editor (3 of 6) In the box labeled Save as type choose Verilog HDL File. In the box labeled File name , type light Put a checkmark in the box Add file to current project Click Save

Design Entry using Verilog – Quartus II Text Editor (4 of 6) Type the Verilog code of our design into Text Editor.

Save the file light.v by choose File > Save.

Design Entry using Verilog – Quartus Text Editor (5 of 6)

Design Entry using Verilog – Quartus II Text Editor (6 of 6) We can change the options of Text Editor of Quartus II by the settings in Tools > Options > Text Editor

Design Entry using Verilog – Adding Design Files If light.v is not a part of the project, this file must be added to the project. For example: if you did not use the Quartus II Text Editor, then you place a copy of the file light.v, which you created using some other text editor, into the directory introductorial. To add this file to the project, click on the light.v file and click Open

Compilation (1 of 2) Verilog code in the design file light.v is processed by the application program called the Compiler. The Compiler : - Analyze the code

1

- Synthesize the circuit - Generate an implementation of the circuit for the target chip. 2

Selecting Processing > Start Compilation

Compilation (2 of 2)

3

Simulating – Analysis & Synthesis

1

Simulating – Analysis & Synthesis

Simulating – Start EDA Nestlist Writer

2

Simulating – Start EDA Nestlist Writer

Simulating – Create VWF file

3

Simulating

Simulating – Set End Time

5

4

Simulating – Insert Node or Bus

6 7

Simulating 8

9

Simulating

10

Simulating

Uncompleted Waveform

Simulating – Editing waveform

Edit waveform

Simulating – Choose Simulator

11

12

Simulating – Run

Run Functional Simulation

Simulating – Done!

Completed Waveform
