, or can be launched in a separate window by selecting Help > Help Contents from the menu.

2.1.1

WebConnect Studio

The first application that has been migrated into the SmartStudio application in this release is WebConnect Studio. WebConnect Studio contains most of the functions that were previously available in the Design Studio, namely the configuration of the following: 1. dashboards and controls 2. constraints 3. searches 4. search, access, population, and constraint rules 5. options and constraints on existing workflow and TLM Control tools 6. the WebConnect menu structure (see New single WebConnect menu structure on page 7 for details) Each configurable object is known as an ‘artifact’ and is displayed within the Artifacts pane. You select the type of artifact that you want to be displayed in the pane, and you can filter the list of these artifacts further by name or by type. You double-click on the artifact that you want to work with to open it in the workspace. For example:

6

TLM Reconciliations 2.7 SP1 Release Notes

(The menu structure is a single item and is excluded from list in the Artifacts pane. It is accessed using a separate button.) If a is currently working with a particular artifact, that artifact is locked, and a message is displayed by the artifact showing which has locked it. The information displayed on the desktop differs depending on the type of artifact that you are configuring. The image above shows the Configuration page for a grid. There is also a Design page, where you can reposition and resize the grid and the dashboard on which it is placed, as well as a Preview page, which allows you to see what the grid dashboard will look like in WebConnect. You can create new dashboards, controls, constraints, searches, and search, access, population, and constraint rules, and when clicking the New button or selecting File > New from the menu, a wizard is launched that takes you through the initial stages of the artifact creation. The Configuration page for that artifact is then opened in the workspace for you to complete the configuration. See the new WebConnect Studio Guide for full details of how to use the WebConnect Studio to create and configure the various artifacts.

2.1.2

Design Studio functions not migrated to WebConnect Studio

There is a small number of functions that have not been migrated from Design Studio to WebConnect Studio. These are as follows: 1. creation and maintenance – a new custom control has been created that can be accessed from WebConnect. See Dashboard availability controlled by roles on page 8 for details of this function. This function also remains in the Design Studio client. 2. Role creation and maintenance – this function remains in the Design Studio client. 3. System settings, including screen legends and system messages - these functions remain in the Design Studio client, and are also available in the Recon client. 4. Form views – these are no longer ed. If you previously used form views, when you version 2.7, the default view will be used as the default layout, and all other form views will be disregarded.


2.1.3

7

Matching Studio

The Matching Studio, a new component of SmartStudio, is currently in Beta and is primarily focused at Customers who have licensed non-item matching. If you have requirements for a matching service that allows tables other than Item to be matched then please your local SmartStream Sales representative to obtain details of this new set of capabilities. As well as non-item matching, the roap for Matching Studio is for it to completely replace Recon for item based matching configuration. Customers who use Recon are invited to preview Matching Studio and provide to SmartStream Product Management. Details of how to configure these artifacts are provided in the Matching Studio Plugin appendix in the Business Processing Guide. Please undertake this preview in non-production environments as this Studio is not yet Production ready.

2.2

New single WebConnect menu structure

The WebConnect menu is now a single menu structure for the whole deployment, which is created using a new Menu Structure configuration function in WebConnect Studio. This new function also introduces the ability to configure cascading menus, that is, you can create submenus at the top level, and then submenus within submenus. Submenus at any level can contain one or more dashboards. The following image shows an example of a Menu Structure at configuration time. The folder icons represent submenus (Cash, Securities, Input, Scratch pads), the dashboard icons represent dashboards that you have configured, and the special command icons represent the ‘reserved’ dashboards and special commands:

The following image shows an example of the above Menu Structure at runtime:

8


The full list of special commands is as follows: • • • • • • • • •

Trial Balance Currency Value Adjusted Balances Overdraft Interest Analysis Asset Position Proofing Generic Manual Input Help Contents About Change

If a dashboard has not been added to the menu structure it will not be available to any s, unless it is a child of a parent dashboard that has been added to the menu. See the new WebConnect Studio Guide for full details of how to configure the menu structure.

2.2.1

Dashboard availability controlled by roles

Because there is now a single menu structure for the whole deployment, access to each dashboard and special command on the menu is controlled by asg one or more roles to each dashboard and special command. If a has not been assigned to any of the roles specified for a dashboard or special command, that dashboard or special command is not visible to that . If a dashboard or special command that is present on the menu has no roles assigned to it, it is not visible to any s.

2.3

Maintenance in WebConnect

You can now access the maintenance functions directly through WebConnect. This means that you no longer have to launch Design Studio to configure and update new WebConnect s. The following maintenance functions are now available from the Maintenance option on the WebConnect main menu: • • • • • • •

Adding and deleting s (only WebConnect-only s) Modifying details Changing s’ Access and Limits Changing s’ Lead Authority Changing s’ s Asg licensed messages Asg s to roles

When you select the Maintenance option, a filter field is displayed. For example:


9

You can enter some filter criteria, or leave the fields blank to return all s. On submission of the filter, all the s that satisfy the filter are presented to the in a grid view. For example:

To access the maintenance functions for a , right-click on the that you want to change, or to create a new right-click anywhere n the grid. The maintenance functions are displayed on a context menu. For example:

10


The windows that are displayed for each function are similar to the existing windows for these functions in Design Studio and Recon ,. You modify (or view) any existing by selecting View. A window similar to the Insert window is displayed, and you can modify all data except the ID, Creation Date and Type. You can create new WebConnect-only s by selecting the Insert option, and completing the fields on the Insert window. You can delete only WebConnect-only s, and only if the is not logged in and is not a lead of other s. You can modify the only for WebConnect-only s. You cannot modify your own from this window, as this is done from the separate Change function on the WebConnect main menu. You can change the lead authority, import the lead ’s shortcuts, change the access and limits, and assign or unassign licensed message for any . Note: The WebConnect Maintenance function requires that TLM Control is installed on your system, and is therefore not available by default. To enable this function you must import the dashboard package into your database and import the TLM configuration file into TLM Control. See the istration Guide for details of how to do this.

2.4

Role Maintenance in WebConnect

You can now access the role maintenance functions directly through WebConnect. This means that you no longer have to launch Design Studio to configure and update roles for WebConnect s. When the and role maintenance functions are installed, the new role maintenance functions are then available from the Role Maintenance option on the WebConnect main menu. You can use them to perform the following tasks: •

View the list of roles in the system and their details

•

Create and configure new roles

•

Delete roles

•

Modify roles – including Update universe access, change associated tools

When you select the role maintenance dashboard, a filter is displayed. For example:


11

You can enter search criteria, or leave the rows blank to return all roles. On submission of the filter, all the rows that satisfy the filter are displayed on a grid dashboard. For example:

To access the maintenance functions for a role, right-click on the role that you want to change, or to create a new role right-click anywhere in the grid. The role maintenance functions are displayed on a context menu. For example:

The windows that are displayed for each function are similar to the existing windows for these functions in Design Studio. For example:

12


Note: The WebConnect Role Maintenance function requires that TLM Control is installed on your system, and is therefore not available by default. To enable this function you must import the dashboard package into your database and import the TLM configuration file into TLM Control. See the istration Guide for details of how to do this.

2.5

New Configuration Transfer utility

Configuration Transfer (CT) is the next generation of the Configuration Import utility (CI). The CT GUI has been developed using the Eclipse R framework, and is also supplied with a command line utility from which you can export and import configuration data. CT offers the same functions as CI, with the addition of the following new functions and enhancements: •

Performance is much improved over CI, particularly in of speed and memory usage.

•

With CT you can create reusable templates that are used to define the artifacts that will be added to the export file.

•

You can export all of the configuration data from a database.

•

From the GUI, you can create a backup of all of the configuration data that is associated with your active menus or shortcut groups.

•

From the GUI, you can clear all of the configuration data from your database. (Note that s and Roles are not cleared.)

As with CI, Configuration Transfer is independent of the TLM version against which it is being run.

2.5.1

Deprecated features

There are a couple of features that were available in CI that are not available in CT, namely: •

You cannot edit packages that you have exported. However, if you used a template file to create the export package you can edit the template and run the export again to create a new package.

TLM Reconciliations 2.7 SP1 Release Notes •

2.6

The Read-only import option is no longer available, which means that if you import the same artifact into a database again, that artifact will be overwritten.

New Dynamic Compare custom control

A new custom control is supplied with this release that enables you to compare multiple data records, for example for a manual match. To enable the Dynamic Compare control you must create a dashboard containing the custom control with the URL "/secure/dynamicCompare.do", and configure that dashboard as a child of a grid dashboard. To launch the Dynamic Compare control you must select at least 2 rows in the parent grid and then select it from the list of child dashboards. The Dynamic Compare control then displays a grid that compares the data values in a record side by side. For example:

Notes on the displayed data: 1. The following icons are used to indicate the state of each comparison test:

2. 3. 4. 5.

- the values are the same. - the values are not the same - the values were not compared (because property 212 was present on the attribute). The rows for which the comparison has failed are displayed in bold/italic. Totals are shown in the rows that have attributes with property 65 set. The business logic tools are borrowed from the parent grid. Use the record selectors to invoke business logic tools. Any constraints on the business logic tools are considered. The selected records are submitted for processing as a single group.

13

14


2.6.1

SmartSchema Properties used

The following properties are used by the Dynamic Compare control to populate the Compare and Totals columns: Property ID

Level

Description

5

Object

Determines whether the attributes for that object are added or subtracted while calculating totals.

65

Attribute

If present, a net total is calculated for the attribute.

212

Attribute

If present, the attribute is not compared, however it is still displayed on the control.

2.7 Configurable Custom Date Formats You can now define system-wide custom formats for date values in WebConnect, using a new SYST setting called DATE_FORMAT. You can configure different formats for different locales. If a custom format is defined for a ’s locale, that custom format is used for that ’s session. If there is no custom format defined for a ’s locale, WebConnect defaults to use the standard Java "SHORT" format, as before. To enable the custom formats, the syst_value of DATE_FORMAT must be set to 1, and the date format must be defined in the SYST_STRING as follows: =

For example: en_GB=dd-MMM-yyyy

Multiple date formats can be specified and separated with a comma. For example: en_GB=dd-MMM-yyyy,en_US=MMM-dd-yy

Only the date part of the format is configurable; there is no for configuration of the time of day format.

2.8 New Expandable Attribute Custom Control To complement the existing mechanism for viewing the message of an expandable attribute, a new custom control has been introduced. This enables a to view the message in a standard dashboard. To configure the custom control, create a dashboard containing the expandable attribute custom control with the URL “/secure/showexpandableattribute.do”, and configure that dashboard as a child of a grid dashboard. The grid should contain at least one expandable attribute within its view. If there is no expandable attribute or there is no message and the custom control dashboard is launched, it will be blank. If there is more than one expandable attribute in the view only the first will be displayed. The following image shows the Expandable Attribute custom control dashboard:


15

The ‘Inbound Message Display’ expandable attribute column in the parent grid could be hidden in the view, and it would still populate the Expandable Attribute dashboard. The existing mechanism for viewing expandable attributes, by clicking on the icon, is still available:

2.9

Viewing a list of currently open dashboards

You can now press F12 to display a list of any dashboards that are currently open in WebConnect. For example:

A tick is displayed next to the currently displayed dashboard, and you can click on another dashboard in the list to bring that dashboard to the front. The list includes any dashboards that are open in a different worksheet, in which case the list is separated by a horizontal line, as shown above.

16


2.10 Grid enhancements The following sections describe enhancements that have been made to grid controls.

2.10.1 Enhanced filtering For columns that contain less than 20 distinct values, the filter field now lists the values that you can filter by, for example:

(This drop-down filter was previously only available when filtering by image decode). For column that contain more than 20 distinct values, a standard edit box is displayed instead of a drop-down filter.

2.10.2 Switching to edit mode You can now single-click on any editable cell to switch it into edit mode (upon which the cell is highlighted in a different colour) and enter the required data into the cell, overwriting the original cell contents without having to press (as was required in previous versions). If you want to edit the original value without overwriting it, you can still do so by single-clicking on the active cell to highlight the original contents, and then using the mouse to position the cursor where you want to edit the text, or to select and drag a portion of the text within the cell. You can also use a number of keyboard shortcuts to navigate the grid whilst editing, including , <Enter> and the arrow keys, which are described in the WebConnect Operations Guide.

2.10.3 Summary row The summary row now provides a more complete description of the total rows presented in a grid, including the original data row count, the number of rows filtered out and the number of aggregate rows added as appropriate.

2.10.4 Fast-cut You can now select more than one row, and then use the new Fast-cut Selection and Fast-cut selection to New Group options on the context menu to fast-cut all the selected items. The fast-cut target is configured in the same way. Fast-cut options for single rows have also now been added to the context menu.


17

2.10.5 Grid Column enhancements A number of new settings have been introduced to SmartStudio to enhance the way in which grids are displayed in WebConnect.

2.10.5.1 Configurable tooltips for column headers Previously, tooltips displayed for column headers in WebConnect were always derived from the column headings. A new Tool-Tip setting is now available in the Grid View Properties pane in SmartStudio, which enables you to specify an alternative tooltip for each column in the view. Additionally, you can now leave column headings blank, which is useful when you want to reduce the width of the columns in a grid view. If you choose to do this, you can still display the column heading to the by configuring the column’s tooltip. For example:

If you do not configure a column’s tooltip in SmartStudio, the default column heading is used.

2.10.5.2 Flexible column widths The following new column width settings have been added to SmartStudio, to allow greater control over the way columns are sized, and to enable the configuration of both fixed-width and auto-fit columns in the same grid view: •

Use System Default – enables you to specify the required width of the column. If the COLUMN_WIDTH_POLICY SYST switch is off, the column width takes the value specified for each column. However, if this SYST switch is on, the width specified is ignored and is instead set to the widest data value in the column (ignoring headings).

•

Fit-to-data (ignore headings) – the width of each column is set to the widest data value in the column (ignoring headings). You can also specify minimum and maximum values for the width.

•

Fit-to-data (include headings) – the width of each column is set to the widest data value in the column (including headings). You can also specify minimum and maximum values for the width.

•

Fixed width – enables you to specify a width for the column.

2.10.6 New shortcut keys for fast-cutting grid data New keyboard shortcuts have been provided to fast-cut single items within and between dashboards. After selecting the required item, the <+> shortcut can be used to fast-cut to a group marked by the insertion point, and the <*> shortcut can be used to fast-cut to a new group.

