3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 1 of 20 Cerrar SIS
Pantalla anterior Producto: GEN SET ENGINE Modelo: 3516 GEN SET ENGINE 25Z Configuración: 3516 Generator Set Engine 25Z02189-UP
Operación de Sistemas Fluid Power and Electrical Graphic Symbols Número de medio -SENR3981-04
Fecha de publicación -01/08/2008
Fecha de actualización -12/08/2008
i03480700
Fluid Power Graphic Symbols SMCS - 5050 Note: Use this module as a basic reference guide for graphic symbols. Do not use this module as a comprehensive reference guide.
Line Identification
Illustration 1 (A) Pressure line
g01387054
(B) Pilot/Load sensing pressure line (C) Drain/Return line (D) Component line (E) Attachment line (F) Air Line
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 2 of 20
Valve Envelopes
Illustration 2 (G) One position
g01345717
(H) Two-position (J) Three-position
Fluid Storage Reservoirs
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 3 (K) Vented
Page 3 of 20
g01345911
(L) Pressurized (M) Return above fluid level (N) Return below fluid level
Techniques For Crossing and ing Lines
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 4 (P) Line crossing
Page 4 of 20
g01819313
(R) Lines ing
Valve Ports
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 5 (S) Two-way
Page 5 of 20
g01353004
(T) Three-way (U) Four way
Fluid Conditioners
Illustration 6 (V) Filter or strainer
g01353011
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 7 Separators
Page 6 of 20
g01386985
(W) Manual drain (X) Automatic drain
Illustration 8 Filter separators
g01386986
(Y) Manual drain (Z) Automatic drain
Basic Component Symbols
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 9
Page 7 of 20
g01819355
(AA) Pump or motor (AB) Fluid conditioner (AC) Control valves (AD) Spring (AE) Restriction (AF) Line restriction (AG) Two-section pump
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 8 of 20
(1) Main (2) Auxiliary (AH) Adjustable spring (AJ) Line restriction (variable) (AK) Variability
Supplemental Component Symbols
Illustration 10 Energy triangles
g01819393
(AL) Hydraulic (AM) Pneumatic
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 11 Measurement
Page 9 of 20
g01819413
(AN) Pressure (AP) Temperature (AR) Pressure tap (AS) Flow
Illustration 12 (AT) Unidirectional
g01819434
(AU) Bidirectional
Pilot Control Symbols
Illustration 13 Released pressure
g01820233
(AV) External return (AW) Internal return
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 14 Remote supply pressure
Page 10 of 20
g01820235
(AX) Simplified (AY) Complete (AZ) Internal pressure supply
Manual Control Symbols
Illustration 15 (BA) Push-pull lever
g01820255
(BB) General manual (BC) Pedal (BD) Push button (BE) Spring (BF) Manual shutoff
Accumulators https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 16 (BG) Spring loaded
Page 11 of 20
g01353246
(BH) Gas charged
Combination Controls
Illustration 17 (BJ) Solenoid or manual
g01820273
(BK) Solenoid and pilot (BL) Solenoid, pilot, or manual
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 18 () Connector (Mechanical Stop)
Page 12 of 20
g01629934
Electrical Controls
Illustration 19 (BM) Solenoid
g01353280
Miscellaneous Controls
Illustration 20
g01820293
(BN) Servo
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 13 of 20
(BP) Thermal (BR) Detent
Hydraulic, Pneumatic Cylinders
Illustration 21 Single acting
g01353333
Illustration 22 Double acting
g01387001
(BS) Single end rod (BT) Double end rod
Hydraulic Pumps
Illustration 23
g01820296
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 14 of 20
Fixed displacement (BU) Unidirectional (BV) Bidirectional
Illustration 24 Variable displacement
g01820298
(BW) Unidirectional (BX) Bidirectional simplified (BY) Bidirectional complete
Hydraulic Motors
Illustration 25 Fixed displacement
g01820313
(BZ) Unidirectional (CA) Bidirectional
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 26 Variable displacement
Page 15 of 20
g01820314
(CB) Unidirectional (CC) Bidirectional
Shutoff Valves
Illustration 27 (CD) Basic symbols
g01820321
(CE) Manual shutoff valve
One-Way Check Valves
Illustration 28 (CF) Basic symbol
g01353434
(CG) Spring loaded
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 16 of 20
Internal ageways
Illustration 29 (CH) Infinite position
g01820338
(3) Flow in one direction (CJ) Two-position (4) Flow allowed in either direction (CK) Three-position (5) Parallel flow (6) Cross flow
Pressure Differential Valve
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 30 (7) Inlet (X psi)
Page 17 of 20
g01358506
(8) Outlet (Y psi)
Control Valves
Illustration 31 (CL) Normal position
g01820466
(CM) Shifted position (CN) Infinite Position
Simple Single Function Circuit
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 32 (9) 45 L/min (12 US gpm)
Page 18 of 20
g01358688
(10) 17000 kPa (2500 psi) (11) 450 kPa (65 psi)
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Illustration 33
Page 19 of 20
g01358901
(12) Three-position four-way open centered motor spool and pilot controlled directional controlled valve (13) Combination crossover relief valve and makeup valve (24000 kPa (3500 psi)) (14) Bidirectional motor (15) Main system relief valve (16) Pressure reducing pilot controlled valves (17) Check valve
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
3516 Generator Set Engine 25Z02189-UP(SEBP2955 - 38) - Estructura del documento
Page 20 of 20
(18) Gas charged accumulator (19) Main pump motor (115 L/min (30 us gpm)) (20) Pilot pump motor (19 L/min (5 us gpm)) (21) Pilot filter and by valve (22) Pilot relief valve (2250 kPa (325 psi) (23) Two positioned two-way pilot system disconnect valve (24) Tank
Copyright 1993 - 2010 Caterpillar Inc. Todos los derechos reservados. Red privada para licenciados del SIS.
Wed Jan 6 13:46:16 UTC-0400 2010
https://sis.cat.com/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/mediasear... 06/01/2010