18


2.11 Business Logic enhancements The following sections describe the improvements that have been made to business logic functions in this release.

2.11.1 Bulk editing for non-item universes Bulk editing on grid data is no longer restricted to the item universe, and can now be performed on data in any universe.

2.11.2 Business Logic Progress Updates The browser polling interval during business logic processing can now be configured by a new SYST parameter BL_UPDATE_DELAY. The value is a string comprising a semi-colon separated list of integers. Each integer represents an interval in milliseconds. The first time the browser polls it will wait for the first specified interval, then the second time it will wait for the second interval and so on. Once the end of the list is reached the last interval will be used for subsequent polling intervals. This setting enables the system to reduce the potentially large number of HTTP request/response cycles for long running business logic and consequent load on the network and HTTP server. The default value is set to '1000;1000;1000;3000;3000;3000;5000' so that very short processes will still complete in a few seconds. This string represents seven intervals of duration: 1, 1, 1, 3, 3, 3 and 5 seconds. Any subsequent polling will therefore be at intervals of 5 seconds.

2.11.3 Attaching documents to non-case universes You can now add a document attach function to a TLM Control Interaction step, which enables s to attach documents to any universe.

2.11.4 New Convert Case tool A new business logic tool, Convert Case, has been added to enable you to manually change an existing case to a different case type. For example:


19

Items belonging to the case being converted must be at or below the level of the new case type.

2.11.5 New Message Routing Tools The following new business logic tools are now supplied: •

WebConnect Message Routing Delete

•

WebConnect Message Routing Insert

•

WebConnect Message Routing Edit

This means that you can now create a Message routing dashboards. The following procedure outlines the steps required to create a message routing dashboard: 1. Using SmartSchema, ensure that the Message Routing universe is present and that the Message routing attributes each have the property Dashboards – Editable selected. 2. Using Design Studio, or WebConnect Role Maintenance, create a role for s responsible for creating or modifying Message Routing records. Ensure that the tools listed above are allocated to this rule, and that all of the attributes in the message routing universe are allocated as editable attributes. Then allocate this role to the relevant s. 3. Using SmartStudio, create a search rule at the Message Routing level, containing the following logic: Message Message Message Message Message

4. 5.

Routing Routing Routing Routing Routing

Message Feed equal to Prompt for Specific Value and From Message Feed Type equal to Prompt for Single Decode To Message Feed Type equal to Prompt for Single Decode Action equal to Prompt for Single Decode Description equal to Prompt for Specific Value

Then create a search that uses this rule. Create a Message Routing Dashboard. This should contain a grid which is configured with the following information: • Universe: Message Routing • Datasource: the search that you created in step 4. • A view that contains the appropriate attributes and objects. • Business logic tools: add WebConnect Message Routing Delete. • In the Save Options, for the Edit tool select WebConnect Message Routing Edit, and for the Insert tool select WebConnect Message Routing Insert. 6. Add the dashboard to the Menu. The dashboard that you have created should look something like the following:

20


To modify a Message Routing record in WebConnect using this grid, double-click on a cell in the grid, modify the cell contents and click on Save button. To insert a new Message Routing record, right-click anywhere on the grid and select “WebConnect Message Routing Insert”. For details of how to create dashboards, grids and searches, see the TLM WebConnect Studio Guide.

2.12 Enhanced search capabilities SmartStudio now contains the following new features to enable you to configure more flexible searches.

2.12.1 Searching across multiple item fields You can now configure search rules to search for a single input value across multiple item fields, by using the new Use Previous Prompts Value attribute in the right-hand side of your expressions. For example, if you want to search for an input value entered into an Item Reference field, within Item Reference fields 1, 2 and 3, you can do so as follows:

2.12.2 Specifying tolerances You can now specify upper and lower tolerances on float, date, datetime and integer values, that are entered in a search field. To enable tolerances on searches, a new similar to operator has been introduced. For example, in the expression configuration below, a lower tolerance of 5 days and an upper tolerance of 1 day is defined for the expression, to ensure that the amounts returned from the search are no more than 5 days earlier and 1 day later than the date input:

The upper and lower tolerances can be expressed as explicit or percentage values, unless they are for date or datetime attributes, in which case explicit values must be used. In WebConnect, a tooltip is displayed when the hovers the mouse over an input field for which a tolerance has been configured, to show the tolerance values that have been specified for the field. For example:


21

2.12.3 Child search prompt enhancement In SmartStudio, a new child dashboard setting, Don’t Suppress if no data, is now available when the Suppress Child Prompts option is selected. When enabled, this setting overrides the Suppress Child Prompts option in situations where the drill-down will not return any data. In this case, the search prompt would be displayed so that the can change the values, before running the search again. Depending on the search criteria, the resulting dashboard might now be populated or it might be empty.

2.12.4 Filter for sign functions Two new functions, Filter for sign and Filter for opposite sign, can now be applied to amount values in the righthand side of search rules in SmartStudio. These functions enable child dashboard searches, for example, triggered from net totals on aggregate rows, to use the sign of the net value to locate the missing items. That is, the items that can complete a match with a resulting net of zero. For example, you would apply Filter for opposite sign in a situation where a group of items with a net amount of -100 requires a drill-down to a grid that displays all Outstanding items, where Item Amount = 100, and Item Type is Our Cash Credit. Alternatively, in a situation where a group of items with a net amount of 200 requires a drill-down to a grid that displays all outstanding items where Item Amount =200 and Item Type is Our Cash Debit, you would apply Filter for sign to your rule.

2.13 Additional authorisation for outgoing case documents WebConnect previously provided an option to specify that outgoing case documents should be authorised before sending, that is, after creation, that document would then have to be authorised by a second . This release introduces the option to configure a second level of document authorisation. If verification is required for case documents, it is still configured in Recon using the Auth Required checkbox on the case document template. When the document creator issues the document, WebConnect first checks the ‘Auth Required’ flag on the document template. If the document requires verification, WebConnect then checks the value of the new SYST setting CASE_DOC_AUTH_LEVELS, which specifies the number of times the document must be authorised before it is sent, as follows:

22


SYST value

Description

0

creates document, no authorisation required.

1

creates document. Must be authorised once by another qualified . This is the default.

2

creates document. Must be authorised by two different qualified s.

If the Auth Required flag is not set, or the Auth Required flag is set but the SYST value is 0, the document is queued to be sent. If the SYST value is greater than 0, the document is set to awaiting authorisation. The document then gets queued for authorisation. Authorisation can be performed only by s with permissions to authorise case documents, using case dashboards. Each document authorisation must be performed by a person who has neither created nor already authorised the document. When 2 levels of authorisation are specified, if a document has been authorised once but requires another authorisation, it is marked as partially authorised in the case history, and remains on the queue for a second authorisation. When the document has been authorised the required number of times, it is queued to be sent.

2.14 Server enhancements 2.14.1 Cash net items released to history The Workflow engine has been enhanced to allow net items to progress through the productised Cash release logic. Previously they were identified by their non-zero match_no, and placed on the chosen queue as an Active queue entry. Now they are progressed through the release processing. An additional initial check has been added to the match_no check to see whether there are any interest parameters set up for the (on the Financial Parameters tab). If the Credit Potentials option is Off, and the No Debit potentials option is On, net items are released. If either of the settings requires an interest calculation, the net items are not released. When net items are released, a final net match record is created with a new match number, however, no new net item is created. Each net item involved in the match goes to history, but retains its original match_no and sec_match_no rather than linking directly to the new match record. Any amount discrepancy remaining on the match is accumulated onto the charge amount that is held on BANK, as for standard cash matches.

2.14.2 Start time of the current job used in scope rules A new ‘Job Start Time’ reserved attribute has been added to the TLM schema to allow a match job to pick up data based on the time that the current job started. This attribute is only available to scope rules, and is interpreted by the workflow engine as the time the current workflow queue job was started.

2.14.3 Parallel processing of duplicate jobs prevented Previously, if the workflow server was already processing a job with a non-zero lock_flg, an identical job with a lock_flg of 0, which means that any server engine can process it, could be placed on the workflow queue for processing, which means that duplicate jobs could be processed in parallel. This has now been modified so that the new job is not inserted with lock_flg of 0, but with a ‘waiting’ lock_flg of 500+N, where N is the workflow server instance that is processing the first job. This means that only the specified server instance can process it, and it will only do so once it has finished its current job, therefore preventing duplicate jobs being processed in parallel. For example, say you submit a new job for an item with the following information: • •

Corr_acc_no = 100000088 list_id = 10075

TLM Reconciliations 2.7 SP1 Release Notes • • •

23

Event_date= 01/01/2009 Workflow_list_id = 0 Lock_flag= 0

The logic checks for any entries with the same corr_acc_no, list_id, event_date, workflow_list_id. • •

If there are no entries, the entry is inserted with lock_flag = 0 If there are entries, the logic reads the lock_flag values and does one of the following: • If there is an entry already with lock_flag = 0, nothing is inserted • If there is an entry with a waiting flag (lock_flag > 500), nothing is inserted • If there is only one entry and it has an in-progress lock_flag (for example, 102 for engine 2 processing), a new ‘waiting’ entry is inserted for the same engine instance (502).

2.14.4 Specifying a currency for a column tolerance In Recon Details, when configuring a population, a currency can now be associated with a tolerance in the Column properties. The currency is available only when an amount-type column is specified. For example:

Where a currency is specified, the tolerance is converted from the specified currency into the currency of the items being matched, using the current exchange rates. This means that, for example, a tolerance of 10 USD when applied to items in a GBP converts $10 into the equivalent value in GBP, and uses the outcome of that conversion as the tolerance amount. Where no currency is specified, the tolerance is not converted. This means that, for example, a tolerance of 10 when applied to items in a USD groups items together that are within $10 of each other, and when applied to GBP groups items within £10. A new database column has been added to the PASC table to store the currency for the column. The Configuration Import utility (CI) has been updated to enable migration this information.

2.14.5 Move the Last-Prop BANK update to the start of the workflow job processing The workflow server records the start date and time of any match run to the Bank record associated with the match job. Previously, the Bank record was updated with the start time at the end of job processing. To allow other jobs to see the time that a currently running job started, to avoid processing data loaded before that time, the bank table update is now performed when processing starts.

24


2.15 Global Stock Aliases An enhancement has been made to the asset logic to allow the use of ‘global’ security aliases alongside territory code-based aliases. Essentially, this enhancement allow aliases with blank territory-codes to be considered ‘global’ so that they can be seen by all Sets, regardless of whether they are linked to territories, while continuing to allow territory-based alias lookup for Sets linked to specific territories. If a territory code is assigned to the Set, the look-is now broken down into separate searches, each of which is only carried out if nothing is found for the preceding stage. These stages are as follows: 1. Look for matching known alias (positive stock_id) with the same territory_code 2. Look for matching known alias (positive stock_id) with blank territory_code 3. Look for matching unknown alias (negative stock_id) with matching territory_code

2.15.1 New SYST setting ALLOW_GLOBAL_ALIAS A new SYST setting, ALLOW_GLOBAL_ALIAS, has been introduced to control whether a global look-up is used, or whether the lookup is restricted to the relevant territory code. The default value of this SYST setting is 0, which means that global lookup is not used.

2.16 New SYST setting EDIT_NET_VALUE_DATE A new SYST setting, EDIT_NET_VALUE_DATE, has been introduced to enable s to specify whether the value date on net items that are created by release workflow can be edited. The default value of this new setting is 1, which means that the data value can be edited.

2.17 New SYST setting TRIAL_BAL_SET_LIMIT A new SYST setting: TRIAL_BAL_SET_LIMIT has been introduced to specify the maximum number of sets that can be included in a trial balance search. This is to prevent excessively large searches being run that would affect the application server performance. The default value for this setting is 1000. If a Trial Balance search will be calculating Trial Differences for more s that the maximum, even if some sets are subsequently filtered out, the is prompted to change the search criteria.

2.18 New value for ITEM_EDIT_REQS_NOTE SYST setting A new value of -1 has been introduced for the ITEM_EDIT_REQS_NOTE SYST setting. This SYST setting is used to control how the note field is used in conjunction with WebConnect productised item save tool. A value of -1 represents that the note is suppressed, and should therefore be used in situations where you do not want the note field to be displayed to the .


25

3 Deliverables 3.1

TLM Platform Deliverables

File Name Design Studio\setup.exe TLM Design Studio.msi SmartStudio 2.8#P10.exe SmartStudio 2.8#P10.msi Control\ tc_setup.zip install_smartdata smartdataservices2_7_1_35.tar TLM SmartDataServer 2.7 SP1.exe WebConnect.war Utilities Configuration Transfer Customer Branding Security SmartSchema

3.2

Version 2.7.0.45 2.7.0.45 2.8.0.140 2.8.0.140 1.2.1.20-1 2.7.1.35 2.7.1.35 2.7.1.35 2.7.1.P06 1.0.0.35 1.0.22.0 2.4.0.13 4.1.1195.0

TLM Recon Deliverables

File Name Recon \setup.exe TLM Recon .msi install_recon TLM Recon Server 2.7 SP1.exe recon2_7_1_44.tar Utilities AAS Client

3.3

Version 2.7.0.148 2.7.0.148 2.7.1.44 2.7.1.44 2.7.1.44 3.3.0.286

New Documentation

Description This Software Release Note WebConnect Studio Guide

File Name TLM Recs 2.7 SP1.pdf

Notes

WebC27WCSG.pdf

istration Guide Configuration Transfer Guide

SmartData27Usr.pdf

Contains information on how to create dashboards, constraints, rules, and so on, which are now configured using the new SmartStudio application. Contains and Role maintenance information and access and limits.

CT 1.0 Guide.pdf

Contains instructions for the use of Configuration Transfer (CT), which is the next generation of the Configuration Import utility (CI).

4 Level of Testing All issues that are listed in the section Issues Resolved in This Release have been tested. All new features have been tested, and system-wide regression tests have also been performed.

5 Installation If you require any assistance with the installation of this software, your Manager or regional Desk to arrange for a Professional Services engagement.

26


6 Open Source Code used The following table lists the open source code used in this product: Antlr

Ehcache

JFreeChart

AOP Alliance

Emma

Joda-time

Apache Commons

gen-java

JSON

Apache Derby

GWT

JSON-RPC

Apache Jakarta

ICU

JSON-RPC-Java

Apache log4j

Jakarta Commons

JUnit

Apache POI

Jakarta Log4j

Libcurl

Apache Struts

Jakarta Oro

Log4j

Apache Xerces

Jakarta Regexp

Quartz

ASM

Jakarta Struts

Saxpath

BIRT

Janino

SigTest

Blowfish

Java Beans Activation Framework

Simple-JNDI

Castor

Java Universal Network/Graph Framework

Spring

cglib Code Generation Library

JavaMail

util.concurrent

Clickstream

Javassist

Xalan-Java

colt

Jaxme 2

Xerces

dom4j

JCommon

Xml Pull Parser 3rd Edition (XPP3)

drools

JDOM

xmlenc

Eclipse Rich Client Platform (including Nebula)

JDOM Jaxen

xstream


27

7 Issues Resolved in This Release This section lists the issues that have been raised by customers that have been fixed in this release. Issues found internally by QA that have also been fixed are not included in this list. The Likely Impact field in the tables below denotes the nature if the change, and the amount of testing that is recommended post implementation, as follows: •

Low - Minor change limited to a single component. Only minimal, targeted testing required.

•

Medium - Relatively major change affecting a single component, or minor change affecting multiple components. Basic test of affected components recommended.

•

High - A wide ranging change which has system-wide effects or involves the major refactoring of a key piece of functionality. Full system-wide functional test recommended.

7.1

WebConnect

Issue No WBC-788

Description WebConnect Trial Balances does not allow a to search with 'Set Group' as the sole search parameter

Priority P3

Problem Reported Currently WebConnect - Trial Balances does not allow a to search with 'Set Group' as the sole search parameter. It requires at least one of Set ID, Category, Currency, Security Code, Message Feed or Set Type to be populated. This is a validation restriction in the code. WebConnect should be modified to allow the 'Set Group' search field to be used as the sole search criteria. The validation message should also be updated. Component Likely Impact Incident No Affected 62651 Problem Solution Details Set Group can now be selected without selecting any other criteria.

Issue No Description WBC-854 Casing issues Problem Reported It is not possible to carry out a range of casing tasks. Component Likely Impact Affected

Priority P2

Incident No 59132

Problem Solution Details Issues fixed.

28


Issue No WBC-1416

Description The unlink business logic tool does not remove a missing balance that was added when linking securites

Priority P3

Problem Reported The missing balance value on a message feed was not updated correctly on an unlink operation. When two security transactions items in Webconnect were matched and linked, a missing balance was correctly created on the asset header (this could be seen in Trial Balance). When the items were recalled and unlinked the missing balance should have been removed but wasn't. Component Likely Impact Incident No Affected GUI Low 61775 Problem Solution Details The balance processing code has been modified with a new formula to calculate the new missing balance when items are unlinked. The missing balance should now be set correctly after an unlink operation.

Issue No WBC-1512

Description Grid returns to start after executing tool on two rows at the end

Priority P3

Problem Reported When selecting the last two rows on a grid and executing test_constraint, the grid returns to the start when you'd expect it to stay at the end. Component Likely Impact Incident No Affected GUI Problem Solution Details Tested and working as expected.

Issue No Description Priority WBC-1563 Auto populate Feed Id based on Set ID P3 Problem Reported Auto-population of the Feed ID - if the Set ID has been input and there is only 1 ledger or statement, the Feed ID should automatically populate. Where there are multiple Feed ID's the Feed ID would be input manually. This is a feature of SSR that is required in TLM Component Likely Impact Incident No Affected GMI Problem Solution Details Feed ID is auto-populated based on Set ID.

62165


29

Issue No Description Priority WBC-1564 Set ID should be validated upfront P3 Problem Reported Set ID is not validated when input. This is one of the last checks that take place, but it should be the first. Any mandatory fields that are not populated are flagged as an issue first. Component Likely Impact Incident No Affected GMI

62165

Problem Solution Details Implemented custom selector for Header Set Id field. On click of the selector, a popup will display the header set id and the feed Id for the corresponding message type. On selection of the required row in the selector popup, the values will be populated in the GMI screen for the corresponding fields. Also, if there is a currency field in the message header and the has entered any data in the currency field, then the header currency field will be populated from the default currency of the Header Set Id.

Issue No Description Priority WBC-1565 GMI is slow on input of many item rows P3 Problem Reported Poor response times when manually inputting items. As more items are input, WebConnect gets slower. This is particularly noticeable when entering a source code, as TLM tries to create a new line at the same time. Component Likely Impact Incident No Affected GMI

62165

Problem Solution Details Changed DropDownMenu for IE 6. Don't Display the new empty row in the item section. can use navigation keys to reach the new row.

Issue No Description Priority WBC-1567 Amount fields should have comma as thousand separator P3 Problem Reported In the Item Amount field, commas should separate the thousands. This works for the credit, debit and net balance, so this is inconsistent. Component Likely Impact Incident No Affected GMI Medium 62165 Problem Solution Details Handled the addition of a thousand separator character for decimal numbers.

30


Issue No Description Priority WBC-1665 Business logic not correctly netting (signs inverted) P2 Problem Reported The amount netted on screen is opposite to the amount netted in the execution of the business logic. Component Likely Impact Incident No Affected Low

62025

Problem Solution Details Sign determined to be incorrect for this schema arrangement. Mirroring lead to sign being inverted irrespective of side and that schema action was not factored in. This issue has been resolved.

Issue No Description Priority WBC-1671 Header Set ID should not be validated from the cache. P3 Problem Reported There is an issue with caching of static data in WebConnect/JBoss where WebConnect displays a validation failure message when validating Set ID and Message Feed. Validation only works when JBoss is restarted. It appears that only the first newly created Set & Message Feed is recognised following the start-up of JBoss. Component Likely Impact Incident No Affected GMI Low 62325 Problem Solution Details The Header Set ID is no longer validated from the cache and the App Server need not be restarted for the new s to be effective.

Issue No WBC-1736

Description Text of the previous note that the added remains in the text prompt

Priority P3

Problem Reported When a adds a note to an item, the text of any previous notes that the added remains in the text prompt. This is considered to be an audit risk. Component Likely Impact Incident No Affected GUI Problem Solution Details The persistence of note messages between note submissions is now a configurable option.

62519


Issue No WBC-1804

Description Delete functionality does not delete the row from ASSET_BALANCE table.

31

Priority P3

Problem Reported The delete functionality for message backout works but causes the Gems server shut down when the data is deleted or reloaded, and as such, the Asset_Balance table must be deleted and the data reloaded from the back end. Component Likely Impact Incident No Affected GUI

61912

Problem Solution Details Tested and working as expected.

Issue No Description WBC-1849 GMI should allow messages with no items Problem Reported GMI should allow messages with no items. Component Likely Impact Affected GMI Low Problem Solution Details Removed the mandatory check for item in the server and UI code.

Priority P3

Issue No

Priority

WBC-1888

Description swin.b_last_used should be read from KeyCacheImpl instead of reading directly from database.

Incident No 62693

P2

Problem Reported swin.b_last_used should be read from KeyCacheImpl instead of reading directly from database Component Likely Impact Incident No Affected GMI Medium 62604 Problem Solution Details WebConnect now caches a chunk of message_nos and provide it to GMI for message_no from this chunk. This will avoid the GEMS server from reading the same message_no.

32


Issue No Description Priority WBC-1895 Add 'Select' and 'Fast-cut' options to context menu. P2 Problem Reported Add ‘Select’ and ‘fast-cut’ options to the context menu so that the can still access these options when they scroll across the screen, without having to scroll back to the left hand side. Component Likely Impact Incident No Affected GUI Low 62888 Problem Solution Details The options Select Row, Select Group, Select Break Group, Select Aggregate Group, Deselect, Fast-cut and Fast-cut to New Group have been added to the context menu. The presence of these options is dependent on the Grid configuration (Show Row Selector, Show Group Selector and Suppress Cut and Paste), and the View configuration (Show Aggregate Group Selector, presence of aggregate-on-change, etc.). The availability of options in the menu is dependent on the status of the highlighted (active) row.

Issue No WBC-1909

Description Allow editing of boolean flags in casing desktop through item maintain.

Priority P3

Problem Reported A bug on the case edit event where a blank field is displayed when editing the “Close When History" field. Component Likely Impact Incident No Affected GUI

62955

Problem Solution Details Occurred when a string decode has been setup on the boolean (integer) fields, when saving it would try to put the string value into the integer field. Now coded to find the encoded value and this is the value that will be saved rather than the string decode.

Issue No Description Priority WBC-1916 Inefficiency in application of edit event filters. P1 Problem Reported Inside the WebConnect work flow engine the code that applies source and target filters to selected items for edit events is inefficient. Component Likely Impact Incident No Affected 62355 Problem Solution Details Modified the edit event filter logic to retrieve rule data in one go (or split based on parameters) when building context for the application of filters.


33

Issue No Description Priority WBC-1938 Rounding issue in netting field in GMI P3 Problem Reported There is a rounding issue in the netting field in GMI. The Net Balance field in GMI shows 6 decimal places and when there are large balances keyed in, the net balance will sometimes show 0.000001, which suggests to the that the page does not balance and can be misleading. This is a display issue with the WebConnect GMI screen and does not prevent the page from loading or cause the page to go to Message Maintenance. Component Likely Impact Incident No Affected GMI Low 62929 Problem Solution Details Issue has been fixed. The value of balanceType is now ed to the interface. In the UI(js) code, it is decided whether the decimal will be 3 or 6 places.

Issue No Description Priority WBC-1940 Fast cut into empty scratchpad fails P3 Problem Reported After a successful release from the Scratch Pad, any further items that are "cut" from Item Search are removed from Item Search (correctly) but do not go in to the Scratch Pad. Selecting Scratch Pad as the Fast-Cut target does not rectify this. Component Likely Impact Incident No Affected 62766 Problem Solution Details Fixed fast cut into empty scratchpad (when scratchpad has previously had rows in it that have been removed)

Issue No Description Priority WBC-1947 U slow for dashboard refresh P2 Problem Reported Following execution of a workflow tool (that is configured to update rows on screen) the JavaScript that performs the update in the browser can sometimes take a long time to execute. The time taken to update the grid can be significantly longer than the time taken to open it in the first place. Component Likely Impact Incident No Affected Low Problem Solution Details Improved performance of code to update grid rows following tool execution.

63043

34


Issue No WBC-1970

Description GMI: Currency is not required as the currency is already populated in the Set ID

Priority P3

Problem Reported Issue: GMI- Manual input form forces to type in currency - this is not compulsory in SSR and is not required to be compulsory in TLM. Currency is not required as the currency is already populated in the Set ID Component Likely Impact Incident No Affected GMI Low 63160 Problem Solution Details On selection of the chooser option for the Set ID, if the has not input the header currency field, then the header currency field will be populated from the default currency of the Header Set Id.

Issue No WBC-1997

Description Priority Primary Key fields not correctly ordered for Case Transaction P2 Universe Key

Problem Reported When executing the TLM Control process from WebConnect, TLM Control is rejecting the message because the key fields are in a different order in the constructed message compared with the SmartMessage definition. Component Likely Impact Incident No Affected Control Interface

63435

Problem Solution Details Corrected order of primary keys in CaseTransactionKey.

Issue No Description Priority WBC-1999 Base currency conversion performance issue P3 Problem Reported Our Item Search Enquiry dashboard is performing extremely slowly (14 minutes to return 5000 items). It is displaying the below Target Currency attribute. Component Likely Impact Incident No Affected GUI

63152

Problem Solution Details Now only reloads exchange rates once for each grid (rather than for each row in the grid).

Issue No Description Priority WBC-2008 Default category selection when only one category is available P2 Problem Reported Default category selection is required on launch of GMI when a logged-in has only one message category available. Component Likely Impact Incident No Affected GMI

63166

Problem Solution Details When only one message category is available, on launch of GMI it will select this category by default and populate the GMI screen for corresponding first message type.


Issue No WBC-2009

Description Disabling the display of an interaction dialogue for non-zero amount differences when configured for no warnings

35

Priority P2

Problem Reported WebConnect has always displayed the release interaction dialogue for non-zero amount differences. The warning limits options in Recon will control the display of a "threshold exceeded" discrepancy but not the "amount difference" discrepancy. This is different to the behaviour of the TLM GUI and will be changed accordingly. Component Likely Impact Incident No Affected GUI

62914

Problem Solution Details An interaction dialog is displayed for released items with a zero amount difference when other discrepancies have been identified.

Issue No WBC-2031

Description Receiving an error saying Item Amount not complete for the Ledger Credit grid on Load & Continue.

Priority P3

Problem Reported In GMI, an 'Our Cash Settlements' input was completed, and an error was received after clicking the 'Load and Continue' button, stating that the item amount was not complete for the ledger credit grid on load and continue. Component Likely Impact Incident No Affected GMI

64567

Problem Solution Details The suppressed onchange event for mandatory numeric field is invoked after formatted value is set to the field.

Issue No WBC-2033

Description Priority Enhance the WebConnect Message Maintenance dashboard to show if the page balances, and the Net Input / Remaining P3 Totals, and a total of debit/credit entries.

Problem Reported A Message Maintenance dashboard has been built but the functionality is different to that of SSR.A view that displays the following is requested: The validation of the total of items on a rejected statement/ ledger page, the opening and closing balance, the net input, and the remaining totals. A total of debit and credit entries without the need for manual calculation using filters. Component Likely Impact Incident No Affected GUI Problem Solution Details The required functionality was implemented for GMM-GMI.

63574

36


Issue No WBC-2140

Description Workflow rule is not setting reserved attribute values for processing

Priority P2

Problem Reported Workflow in WebConnect isn't validating dates correctly, for example, when comparing Entry date with System date.. Component Likely Impact Incident No Affected GUI

63508

Problem Solution Details WebConnect was not correctly setting the value for the reserved attribute. This has now been resolved.

Issue No WBC-2336

Description OutOfMemoryException thrown opening message maintenance dashboard

Problem Reported It is likely that the WebLogic server is running out of memory. Component Likely Impact Affected GUI

Priority P2

Incident No 100231

Problem Solution Details Reverted to using a text edit when editing setId (form & bulk edit). Added validation when changing setId in forms, bulk edit and editing directly in the new grid.

Issue No WBC-2390

Description UPD_CASE_ITEMS_SUMM flag for accept/reject amount and reference

Priority P4

Problem Reported Regardless of whether the syst_value is set to 0,1, or 2, s are still prompted to accept or reject amount and reference, which is not expected behaviour. Component Likely Impact Incident No Affected GUI

100628

Problem Solution Details Respect the UPD_CASE_ITEMS_SUMM SYST setting as described.

Issue No WBC-2414

Description Check for Bank lead currency does not spot empty lead currency

Problem Reported Position items cannot be matched in thin client. Matching in thick client works OK. Component Likely Impact Affected GUI Problem Solution Details Ensure a blank lead currency is handled correctly.

Priority P2

Incident No 100836


37

Issue No Description Priority WBC-2434 Unable to attach documents to Cases P2 Problem Reported The is unable to attach documents to Cases. as "attach" ( "attach") "attach" has access through WebConnect to "Case Summary (Web)" A blank search on this returns a number of Cases. When an unresolved case is selected from the list the option to attach a document becomes enabled and when selected opens a new window. The is allowed to browse to a file and then needs to add a note before selecting OK. The should receive a report to state that the document has been successfully attached however, an error is reported: "There was a problem attaching the specified document, please your system ." The WebConnect.log states "Error while Attaching Document" and "Received Null Lob Id from Cache" (Attached) NB The environment should be noted as this is working on hora08... this is using Linux, JBOSS 4.2 with unicode switched on. Component Likely Impact Incident No Affected Medium 103242 Problem Solution Details This occurred only on JBoss running 2.6 onwards, it was caused by WBC-1399. Have modified the database write so the error doesn't occur. Issue No Description Priority WBC-2436 Trial Balance fails for large number of sets P3 Problem Reported An error in the log seems to be caused by a bug whereby, when the currency or asset feed search returns in excess of 1000 sets, the item table search fails because the Oracle driver cannot handle more than 1000 predicates in the SQL and this is not handled correctly. Additionally, when the logs are showing OutOfMemoryError this means the amount of data loaded is too much for the memory allocated to the application server. You can increase the heap size for the application server but a search of this size is always going to be very slow. Component Likely Impact Incident No Affected GUI Low 100848 Problem Solution Details The Trial Balance search was failing for some very large searches. Specifically, if the number of distinct sets in the search was in excess of 1000, the search would fail with an error. The search query has been fixed so that the Trial Balance can load this quantity of data. Note, however, that searches are this size are very slow and will require significant memory resources from the application server.

Issue No WBC-2509

Description Ensure fast-cut operation moves active row, so that grid doesn't scroll back to previous active row

Priority P2

Problem Reported Currently, if you fast-cut the active row on a grid it moves the active row to the next row in the grid. However, if you fast cut a row other than the active row it scrolls the grid back to that active row after the fast-cut. The fast-cut operation should effectively make the chosen row active before the cut is done and then let the logic move the active row to the next row, just as if the had clicked on the row before fast-cutting. Component Likely Impact Incident No Affected 101269 Problem Solution Details In the case of a fast cut, the active row is now set explicitly to be the row corresponding to the fast cut button clicked on.

38


Issue No WBC-2515

Description Provide a means of viewing the charge amount on a productised (released) cash match in the audit trail

Priority P2

Problem Reported Currently, there is no way of directly viewing the amount difference on a released match. The audit trail shows if a net item was produced and also displays an entry for any interest amount raised. However, it doesn't directly show any charge-amount raised if no net item was created. We should consider creating an extra display node in the audit display, under a released match entry, that can spot when a charge amount has been created from the match (non-zero charge_amt on TRNS) and display that amount with the associated currency, in the audit alongside any interest node. Component Likely Impact Incident No Affected GUI

100990

Problem Solution Details Display charge amount in audit trail (node appears labelled 'Amount Difference' if applicable).

Issue No Description Priority WBC-2554 Add Notes Custom Control is failing due to code merge issue P2 Problem Reported The Add Notes Function is not working in 2.6Sp1. This is due to a merge issue when the CCD Maintenance code was checked in 2.6Sp1. The root cause of this issue is present in CustomSubmitAction.java. Component Likely Impact Incident No Affected CCD

101454

Problem Solution Details Place the code snippet in the place it was before, and remove it from individual places except for group submission. At the end of code specific to group submission ensure that gridRow is null so that common code is not executed for group submission.

Issue No Description Priority WBC-2581 Confirmation Limits not being used correctly for net items P2 Problem Reported When a Logs into TLM 2.6 WebConnect as a non- and releases two items, amounts of which exceed the ’s limit set in Recon , the has to enter their Supervisor id/. The credit Netting Limit (of the Supervisor) being read in such a case is not in accordance with the setting in Recon and thus is an issue and needs to be corrected. Essentially, if a release requires confirmation and it is selected for netting, the confirmation limits then used are the charge confirmation limits rather than the net confirmation limits. A proper check of the netting option needs to be made to determine which set of limits to use. Component Likely Impact Incident No Affected 101428 Problem Solution Details The release of cash items is now handled correctly in cases where the confirmation of a supervisor's net limits is required.


Issue No WBC-2609

39

Description Priority Edited rows disappear after refresh if they no longer meet the P2 search criteria

Problem Reported It should be possible to see rows that have been edited after a refresh even if the changes made would cause the row to no longer be returned. Component Likely Impact Incident No Affected 101888 Problem Solution Details Rows that have been edited now remain visible after a refresh even if the changes made would cause the row to no longer be returned.

Issue No WBC-2621

Description Enable selectors in the bulk edit dialog that take precedence over dropdowns in forms.

Priority P2

Problem Reported Enable selectors in the bulk edit dialog that take precedence over dropdowns in forms, so that an attribute which has a dropdown can be overridden with a selector definition. This needs to include validation if the field is a text box, to prevent incorrect source codes from being entered into the system. Component Likely Impact Incident No Affected 101887 Problem Solution Details Enabled selectors in the bulk edit dialog that take precedence over dropdowns in forms.

Issue No Description WBC-2622 Allow fast-cut of multiple items. Problem Reported Need the functionality required to fast-cut multiple items. Component Likely Impact Affected

Priority P2

Incident No 101614

Problem Solution Details It is now possible to fast cut a selection of rows in a single operation.

Issue No Description Priority WBC-2623 Allow date entry without separators e.g. 101208 for 10/12/2008 P2 Problem Reported Allow date entry without separators e.g. 101208 for 10/12/2008 Component Likely Impact Incident No Affected 101881 Problem Solution Details s can now enter dates with or without separators e.g. 101208 or 10/12/2008 are equivalent.

40


Issue No WBC-2624

Description Don't show ellipses (...) in grid data where column width is configured to be "very narrow".

Priority P2

Problem Reported Dashboard grids need the ability to only display a single character regardless of the length of the field. Currently columns display (...) when the data is continued. By design, some of our dashboards only display the first character of a field (O for Outstanding, H for History, etc.) Component Likely Impact Incident No Affected 101886 Problem Solution Details Grid cells that are too narrow to display their contents in full will not show ellipsis (...) if that would result in the content not being displayed.

Issue No Description Priority WBC-2643 Audit Trail fails to display for some NET items P2 Problem Reported When opening the audit trail for certain NET items, a SQL Exception in thrown which is likely due to a bug in: AuditTrailOtherDAO.populateChargeAmountDetails(). The code is attempting to load a column called: system_currency. This column is only present in the results some of the time (because different SQL queries use this code). This column name should be removed entirely and replaced with a call to the SystemParameterService to load the syst parameter for system currency. Component Likely Impact Incident No Affected GUI Low 102042 Problem Solution Details A previous patch fix has uncovered an error with the database search. This error caused the audit trail to fail for NET items when the system base currency was loaded. The database query has been fixed so that the audit trail will work for all items.

Issue No WBC-2655

Description A release that exceeds a 's charge limit is subsequently evaluated against confirmation limits in all cases.

Priority P2

Problem Reported If a release exceeds a 's charge limit and the decision is made to check the "net item" box in the interaction dialogue, rather than re-evaluating against the 's net limits, the release always progresses to authorising with supervisor limits. In this case, it should be possible to perform release against the 's net limits. Component Likely Impact Incident No Affected 101428 Problem Solution Details A release that exceeds a 's charge limits may now be evaluated against net limits following the checking of the net item option in the interaction dialogue, rather than proceeding to supervisor authorisation in all cases.


Issue No WBC-2675

Description Set ID is not populated for all messages in GMMI when it is opened via GMM.

41

Priority P3

Problem Reported If you select a message from the GMM grid, Set Id is present for that message. When you open the message in GMMI, Set Id is populated as a blank message. This issue is consistent with all messages. Component Likely Impact Incident No Affected CCD

101878

Problem Solution Details WBC-2679 : WebConnect cache is updated if it doesn't contain the requested ID. WBC-2675 : Now Set ID field is populated correctly when using GMM-GMMI

Issue No WBC-2679

Description Set ID is not displayed for a newly created in GMMI when it is opened via GMM.

Priority P3

Problem Reported After creating a new for a message type, the ’s Set ID is not displayed when the message is opened in GMMI via GMM. The Set ID is only displayed when WebConnect is restarted. Component Likely Impact Incident No Affected CCD

101878

Problem Solution Details WebConnect cache is updated if it doesn't contain the requested ID. WBC-2675 : Now Set ID field is populated correctly when using GMM-GMMI

Issue No Description Priority WBC-2738 Allow six digit date entry in GMMI P2 Problem Reported GMMI screen allows to enter dates in six digit format e.g. 251208 instead of 25/12/2008 but this is not useful since the six digit format can't be validated on the server. The front end should rewrite valid six digit dates before submission to the server. Component Likely Impact Incident No Affected GMI

101881

Problem Solution Details GMMI allows to enter date in six digit format e.g. 251208 and the front end rewrites a valid six digit dates to required 25/12/2008 format.

42


Issue No WBC-2739

Description Allow six digit date entry in form control, item edit form, analytics search prompts and business logic interaction

Priority P2

Problem Reported The form control, item edit form (bulk edit), analytics search prompts and business logic interactions allow to enter dates in six digit format e.g. 251208 instead of 25/12/2008 but this is not useful since the six digit format can't be validated on the server. The front end should rewrite valid six digit dates before submission to the server. Component Likely Impact Incident No Affected GUI

101881

Problem Solution Details Six digit date entry is now ed in form control, item edit form, analytics search prompts and business logic interaction.

Issue No Description Priority WBC-2756 Create custom control to display the expandable attribute. P3 Problem Reported The current process for viewing data associated with expandable attributes has been found to be cumbersome and in some cases does not work at all. A simpler solution is required, maybe by making use of a separate dashboard. Component Likely Impact Incident No Affected 101873 Problem Solution Details The solution has been to push the current functionality of displaying expandable attribute messages into it's own custom control. This new custom control can be configured within design studio (url: /secure/showexpandableattribute.do) and assigned to the grid control, which contains the expandable attribute, as a drilldown. This allows the to then drilldown from a row in the grid to view its associated expandable attribute message.

Issue No WBC-2792

Description When entering data in GMI for generic message types, the "net remaining" text box at the bottom of the screen is not shown.

Priority P3

Problem Reported WebConnect 2.6 SP1 issue: When entering data in GMI for generic message types, the "net remaining" text box at the bottom of the screen is not shown. Component Likely Impact Incident No Affected GMI

102807

Problem Solution Details Added a for balance type Dual Balance, Generic Currency and Generic Asset to show "net remaining" text box at the bottom of GMI dashboard.


Issue No WBC-2696

43

Description Priority The fast-cut destination grid scrolls to the top of the record set P3 every time fast-cut is used.

Problem Reported When cutting rows to a different grid the target grid scrolls to the active row (typically the first row for a scratchpad grid). This means that the newly cut rows are not necessarily visible. The newly cut rows should always be visible. Component Likely Impact Incident No Affected GUI

102328

Problem Solution Details When cutting rows from one grid to another, the target grid will scroll so that the last row cut is visible.

Issue No Description Priority WBC-2736 LDAP configuration allows to with blank . P2 Problem Reported LDAP can legitimately allow a to with a blank . WebConnect should be updated so that a cannot with a blank . The workaround is to configure LDAP to disable anonymous binds. Component Likely Impact Incident No Affected GUI

102355

Problem Solution Details s can no longer using a blank through LDAP authentication.

Issue No Description Priority WBC-2740 Default highlight of selected row is very difficult to see. P2 Problem Reported Issue raised previously under SI 100487 and partially addressed via WBC-2401. Problem still exists, as the fix did not address the default darker/more visible 'tramlines' - only that they are configurable. Change default current row highlighting from WHITE to BLACK. Component Likely Impact Incident No Affected 101137 Problem Solution Details Changed default row highlight colour to black.

44


Issue No WBC-2776

Description Allow character months in date format & control over 2-digit years

Priority P2

Problem Reported Due to the international nature of our business, we are looking to have control over the display format of dates in WebConnect. We are proposing a format of "DD-MMM-YY". Component Likely Impact Incident No Affected GUI

102379

Problem Solution Details Added facility to define system-wide custom formats for date values, configured by an entry in the syst table. It is possible to configure different formats for different locales. If a custom format is defined for a 's locale then that custom format is used for that 's session. If there is no custom format defined for a 's locale then WebConnect will default to use the standard Java "SHORT" format as before. To enable the custom formats an entry is added to the syst table with the following SQL: insert into syst (syst_name,description,syst_title,syst_type,syst_string) values ('DATE_FORMAT','WebConnect - custom date format','WebConnect - custom date format',1,') Then the customs formats can be set using SQL similar to this: update syst set syst_string='en_GB=dd-MMM-yyyy,en_US=MMM-d-yy' where syst_name='DATE_FORMAT' The configuration string specifies the locale and the format separated by an = sign. Specifications for multiple locales must be separated by a comma. The locale and format are specified in a similar way to the standard Java Locale and DateFormat. Only the date part of the format is configurable (there is no for configuration of the time of day format) and only the d, M and y pattern letters are ed. ref: http://java.sun.com/j2se/1.4.2/docs/api/java/util/Locale.html ref: http://java.sun.com/j2se/1.5.0/docs/api/java/text/SimpleDateFormat.html

Issue No WBC-2808

Description Priority After invoking the GMMI window from Message Maintenance and cancelling the input, refreshing the Message Maintenance P2 window causes the search to run indefinitely.

Problem Reported After invoking the GMMI window from Message Maintenance and cancelling the input, refreshing the Message Maintenance window causes the search to run indefinitely. Component Likely Impact Incident No Affected CCD

102864

Problem Solution Details The main cause of this issue that custom control was not built correctly in UI tier and it is fixed in gmmGmmi.jsp.

Issue No WBC-2811

Description Priority Remove the loading of all set IDs which causes problems in the P2 case where there are too many to handle.

Problem Reported Remove the loading of all set IDs which causes problems in the case where there are too many to handle. The worst of this was fixed by WBC-2336, this will go the whole hog. Component Likely Impact Incident No Affected GUI Problem Solution Details Removed the loading of all set IDs per .

101633


Issue No WBC-2815

Description Net items that have gone on through (un-audited) workflow processing cannot be recalled

45

Priority P2

Problem Reported Clone of issue on 2.6SP1. In WebConnect, item matches that create net items that have gone on through (unaudited) workflow processing cannot be recalled. 1. Release two items that will create a net item (due to an amount discrepancy). 2. Run a workflow tool against the net item that has a single UNAUDITED event (e.g. an unaudited edit event on Reference 1). This will update the net item softlock but not the audit ID. 3. Recall the original item match. 4. WebConnect will attempt to recall the net item and will fail with the message: 'This group may not be recalled as you are attempting to recall the items matched against the lead item in a different order from that in which they were released.' This occurs because the net item recall is using the 'event_group_id' instead of the 'audit_id' to test if the item can be recalled. This error has been present in WebConnect since 2.6. Component Likely Impact Incident No Affected Low

101302

Problem Solution Details WebConnect was not able to recall net items that had undergone unaudited workflow since creation. The recall process was incorrectly using the item softlock instead of the audit ID to determine if the item could be recalled. The recall process has been fixed to correctly recall net items.

Issue No Description Priority WBC-2833 Document template fails to parse currency field P3 Problem Reported When manually create the document : YOU BUY currency is being shown correctly as item.currency_2 which is SGD for this item but YOU SELL currency is not being reflected in the document . Component Likely Impact Incident No Affected GUI

102384

Problem Solution Details The currency that was being used was taken from the bank row or message header row associated with the item, rather than the item currency itself. The fix is to explicitly overwrite the currency with the item currency to ensure this is the value that is used. Issue No WBC-2845

Description Summary row to include break down of data and aggregate rows

Priority P2

Problem Reported The summary row needs to be modified to include total values of both data row and aggregate rows, where applicable. Component Likely Impact Incident No Affected GUI

102380

Problem Solution Details The summary row now provides a more complete descriptions of the total rows presented in a grid, including the original data row count, the number of rows filtered out and the number of aggregate rows added as appropriate.

46


Issue No WBC-2850

Description Priority Include the option to maintain grouping following modification P2 to sorting

Problem Reported Currently, all grouping is removed upon the first initiated change to sorting configuration. In some cases it may be desirable to keep the grouping behaviour of a grid's view while adding, removing, reordering or reversing the sorting behaviour on one or more columns. Component Likely Impact Incident No Affected GUI

102578

Problem Solution Details It is now possible to maintain the grouping of rows following the modification of a grid's sorting configuration. This optional behaviour may be enabled globally through the setting of a -DmaintainGroups=true parameter when launching WebConnect. Issue No Description Priority WBC-2923 Add case note on case edit failing - transaction issue P3 Problem Reported Select a row in a case grid and edit. On save changes, add a note. An exception is thrown. IllegalStateException: Trying to change transaction TransactionImple < ac, BasicAction: -3f5791e4:7a8:49917202:57 status: ActionStatus.RUNNING > in enlist! This occurs on JBoss4.2.3. Component Likely Impact Incident No Affected GUI 103380 Problem Solution Details Add note to case on edit should now work when running on JBoss Issue No Description Priority WBC-2932 Enforce uppercase based on schema for Choosers and forms. P3 Problem Reported Enforce uppercase based on schema for Choosers and forms. Component Likely Impact Incident No Affected GUI Low 103336 Problem Solution Details Within forms ensured fields take into considering the specified font case as defined on their associated attributes. If upper case is required, then input will be transposed appropriately. This fix also resolves the issue relating to the chooser, in that text copied from an upper case field into the chooser filter, will now be in the expected format.


Issue No WBC-2942

Description Date range difference not correctly calculated for workflow rule

47

Priority P3

Problem Reported We have a workflow rule that tests the values ed in a group from WebConnect, to ensure that settlement dates fall within a certain range of each other. Prior to this test we have ensured that the group contains only two items with settlement dates of 19/11/2008 and 25/11/2008. I have substituted the rule CSH SETT DATE GAP < 4 by one which tests that all settlement dates are the same. With this test in place the group failed this workflow step. It seems that the range test simply does not work. I have checked that there are no non-working days set up over the period between 19/11 and 25/11. With the rule changed to a range of 2 days, our test case still es. In other words TLM thinks that there are 2 or fewer days between 19th and 25th of November. Component Likely Impact Incident No Affected GUI 102435 Problem Solution Details Corrected the date range difference algorithm to ensure the correct max and min dates are used. Issue No Description WBC-2945 Not ing under limit and over limit checking Problem Reported The warning screen for under charge limit matches is not displaying. Component Likely Impact Affected GUI Low Problem Solution Details Coded to Under/Over limits for interest and charges.

Priority P3

Incident No 102764

Issue No Description Priority WBC-2947 Audit trail fails to open correctly on Sybase P2 Problem Reported When an item is ed through my initiation event, NO AUDIT TRAIL comes up for the item. When you click on audit trail the audit trail box appears saying Associated Items, and there is nothing displayed. Component Likely Impact Incident No Affected GUI 103468 Problem Solution Details Handle ID by correct data type. Issue No Description Priority WBC-2948 Not netting positions items correctly during release workflow P2 Problem Reported Set up a release workflow that will test the net of an Our Positions item and a Their Positions item. One value should be subtracted from the other based on schema sign, however they are added. Component Likely Impact Incident No Affected GUI 102874 Problem Solution Details Securities items' sign should be inverted if a ledger , and inverted again if a mirrored . This then provides the correct multiplier for netting calculations.

48


Issue No Description Priority WBC-2959 Document template fails to parse currency field P3 Problem Reported When manually create the document : YOU BUY currency is being shown correctly as item.currency_2 which is SGD for this item but YOU SELL currency is not being reflected in the document . Fix went in to 2.7, but SQL is not Oracle compliant. Component Likely Impact Incident No Affected GUI 102384 Problem Solution Details The currency that was being used was taken from the bank row or message header row associated with the item, rather than the item currency itself. The fix is to explicitly overwrite the currency with the item currency to ensure this is the value that is used. Ensure SQL is Oracle compliant. Issue No Description WBC-2978 GMI Dashboards should raise when clicked on Problem Reported The GMI Dashboard should raise when clicked on. Component Likely Impact Affected GUI Low Problem Solution Details GMI Dashboard now raises when clicked on

Priority P3

Issue No Description WBC-2979 Analytics Dashboards should raise when clicked on Problem Reported The Analytics Dashboards should raise when clicked on. Component Likely Impact Affected GUI Low Problem Solution Details Analytics Dashboards now raises when clicked on

Priority P3

Issue No WBC-2984

Incident No 101882

Incident No 101882

Description Priority The 'retain note text' system setting is not respected by the edit P2 tool

Problem Reported When the SYST setting 'RETAIN_NOTE_TEXT' is set to true, the note dialogs on the business logic tools will and display the last entered note. It has been observed that the note dialog on the productised edit save tool on grids does not and display the last entered note. Component Likely Impact Incident No Affected GUI Low 103135 Problem Solution Details Added the 'Retain Note Text' system parameter functionality to the edit save tool. The note dialog on a save will now '' the s last note.


49

Issue No Description Priority WBC-3163 Validation of long decimal numbers does not work correctly P2 Problem Reported The validation in the bulk edit form of long decimal numbers sometimes incorrectly fails the 'decimal place' check . To reproduce: 1. Create a 'security positions' item grid with an edit save tool. 2. Add the attribute : 'Item On Loan Quantity' (ID 665) to the view. 3. Open grid and select a row. 4. Open bulk edit form (using right-click edit option) and enter '12345678901' (i.e. 11 digits) into the 'Item On Loan Quantity' field. 5. Submit changes and you should get an error "Invalid value for field: Item On Loan Quantity" even though the decimal places have not been exceeded. This issue is related to the conversion from a Long to a Double to a BigDecimal in GenericAttributeValidator. Component Likely Impact Incident No Affected GUI Low 104061 Problem Solution Details The attribute validation has been modified to prevent stripping of trailing zeros on a number value when the number is in scientific notation. Issue No Description Priority WBC-3175 Tool constraint using lead fails on dashboard open P3 Problem Reported If in case of the Delete tool I use Constraint Management and in the constraint Rule Detail I specify e.g.: Lead ID = 'LDLATNE1' then instead of the dashboard in WebConnect I can see an error message. I have tried to change the constraint rule and instead of Lead ID use Current ID. In this case I can see the dashboard. Component Likely Impact Incident No Affected GUI Low 104230 Problem Solution Details Ensure the id is available for tool constraint evaluation. Issue No WBC-3196

Description Priority GMMI : An input string like 01-02-03 is being interpreted as a P3 date in the year 0003 rather than the year 2003

Problem Reported An input string like 01-02-03 is being interpreted as a date in the year 0003 rather than the year 2003 in GMI. This issue occurs in WebConnect 2.6SP1. Component Likely Impact Incident No Affected GMI 102379 Problem Solution Details Now GMI and GMM/GMMI handle custom date format correctly.

50


Issue No WBC-3202

Description When the try & load a message for the same day as a previous currency_balance (& there are no missings), GMI does not give the option to carry on & submit.

Priority P3

Problem Reported When the try & load a message for the same day as a previous currency_balance (& there are no missings), GMI does not give the option to carry on & submit. It prevents the input when the get the 'No missing' message', where the should be allowed to submit message. Component Likely Impact Incident No Affected GMI Low 104135 Problem Solution Details When the gets the 'No missing' message', rather than preventing submission, the is allowed either to submit message or to cancel it. Issue No Description Priority WBC-3245 WebConnect times out releasing two items P3 Problem Reported Matching two o/s cash items (ls_types 2 and 4) where one of those is a NET item results in excessive query on OIRC / OIRD to ascertain the interest applicable to the match. The superfluous query appears to come from the fact that all underlying items from the NET item are included in this calculation when I do not believe this should be the case i.e. only use the current items in match group and their value dates. Component Likely Impact Incident No Affected GUI 103260 Problem Solution Details Currency rates are now resolved more efficiently. Issue No WBC-3279

Description Unable to recall create data event items created as part of release workflow

Priority P3

Problem Reported Unable to recall any items that have been created using a Create Data event through Release workflow. Component Likely Impact Incident No Affected GUI Low 104714 Problem Solution Details Corrected code to execute as a batch statement, and ensure all items are processed.


Issue No WBC-3290

Description Securities transaction items not being netted correctly in release workflow

51

Priority P2

Problem Reported Release two items, one a Their Sells Ledger and one Our Deliveries Ledger. Rule tests abs net item deal quantity > 0. Select two items that do net to 0. However the rule es. WebConnect is failing to apply the correct sign based on side and sign. Component Likely Impact Incident No Affected GUI Medium 104257 Problem Solution Details The side/sign logic has been rewritten for release items. All release items should net to the correct values regardless of item type. The sign used is determined by the schema property 5 (Action). This fix affects all cash, security and generic items in the productised release process. Issue No Description Priority WBC-3294 Implement a tolerance on balance checks for GMI P2 Problem Reported Customer has raised an issue for out of sequence in GMI, wherein the gets a warning message when there is a very minor difference between Opening Balance and Latest Closing Balance. We will insert a tolerance value for the difference. Component Likely Impact Incident No Affected CCD Low 104580 Problem Solution Details While comparing opening balance and closing balance a small tolerance value will be considered for equality. This has resolved the problem reported. Issue No Description Priority WBC-3297 SSO can still present change screen P3 Problem Reported When a WebConnect s expire, the change prompt appears through WebConnect, however when the tries to update they are presented with a blank screen. management is suppose to be completed via Recon for this type of and as such the change option should not be presented. Component Likely Impact Incident No Affected GUI Low 104908 Problem Solution Details Do not allow change in SSO or when using Web Services authentication.

52


Issue No WBC-3302

Description Create Data Event Workflow Not Recalled Following Cash Release

Priority P3

Problem Reported Productized recall tool does not recall a create data event item fired as part of release workflow. This is following a cash release. Component Likely Impact Incident No Affected GUI Low 104716 Problem Solution Details Items created via a release workflow containing a create data event now get recalled successfully. Issue No WBC-3315

Description Create case event not finding correct amount for currency conversion

Priority P3

Problem Reported Firing a create case event with item currencies that are not in the base currency throws an exception. Component Likely Impact Incident No Affected GUI Low 104563 Problem Solution Details Add the amount attribute to the required attributes for the create case event, as this may be needed for converting to base currency to determine the lead item. This attribute may not already have been added if none of the four Create Case amounts are this amount attribute. Issue No Description Priority WBC-3326 The Edit Case tool does not refresh child dashboards P2 Problem Reported The 'Edit Case' productised tool does not trigger the (correctly configured) child dashboards to refresh when a edit is saved. Stale data is left on the child dashboards. As the form edit and other business logic tools do trigger refreshes, I think the productised edits tool should do so as well. Scenario: 1. Create a Case Summary dashboard with a Case Details child dashboard (see Case Summary on WC_Reg_Test) 2. Configure a 'Edit Case' save tool on the case summary dashboard. 3. Load dashboard and open child. 4. Edit a field in the parent dashboard and save it. 5. Observe that the parent grid row refreshes but the child control does not. See incident details for more detail. Component Likely Impact Incident No Affected GUI Low 104254 Problem Solution Details Child dashboards are now refreshed after edits in the parent grid have been saved.


53

Issue No Description Priority WBC-3366 SSO URL allows multiple launches of WebConnect P3 Problem Reported It's possible to launch WebConnect multiple times (for a single and session) in a SiteMinder environment using bookmarks, favourites, or links. In this particular case a URL in an e-mail. i.e. http://******:8080/WebConnect//siteminder.jsp The presence of more than one application window can cause various problems and WebConnect should guard against it happening. Component Likely Impact Incident No Affected GUI Low 104908 Problem Solution Details Modified SiteMinder JSP to prevent it launching a WebConnect application window if the is already logged on. Issue No WBC-3382

Description Attempting to save a case edit causes an UpdateException during row refresh

Priority P2

Problem Reported From the incident: After editing a case, it is not possible to save it. In the log file I can see the following error: Incorrect syntax near 'C'. It looks like that something (where?) is missing between ( C.event_id = EVDE.event_id ) (C.case_no=4408271) Component Likely Impact Incident No Affected GUI Low 105183 Problem Solution Details The saving of case edits has been made more robust with regard to the subsequent refresh of row data from the database. Issue No WBC-3406

Description Web Services authentication does not '$' and '&' in the name or

Priority P3

Problem Reported Authenticating via web services does not having a dollar sign or an ampersand character in the . Component Likely Impact Incident No Affected GUI Low 104866 Problem Solution Details Parse $, &, < and > characters in by parsing/escaping before creating XML message.

54


Issue No Description Priority WBC-3435 MAXIROWS not respected on Sybase P2 Problem Reported Sybase driver does not respect call to setMaxRows. Component Likely Impact Incident No Affected GUI Medium 105156 Problem Solution Details The Sybase driver is not respecting the call to set the maximum number of rows to return, so all are being brought back and processed (causing memory issues in WebConnect). Updated the code to only process the maxi rows number of rows returned. Setting maxi rows is still in place as this is respected by SQL Server and Oracle. Still allows unlimited rows to be processed for Corona. Issue No Description Priority WBC-3459 Close when history not respected on create case event P2 Problem Reported In FX Confos, the status of the trades will be changed to HISTORY upon manual match /force match, and the CASE STATUS should also be auto set to 'RESOLVED'. However the case status remained as "UNRESOLVED" , even though in the create case event , it has been set to "Close when History". Component Likely Impact Incident No Affected Low 105218 Problem Solution Details Use the status field for checking whether to resolve the case. Issue No WBC-3666

Description Workflow rule with abs net amount fails to resolve correctly (Trunk)

Priority P3

Problem Reported Create a Workflow Rule on a Generic Cash Rec where "abs net Item Amount less than '0.01'", and trigger it against an item with amount 0.13 JPY, it es, Component Likely Impact Incident No Affected GUI Low 105818 Problem Solution Details Ensured that the syst setting "USE_BANK_CURRENCY" is applied during rule processing Issue No WBC-3692

Description Priority The SmartStudio client can take several minutes to start-up on P2 a slow network.

Problem Reported On an unreliable and/or latent network the schema loading phase can take several minutes. Component Likely Impact Incident No Affected SmartStudio Low 105759 Problem Solution Details Performance improvements have been made which should affect the loading of SmartStudio clients on slow networks.


Issue No WBC-2955

Description s are able to submit a Trial Balance search that can include a large number of Sets that effectively brings production to a halt.

55

Priority P3

Problem Reported Original quoted problem was "s are able to submit a Trial Balance search without any parameters being entered that effectively brings production to a halt." "Customer is requesting some mechanism to prevent such searches from commencing, such as mandatory search parameters in the Trial Balance prompt, or even just some default text in the Set ID box that must be overwritten." In fact the trial balance search does insist that you must fill in a Set, Group, Currency, Category or Set-type, but some of those parameters can cover a very large number of Sets. Default text would not work & would just be an annoyance to other s. Component Likely Impact Incident No Affected GUI Low 103428 Problem Solution Details A maximum number of sets will be specified in the SYST setting: 'Trial Balance set search limit'. The default value is 1000. If the SYST value is missing then it is unrestricted. If a Trial Balance search will be calculating Trial Differences for more s that the maximum (even if some sets are subsequently filtered out), then the will be prompted to change the search criteria. Issue No WBC-2961

Description Provide a means to configure the browser polling interval between business logic progress updates.

Priority P2

Problem Reported When a instigates server-side business logic execution, the browser periodically polls for progress updates. The polling interval is hard-coded to one second. This results in a large number of http request / response cycles for long running logic and consequent load on the network and http server. Some control over this load could be provided if the polling interval could be configured to adapt to the logic's execution time. Component Likely Impact Incident No Affected GUI 103642 Problem Solution Details The browser polling interval during business logic processing can be configured by a new entry on the SYST table (syst_name = 'BL_UPDATE_DELAY'). This entry is a string comprising a semicolon separated list of integers, e.g. '1000; 3000; 5000; 10000'. Each integer represents an interval in milliseconds so the example string represents four intervals of duration 1, 3, 5 and 10 seconds. The first time that the browser polls it will wait for first specified interval, then the second time it will wait for the second interval and so on. Once the end of the list is reached the last interval will be used for subsequent polling intervals. Note that the minimum interval that the browser will wait is 1000ms. If an interval shorter than this is configured, the minimum will be used.

56


Issue No WBC-2982

Description The bulk edit tool does not validate the existence of entered values for certain attributes

Priority P2

Problem Reported When edits are saved on a grid, some attributes (e.g. currency, source code) are checked against the database to ensure a valid value has been entered (such as a real currency code). However, this check is not performed when a bulk edit is performed against a number of rows. As a result the does not find out that a large edit is invalid until they press the save button. It is proposed that the bulk edit form will perform these validation checks and reprompt the for a correction if any entered values fail validation. Component Likely Impact Incident No Affected GUI Low 101883 Problem Solution Details Added business tier validation to the bulk edit form so that -entered values for decode attributes or attributes with existence-checking properties (e.g. Currency, Source Code) will be validated against the permitted values. This was already happening when the grid was saved but will now also happen the bulk edit form is submitted. Issue No WBC-3166

Description Improve the performance Analytics : Currency Value Adjusted Balances

Problem Reported Patch the CVAB performance enhancements from 2.5SP1 to HEAD. Component Likely Impact Affected GUI Low Problem Solution Details The performance of CVAB analytics screen has been enhanced. Issue No WBC-3212

Description Allow net item value date to be non editable in release group summary interaction

Priority P2

Incident No 103683

Priority P3

Problem Reported Customer requires the ability to toggle whether the net item being created in release has an editable value date. This will be driven by a new syst switch. Component Likely Impact Incident No Affected GUI Low 104327 Problem Solution Details Now allows net item value date to be non editable in release group summary interaction.


Issue No WBC-3249

Description Syst flag to toggle writing 0 instead of 10 for Resolution or Note CAST records

57

Priority P3

Problem Reported Make use of SYST-based export settings in WebConnect to decide that any Resolution CAST records or Note CAST records are written with status = 0 instead of 10 - that will allow a custom version of transmit to pick the records up & deliver the appropriate messages to PEGA. Case resolution must be consistent no matter how the case is closed - manually, Case resolve event or auto-close as items go to history. Component Likely Impact Incident No Affected GUI Low 104326 Problem Solution Details Write 0 to CAST if X_EXPORT_TYPE not STANDARD for Case Resolve. Issue No Description Priority WBC-3250 Audit of Cancelled Case toggle status by X_EXPORT_TYPE P3 Problem Reported As per auditing of Resolution, need to be able to toggle status to 0 (case status outbound message waiting) based on X_EXPORT_TYPE_STANDARD syst switch. Component Likely Impact Incident No Affected GUI Low 104326 Problem Solution Details Audit of cancelled case status toggled by X_EXPORT_TYPE. Issue No Description Priority WBC-3277 Extend SSO options P3 Problem Reported If the GSSO_ syst value does not match a header received from the SSO application, assume that this contains an absolute URL for the page. If this syst value is blank, then default to a WebConnect page. This will contain no links or buttons, simply a message stating the has logged out. Component Likely Impact Incident No Affected GUI Low 104708 Problem Solution Details URL can be ed in header, or looked up in syst, or default to a WebConnect logged out page. Issue No WBC-3321

Description Priority Exported Cases should allow same functionality as Unresolved P2 cases

Problem Reported Unresolved or pending cases allow: - doc attach - add note - add items to case - cancel case Unresolved cases allow: - resolve case - document - delete document Exported cases to allow the same, independent of CASEREFAMEND syst switch. Component Likely Impact Incident No Affected GUI Low 104326 Problem Solution Details Exported cases to allow same functionality as unresolved cases independent of CASEREFAMEND flag. Editability of exported cases still driven by CASEREFAMEND flag.

58


Issue No Description Priority WBC-3486 Tool refresh on items with currency convert attributes is slow P3 Problem Reported Fire a release tool on a number of items that include a currency convert attribute. The post tool update policy is to refresh the grid. This checks the for the latest currency rates for every selected row. This should only be done once. Component Likely Impact Incident No Affected GUI Low 105032 Problem Solution Details Only refresh the currencies for convert currency attributes once for a grid refresh (as opposed to every row). Issue No Description Priority WBC-3491 Debug on large release is causing an inefficiency P3 Problem Reported When the ReleaseGroupBuilder provides a ReleaseGroup via getReleaseGroup(), it logs a debug message at the end of the method. The debug message uses toString() on the release group which in turn calls toString() on its (cash) items. The items use the string of their release group as part of their string so we get this cyclic dependency. As far as I can make out, the offending code has been around since about 2004. Unfortunately, the debug message is build even if debug logging is disabled due to a missing if(log.isDebugEnabled()) check beforehand (this happens a lot in the code and should be guarded as described). So we can do a number of things: 1 - Ensure that debug strings are only constructed if debug logging is enabled (this would at least restrict the occurrence of the problem). 2 - Break the cyclic dependency between CashItems and CashReleaseGroups in their toString() methods. 3 - Dig a bit deeper to find out why we've only now had this problem (perhaps the items and the group are being associated with each other a bit earlier causing the runaway message at this point). To actually stop the problem for now (i.e. action point 2) would be trivial. Component Likely Impact Incident No Affected GUI Low 105909 Problem Solution Details The verbosity (i.e. depth) of debug messages during the release of potentially deep netting item trees has been restricted and now not constructed at all when debug logging is disabled. Issue No WBC-3699

Description Priority When an event code is added to one item, the event code for subsequent recalls should not pre-populate with the last event P2 code selected. (2.7SP1)

Problem Reported Customer has the following requirements: 1. When an event code is added to one item, the event code for subsequent recalls should not pre-populate with the last event code selected. 2. It is a requirement for the event code chosen to appear in the audit trail. 3. It is acknowledged that the event code can be seen by viewing the notes on a item, but the business would like the event code to be displayed in the main body of the audit trail. Component Likely Impact Incident No Affected GUI Low 106419 Problem Solution Details RETAIN_NOTES syst setting now retains or discards the last entered event code as well as the last entered note. Note that if retention of note and event code is not required, then the relevant SYST_VALUE must be set to 0.


59

Issue No Description Priority WBC-3481 gmmGmmiError.jsp file is missing in GMM-GMI. P3 Problem Reported Customer has raised this issue because they were getting the following error message (due to incorrect configuration). > JSPG0036E: Failed to find resource /secure/cust/gmmi/gmmGmmiError.jsp. The request is forwarded to this file when any exception is thrown in GMMGMMIAction.java. There is not implementation available for gmmGmmiError.jsp in GMM-GMI. Component Likely Impact Incident No Affected GMI Low 105140 Problem Solution Details Error handling is provided in GMM, to handle breaking of functionality when no input is provided to input parameter 'messageNumber' while configuring the custom control. Issue No WBC-2949

Description Priority Siteminder: Remove the domain name if included in the logon P2 id.

Problem Reported While doing the integration with siteminder at customer site, we encountered a problem Vanguard supplies the information to various applications. Basically, customer has two ways we to send the Siteminder response the SmartStream application. 1. The Standard Header. (HTTP_SM_). This will the domain/id (example: customer\uaqm). The domain is part of the ed information based on "Windows Integrated Authentication" and also "NT Lan Manager" (NTLM) architectures. We cannot change how this is ed,. 2. The Custom Header. (Custom_Header). In addition to the Standard Header, customer has the ability to create and send a "Custom header" that contains only the ID. This is the method that SmartStream should use if they cannot process the Standard Header and extract the ID. The custom header is used when the standard header is not feasible, or it does not supply the information required by the receiving application. Siteminder does not read custom header if there is standard header already available. But WebConnect does not the standard header with domain names. PS requesting to remove the domain information if it available. Component Likely Impact Incident No Affected GUI 103173 Problem Solution Details If the name request header contains a domain element (delimited from name with a slash), then strip the domain element. Issue No Description Priority WBC-3037 Delete Message in Case Transmission universe P3 Problem Reported The tool can be selected via the thick client, but is not currently ed by WebConnect. Component Likely Impact Incident No Affected GUI 103899 Problem Solution Details Delete Message tool now ed in WebConnect.

60


Issue No WBC-3199

Description Re-instate use of existing CASEREFAMEND switch to allow exported cases to be edited by s

Problem Reported Respect CASEREFAMEND syst parameter. Component Likely Impact Affected GUI Low Problem Solution Details Allow edit of exported cases via CASEREFAMEND syst switch. Issue No WBC-3208

Description Allow NET Item value date to be derived from earliest value date of released items

Priority P3

Incident No 104326

Priority P3

Problem Reported "Currently the value date on net items is derived from the lead item. An option is required to derive this from the earliest value date - controlled by a SYST switch" Component Likely Impact Incident No Affected GUI Low 57477 Problem Solution Details Use the earliest value date from the group of items in the release for the net item if SET_EARLIEST_NET is on.


Issue No WBC-3342

61

Description Priority HVB Hunt - Introduce configurable tolerance on amount fields P2 in TLM searches

Problem Reported The SSR Hunt function automatically applied a small tolerance to searched for amounts. WebConnect must provide a means of optionally allowing a tolerance to be applied to any amount fed into a search at the individual search prompt level. It must be possible to specify separate 'above' and 'below' tolerances for integers, amounts (decimals), dates, and dates with times when used in search rules. Backwards compatibility must be maintained, ie existing rules must work as presently. CI must be able to migrate the rules containing this configuration SmartStudio must offer configuration for this feature. The tolerances will not editable by the at runtime. Exisitng range functiionality can be used to achieve runtime editing if required. The same units should be used for both the above and below tolerances, ie. If percentage is used for the low tolerance then it must also be used for the high tolerance. It should be possible to determine whether a tolerance is being applied by lookinig at the prompt screen. For example by showing a different operator than '='. The allowed values of the tolerances must be appropriate for the attribute's datatype. ie. Integer attributes will only allow integer tolerances Amounts will allow decimal tolerances Dates will allow integer tolerances (number of days) Dates with times should allow a choice of the unit of the tolerance. Either Days, Hours, Minutes or Seconds Strings will not allow tolerance comparisons Attributes with decodes, or decode by procedure, will not allow tolerance comparisons. The underlying values of these fields are not visible to the , so allowing a tolerance would likely result in non-decodable values. Percentage tolerances must be allowed for integers and amounts, but not for dates or datetimes. No currency conversion will be performed for any of the comparisons. The tolerance feature should also work where a range of values if involved, ie. The 'Prompt for Range of Values' RHS reserved attribute is used. The tolerances may be applied to expressions where the right hand side is either a literal, a prompt, or the value of another attribute Use Case 1 : The opens a dashboard and is presented with a search prompt. A single prompt field is present for the attribute Item Amount. The enters the value 150.00. The rule has been configured to search for values close to the entered value. There is a below tolerance of 10, and an above tolerance of 100.50. The generated search will return values >= 140 and <=250.50 Use Case 2 : The opens a dashboard and is presented with a search prompt. A single prompt line is present for the attribute Item Amount with a From and To value The enters the values 100.00 to 250.50 The rule has been configured to search for values close to the entered value. There is a below tolerance of 10, and an above tolerance of 100.50. The generated search will return values >= 90 and <=351 Use Case 3: The opens a dashboard and is not shown a search prompt. The search rule is configured to show rows where Item Amount is close to the value of Item Extra Amount 1. There is a below tolerance of 10, and an above tolerance of 100.50. The generated search will return values where Item Amount >= (ItemExtraAmount1 - 10) and Item Amount <= (ItemExtraAmount1 + 100.50) Component Likely Impact Incident No Affected 102476 Problem Solution Details Configurable tolerance on amount fields in TLM searches implemented. Issue No Description Priority WBC-2903 Unable to attach documents to Cases P2 Problem Reported Unable to attach documents to Cases Receive an error in WebConnect when trying to attach a document to a case. It looks as it might be a db related error as per error logs attached. (cannot locate next id) Component Likely Impact Incident No Affected 103242 Problem Solution Details Fixed in 2.7SP1 by WBC-2434

62

7.2


Design Studio

Issue No Description DST-626 Save Option box is blank for case Desktop changes Problem Reported When you make a change on the case desktop, the save option box that appears is blank. Component Likely Impact Affected GUI Low Problem Solution Details Use the existing message from the emsg table.

Priority P1

Incident No 5008

Issue No Description Priority DST-635 Memory leak when opening dashboards multiple times P2 Problem Reported When repeatedly opening dashboards which parameters, a small but persistent memory leak is observed. The memory leak appears to be around 5MB after 100 iterations. Component Likely Impact Incident No Affected GUI Low 51469 Problem Solution Details The code has been changed to prevent memory leakages.

Issue No DST-636

Description Asset Transactions Manual Input amounts and currencies validation is incorrect for zero amounts

Priority P1

Problem Reported If an amount field is zero, it generally means that the field is blank. It is a requirement that for non zero amounts that a linked currency field is populated with a valid currency. However, currencies for zero amounts are not currently allowed. This extra validation is excessive and should be removed. Component Likely Impact Incident No Affected GUI Low 51128 Problem Solution Details The validation has been updated so that currencies are permitted for zero amounts.

Issue No Description Priority DST-642 Cases not closed when using close when history P2 Problem Reported If a case has been created with Close when History turned on and then manual progression is used with an edit event to set item to History, the case remains open. Component Likely Impact Incident No Affected GUI Low 40503 Problem Solution Details Close cases if case has "Close when History" on and manual progression is used to send an item to history.


7.3

63

SmartData Services

Issue No SDS-265

Description Add syst parameter for whether to highlight selected rows in the grid.

Priority P2

Problem Reported WebConnect is being enhanced to highlighting rows that have been selected by the selection mechanism (WBC-1998). Need to add a system parameter, HIGHLIGHT_SELECTION, defaulting to true to this. Component Likely Impact Incident No Affected Metadata

63449

Problem Solution Details Was already present when branched

Issue No Description Priority SDS-357 configurable custom date formats for WebConnect P3 Problem Reported A new syst parameter has been added for 2.7 'DATE_FORMAT'. To enable the custom formats in WebConnect an entry should be added to the syst table with the following SQL: insert into syst (syst_name,description,syst_title,syst_type,syst_string) values ('DATE_FORMAT','WebConnect - custom date format','WebConnect - custom date format',1,' ') The custom date formats can then be set using SQL similar to this: update syst set syst_string='en_GB=dd-MMM-yyyy,en_US=MMM-d-yy' where syst_name='DATE_FORMAT' Component Likely Impact Incident No Affected Database Schema Low 102379 Problem Solution Details Added new SYST switch to static data (syst.csv)

Issue No SDS-248

Description Priority Static data entries required for SYST for database specific IN, P2 WHERE clause limits and BATCH size

Problem Reported Static data entries required for SYST for database specific IN, WHERE clause limits and BATCH size. For Oracle, they are as follows: Oracle_BATCH_limit|0|Oracle_BATCH_limit|01/01/1900|0|15| |Oracle_BATCH_limit|-4|50 Oracle_IN_limit|0|Oracle_IN_limit|01/01/1900|0|15| |Oracle_IN_limit|-4|10 Oracle_WHERE_limit|0|Oracle_WHERE_limit|01/01/1900|0|15| |Oracle_WHERE_limit|-4|10 There is also SQL Server, Sybase, and Db2 to consider. SQLServer_IN_limit SQLServer_WHERE_limit SQLServer_BATCH_limit Sybase_IN_limit Sybase_WHERE_limit Sybase_BATCH_limit Db2_IN_limit Db2_WHERE_limit Db2_BATCH_limit Component Likely Impact Incident No Affected Services Medium H62355 Problem Solution Details Added database specific switches for in, where and batch

64

7.4


Recon Services

Issue No RES-613

Description Priority Workflow server crashes when running multiple initiations that contain a mixture of standalone edit events and P2 createdata events

Problem Reported Workflow server crashes when running multiple initiations that contain a mixture of standalone edit events and createdata events. The order of the events and es need to be as follows to observe the crash: Within the context of a single initiation Prior has an edit event as it's last event. Subsequent es that do not fire events do not impact replication Next that does fire events fires createdata event first In this scenario the toolbox editevent code was attempting an invalid memory access. Component Likely Impact Incident No Affected Toolbox Low 62137 Problem Solution Details Ensure that order of events being fired does not cause workflow server to attempt an invalid internal memory access. Specifically ensure that edit event in a previous followed by a create data event in a subsequent does not attempt to access 'stale' internal workflow server memory.

Issue No RES-671

Description Gems reports memory allocation error when it is trying to allocate zero bytes on an AIX O/S

Priority P3

Problem Reported Memory alloc error entity keys This comes from GEMS when it is trying to allocate a piece of memory in preparation for attaching items to the initiation. In this case there are NO ITEMS and GEMS is therefore asking the O/S for 0 bytes of memory. In most other environments this returns a pointer to an area of memory which has no data and there are no issues. However on certain environments this has recently been found to return a NULL pointer which does cause the above message to appear. The problem is in Gemsload.sc in the function populateItemKeys(). The rest of the issues all occur because of the first issue. Extract from log below ======================= (I) Message:0 *** Started feed /dtlm02/tlm/tlm1.2/var/ft/swift_out/20080506194438234237.SWF, KB FD_PURESWF Memory alloc error entity keys Log file is not open UNABLE TO ATTACH ITEM LIST - NO ITEMS ======================= Customer comment below for ref only In the swift file, the Sequence B of MT535 is not provided, so the NoOfItems is 0 in this case. Therefore we got the "Memory alloc error entity keys" message in the log file. The error checking of the function calloc does not consider the case that NoOfItems is 0 (or <0) the return can still be NULL.It should be a warning rather than an error.The log file is misleading. Component Likely Impact Incident No Affected Low Problem Solution Details Stop allocation of memory when none is needed

H62794


65

Issue No Description Priority RES-754 Limit the length of strings extracted from tag 86 P2 Problem Reported There is a function in GEMS which takes information from tag 86 of an MT940 and maps it to various item fields. There is no restriction on the length of the string extracted apart from the length of tag 86 itself. This can lead to overflows when attempting to load the string to the item table. Component Likely Impact Incident No Affected GEMS

63820

Problem Solution Details Check the length of the item columns being mapped. If the string is longer than the length permissible, then restrict its length.

Issue No RES-766

Description Priority In AAS an error in the stored procedure executing any extract will have its error message truncated to four or eight P2 characters

Problem Reported When the stored procedure returns its error string to the RunExtractSP(char * pszRet) function we have code of the following form: int RunExtractSP(char * pszRet) { call to stored proc here which returns string szRet sprintf(gszTempStr,"%d:%s", iRet, szRet); strny(pszRet, gszTempStr, sizeof(pszRet)); return iRet; } Because pszRet is a pointer to a character, sizeof(pszRet) is 4 or 8 bytes (machine dependent). Therefore pszRet will only get the first 4 or 8 characters of szRet copied into it. Component Likely Impact Incident No Affected Archive Server 64058 Problem Solution Details Change code so that it outputs the whole of the error message produced by the database in the extract phase of any job.

Issue No RES-792

Description GMI - when header field asset code is populated but not item asset code, gems isn't writing this from message header to subfield_8 on item

Priority P2

Problem Reported When the header field asset code is populated but not item asset code, gems isn't writing this from the message header to subfield_8 on item (item asset code). When both fields are populated, item.subfield_8 also gets populated. Component Likely Impact Incident No Affected GEMS Problem Solution Details Copy header stock code to each of the items for messages loaded from GMI.

64541

66


Issue No RES-803

Description Priority Allow 'Message Header' attribute to be viewable in dashboard P3 grids

Problem Reported The 'Message Header' attribute (attribute_id 457) should be given the Dashboard Views Displayable property (property_id = 68). This will allow s to drill from Item rows into the associated Message-header record when required. In particular, this will provide a work around for when a client wants to be able to search for Message-Headers that link to items with specific amounts - they will be able to search for the items first & then drill into the related header, rather than searching for both (as you could in SSR message maintenance). Component Likely Impact Incident No Affected Database Schema Low 100385 Problem Solution Details Modified static data recon.zs_attribute_sheet to add this property.

Issue No Description Priority RES-804 Header Feed ID not being included in kb generation P2 Problem Reported Header_feed_id is not being included when a new generic kb is created, due to the presence of attribute property 45. Component Likely Impact Incident No Affected 51848 Problem Solution Details Fixed in previous versions - refdata carried over to 2.7

Issue No RES-914

Description When a message has no items GEMS does not check if it is a duplicate

Priority P2

Problem Reported Duplicate pages loading into TLM 2.5 1. A statement page containing an opening and closing balance and transactions is loaded into TLM. The closing balance is marked as final. 2. A second statement page arrives in the same file for the same sub with the same statement number/page and has 0 opening and closing balances and no transactions In TLM, the second page loads and causes a missing balance. SSR used to mark it as a possible duplicate page and put it on the operator intervention queue. Component Likely Impact Incident No Affected GEMS Low 64600 Problem Solution Details Move duplicate page checking outside of check for items on the message


Issue No RES-918

Description Workflow rules which involve currencies are not working correctly

67

Priority P2

Problem Reported It is in the operation of any workflow rule (which is in this case evaluated as part of the 'Release Workflow') which has a RHS which involves a currency. For example, our rule in question has the following expression: where abs net item position value less than or equal to '1 aud' What this rule will do is evaluate the net item position value for the match group and take its absolute value. This will then be compared to 1 AUD. Now for this comparison to take place the LHS and RHS have to be in the same currency. What the code does is convert the RHS of this rule so that the '1 AUD' is replaced by an equivalent expression in the common curency (which is either base or bank currency). In this case the common currency is bank currency for the set, which is XAU. The conversion rate from XAU to AUD is to be found in the crat table: 1 base_currency = crat.rate X crat.currency therefore 1 AUD = 0.00185 XAU This gets rounded to 3 dp, which means that the '1 AUD' part of the rule is replaced with '0.002 XAU'. This can then be compared to the abs net of the item position value for the group, which is also in XAU. For our group the abs net item position value is 0.75 XAU. Therefore this is greater than 0.002 XAU, so we expect the rule to fail. However there is a bug where the common currency is not defined before the workflow rules are read in by the call to read_match_lifecycle_rulelists(), which is done inside proprule(). The common currency is actually defined inside load_items(), which comes later. Note that quality rules are OK because they are read in after load_items() - only workflow rules are affected. This bug means that the RHS side of the rule, instead of being convered from '1 AUD' into '0.002 XAU', becomes '1 XAU', causing incorrect evaluations of our groups against this rule. Component Likely Impact Incident No Affected Workflow Low 100282 Problem Solution Details Move the piece of code which reads in the common currency so that it comes before the reading in of the workflow rules.

Issue No RES-921

Description Arcxport is creating and dropping tables once per chunk per job. On Oracle this is creating a performance bottleneck.

Priority P2

Problem Reported The tables in question are as follows: ARC_TEMP_QD_1 ARC_TEMP_QD_2 ARC_TEMP_QD_3 ARC_TEMP_QD_4 ARC_TEMP_QD_5 ARC_TEMP_QD_6 The integer at the end of the table name corresponds to the server instance number. We could reduce the number of times they are created and dropped. At the moment they are created and dropped once per chunk per job. We could change this so that they are created and dropped once per job, or even get each instance of advarc to create its table once at startup and drop it when it closes down. Component Likely Impact Incident No Affected Archive Server Low 63356 Problem Solution Details Change advarc and arcxport so that each instance of advarc will create and drop one table at startup and shutdown respectively. Therefore instance 1 of advarc will create and drop table ARC_TEMP_QD_1 and so on. Previously, each instance of arcxport (which is called by advarc) was creating and dropping one of these tables once per chunk of each job - this could have been hundreds or thousands of times per job.

68


Issue No RES-932

Description Priority The Audit Category is not correctly identifying groups which it P2 may totally archive

Problem Reported The Audit Category should be able to archive complete groups from the audit_trail if all that is left over after the removal of orphans are unimportant rows. By unimportant we mean any rows which have event_type not in (12,15,20,21,25). However, the current implementation is unable to spot such groups. This results in complete groups not being archived when they should be. This has implications for the appearance of the audit_trail table in an archive database, since we advise the use of the Audit to transfer header rows to the archive database after a Transaction has been run with 'Include Audit Data' not ticked. Component Likely Impact Incident No Affected Archive Server Low 100775 Problem Solution Details Modify the 'Audit' category so that it can correctly spot groups within the audit trail which may be completely archived.

Issue No Description Priority RES-966 AAS can purge more rows from netm than it extracted P2 Problem Reported This comes about because of a simple typo in the p_stla_PurgeMatch() stored procedure. The code currently has IF @v_netm_extract > 0 BEGIN DELETE netm FROM arc_trns a, netm n WHERE a.corr_acc_no = n.corr_acc_no AND a.sec_match_no = n.netm2 SELECT @v_count = @@ROWCOUNT EXEC p_stla_UpdateRowcountPurge @p_job, 'netm', @v_count END where it should have IF @v_netm_extract > 0 BEGIN DELETE netm FROM #arc_trns a, netm n WHERE a.corr_acc_no = n.corr_acc_no AND a.sec_match_no = n.netm2 SELECT @v_count = @@ROWCOUNT EXEC p_stla_UpdateRowcountPurge @p_job, 'netm', @v_count END i.e. it uses arc_trns where it should be using #arc_trns. This bug means that the purge will be deleting rows from netm which to the whole of the arc_trns table - i.e. all rows from all jobs. The #arc_trns table only contains rows from the current job and chunk. Component Likely Impact Incident No Affected Low 100840 Problem Solution Details Replace arc_trns with #arc_trns in the p_stla_PurgeMatch() Sybase stored procedure

Issue No RES-968

Description If you have a very long list of workfolders, an Investigations Category AAS extract job can fail with oracle error -6502

Priority P2

Problem Reported In TLM-3065 we made a change to advarc so that it could handle a list of workfolders which is longer than 4000 characters in length. The same change must also be made to the oracle stored procedures p_stl_ExtractCase() and p_stl_DeleteCase(). Component Likely Impact Incident No Affected Archive Server Low 100418 Problem Solution Details Increase the size of an array used by the oracle stored procedures to hold a list of workfolders.


Issue No RES-969

69

Description Priority AAS fails to extract data for a Transaction' with 'Include P2 Audit Data' and 'Investigation' ticked.

Problem Reported The bug comes about when you have a 'Transaction' with 'Include Audit Data' and 'Investigation' ticked. If it turns out that there are items to be extracted but no cases for those items, the code doesn't clear down an array as it should do and it tries to insert the audit trail rows for the extracted items twice into arc_audit_trail. This causes a primary key violation. The error message you get is something like: DoExtract szRet <1:ORA-00001: unique constraint (.) violated > Component Likely Impact Incident No Affected Archive Server Low 100418 Problem Solution Details Clear down array in code so that if there are no cases on extracted items in a 'Transaction' , no primary key violation occurs in the arc_audit_trail table.

Issue No Description Priority RES-970 Index created without specifying tablespace P3 Problem Reported The upgrade script TLM2100a.sql drops and re-creates the index for lifecycle_itemsixa but does not specify a tablespace so it attempts to build it on the default tablespace (in this case s) which is too small and therefore fails. An amendment should be made to the TLM2100a script so that it creates the index on the correct tablespace. Component Likely Impact Incident No Affected Database Schema Low 101768 Problem Solution Details Added explicit table space to index.

70


Issue No RES-1006

Description Priority Arcxport can fail to insert a row directly into an archive database if the database has regional settings which mean that P2 the decimal point is a comma rather than a full-stop

Problem Reported If arcxport is unable to insert a complete chunk of data into the archive database it has to do row-level inserts. Each insert would be of the form insert into archive_xxxx (col1, col2, ..., colN) values (val1, val2, ..., valN) This insert statement is in the form of a string which we put together ourselves., using data values selected back from the database into a result set. The problem is that if the regional settings of the oracle database are such that floating point numbers use a comma instead of a full-top to represent the decimal point, a number such as 1234.56 becomes 1234,56 which looks like two fields in the above insert statement. For oracle, the decimal character is determined by the NLS_NUMERIC_CHARACTERS setting To make sure that we always use a full-stop instead of a comma we need to do alter session set nls_numeric_characters = ". " Probably the best place to do this would be in arcxport.init(), immediately after the call to dbconnect(): if ( dbconnect(strProg.szServerName, strProg.szDbName, strProg.szName, strProg.sz, 0) == FAILURE ) { fprintf(stdout, "FAILED TO CONNECT TO <%s> , <%s>\n", strProg.szServerName, strProg.szDbName); exit(-12); } #ifdef ORACLE exec sql alter session set nls_numeric_characters = "."; #endif This ensures that the change is only for the current session of arcxport. Component Likely Impact Incident No Affected Archive Server Low 102364 Problem Solution Details To make sure that we always use a full-stop instead of a comma we need to do alter session set nls_numeric_characters = ". " for each arcxport database session.

Issue No RES-1016

Description It is possible for two initiation events to use the same workflow_list_id value

Priority P2

Problem Reported The error the customer is getting is as follows: RULE FAILED:NO INITIATION ITEM What is happening is they have a scope rule which tries to make use of a 'Right Hand Side Initiation Attribute'. For this to work you must have an attached item in the entity_list table, and theirs has been deleted. The deletion occurs because the workflow server incorrectly inserts two rows in workflow_queue (with links to entity_list) with the same workflow_list_id value (which equates to two groups on entity_list with the same list_id value, so they appear as a single group). When the first job gets processed to completion by the workflow server it deletes all rows from entity_list for its value of list_id - and this also deletes the items which are really for the second job. When the second job is started we see the above error at the point the code looks for the (now missing) attached item(s). Component Likely Impact Incident No Affected Workflow Low 101629 Problem Solution Details Fix bug in the workflow server which allows successive initiation events to have the same workflow_list_id values.


71

Issue No Description Priority RES-1022 Currency server does not load FIXed length data P2 Problem Reported If the following parameters are used in the Currency server then no data is loaded. 'CURRENCY_PARAM' sFIX -1 -cl3 -rp5 -rl15 -dp20 -dl30 -ep4 -el1 -vp50 -vl1 -fp51 -fl8 -dfYYYYMMDD This is because the data was not being correctly split up. Component Likely Impact Incident No Affected Low 104264 Problem Solution Details Split the data correctly when using the FIXed length parameters

Issue No RES-1051

Description Workflow crashes when there are two rows with same stock_code, territory_code & +ve stock_id in stol

Priority P3

Problem Reported Stock aliases can be set up for ledger, statement or both sides. Workflow does not check the stol_type so it does not distinguish between these values. If one has been set up for statement and one for ledger then Workflow crashes because it was only expecting a single row. It needs to be changed to take the side of the item into Problem occurs in query at position SN_WORKFLOW_40 Note that just before this position in code there is s call to set_side_sign(comflds.ls_type); This will set comflds.side (Ledger/Statement) that can be used in changing the query to include selecting on stol.stol_type See SPR17584 and associated propose code for details of how this was fixed in SSR 7640. Component Likely Impact Incident No Affected Workflow 62177 Problem Solution Details Fixed as a side-effect of territory code enhancements.

Issue No RES-1068

Description GEMS errors if generic cash messages loaded with different currencies

Priority P2

Problem Reported When a message_feed is created, a currency_header for the currency of the message_feed/ is generated. When you load a message to a generic cash , GEMS will create a curency_header for the currency of the message if it does not exist. After two different currency_headers exist, GEMS will error on the next message loaded to that message_feed as there will be two rows returned for a single variable (singleton select error), when trying to determine the currency to use for the message. Component Likely Impact Incident No Affected GEMS Low 102865 Problem Solution Details Don't get the currency from currency_header but use the message currency or, if not specified, the bank currency for calculations

72


Issue No RES-1095

Description The deletion of rows from match_queue_header can produce on ora-1555 error on large databases

Priority P2

Problem Reported This concerns AAS when it is running the following SQL: DELETE match_queue_header WHERE (queue_id, proposed_match_no, corr_acc_no) IN ( SELECT DISTINCT qd.queue_id, qd.proposed_match_no, qd.corr_acc_no FROM arc_item ai, queue_detail qd WHERE qd.corr_acc_no = ai.corr_acc_no AND qd.gin = ai.gin AND ai.job_number = :b1) They are getting oracle error ORA-1555 (snapshot too old). This happens because the statement is not chunked-up, so the transaction can get arbitrarily large. The customer says that they have 120 million rows on match_queue_header and 230 million rows on queue_detail. Why don't we do this in chunks? The comment in the code says: "Unfortunately we can’t do the MQH count on a chunk basis else we end up counting QD items against a header more than once." This statement is true for the code which does the extract, but it is not true for the code which does the deletion. If we have two items having the same (queue_id, proposed_match_no) values but which are in different chunks, they will not cause the same row on match_queue_header to be counted twice because the second deletion will have nothing to delete. Also, there is no need to have a reference to match_queue_header.corr_acc_no in this statement, since it adds nothing. Therefore we should move the statement back inside the chunk processing and modify it as follows: DELETE match_queue_header WHERE (queue_id, proposed_match_no) IN ( SELECT DISTINCT qd.queue_id, qd.proposed_match_no FROM arc_item ai, queue_detail qd WHERE qd.corr_acc_no = ai.corr_acc_no AND qd.gin = ai.gin AND ai.job_number = :b1 and ai.chunk_number = Y) The original jira AAS-474 has been retrofitted into the main code stream for the oracle stored procedure (in revision 1.103), but we have yet to do it for Sybase and SQLServer. This jira is for AAS-474 to be retrofitted onto the AAS_TLM branch for Sybase and SQLServer. The original changes for AAS-474 were as follows: Component Revision stl_advarc_package.sql (oracle) 1.41.6.4 stl_advarc_procs.sql (sybase) 1.36.6.5 stl_advarc_procs.sql (sqlserver) 1.8.6.4 Component Likely Impact Incident No Affected Archive Server 100772 Problem Solution Details Modify delete statement so that its transaction is always bounded by the chunk size. Issue No RES-1107

Description AAS fails to archive a NET item that was released [without (and with) matching it against another item]. Therefore the originating items are not archived

Priority P2

Problem Reported When archiving cash net items (items that are created when you match two items which do not net to zero) , the Sybase and SQLServer versions of the AAS stored procedures do not work properly. This results in none of the items (i.e. the net items or the items which were matched to produce the net items) in the net chain being archived. Component Likely Impact Incident No Affected Archive Server Low 104318 Problem Solution Details Fix the Sybase and SQLServer version of the AAS stored procedures so that cash net matches are correctly archived.


Issue No RES-1110

73

Description Priority In some circumstances existing case numbers may not be reset P2 within workflow

Problem Reported In the following circumstances, workflow can retain information on existing cases A group of positions items are matched. A create case event is triggered. There is an existing case for the same case type & case amounts. The case type has close when reraise flag set. Either the case type does not have reraise same stock set or some other part of the workflow stops the case from being raised. In these circumstances, workflow may try to close cases in error if the next case raised is a non-positions case. It may try to close the same case again for subsequent non-positions cases until the next positions case resets the value. Component Likely Impact Incident No Affected Toolbox Low 105686 Problem Solution Details Ensure that the existing case number is reset in every path through the case create code Issue No RES-1132

Description Priority stlmqi_s on AIX not able to connect to a queue manager using P2 the MQ server libraries

Problem Reported stlmqi_s is able to connect to a queue manager using either the MQ server libraries (if installed) or the client libraries. On AIX these libraries are as follows: server library: libmqm.a client library: libmqic.a The code for stlmqi_s uses the unix dlopen() function to load the appropriate library at runtime, and we have given the wrong name for the library to search for. We have "libmqm.a(mqm.o)" as the library to search for, where it should be "libmqm.a(libmqm.o)". Component Likely Impact Incident No Affected STLMQI Low 104895 Problem Solution Details Change the code for stlmqi so that it can correctly find the MQ server library libmqm.a(libmqm.o) at runtime on AIX. Issue No RES-1133

Description Duplicate insert error when loading vabl records in a generic sub-

Priority P2

Problem Reported Occasionally when loading messages to a generic cash sub-, GEMS exits with a duplicate insert error. Component Likely Impact Incident No Affected GEMS Low 106367 Problem Solution Details Clear out cached value balance information at the end of every message to force a reread of the value balance dates

74


Issue No RES-1136

Description Cash value balances are not calculated in GEMS if item.amount is zero

Priority P3

Problem Reported If there is a generic schema where the cash amount is put into a field other than item.amount then the value balances may not be set up. This is happening because there is a check that item.amount is non-zero before calling the vabl processing functions with the generic amount. Component Likely Impact Incident No Affected GEMS Low 104416 Problem Solution Details Change check to ensure generic amount is non-zero instead of item.amount. Issue No RES-1137

Description Priority If there are more than 20 edit (or population) events operating P1 upon an item in a workflow, the workflow server can crash

Problem Reported Code produces spurious messages in the logs of the form: WORKFLOW01 Thu Jun 4 14:15:09 2009 INSUFFICIENT MEMORY TO INCREASE ((*item_: ((*item_update_data)->item+itemPos)->editEventSize = < WORKFLOW01 Thu Jun 4 14:15:09 2009 INSUFFICIENT MEMORY TO INCREASE ((*item_: 40> For each item in the edit event the code checks to see if that item has been processed by any earlier edit events in the workflow. If the item has been processed by an earlier edit event and this one is going to update a different attribute, it is at this point where we check to see if we need to do a realloc to get more memory to hold more edit events for the item. If we have already used 20 edit events (really 20 updates to distinct attributes), we need to do a realloc. Because we are checking the wrong pointer, it is possible to think that the realloc fails when it doesn't. This results in the edit event being aborted, and the next time we process an edit event the code can crash. Component Likely Impact Incident No Affected Workflow Low 104773 Problem Solution Details Fix bug in code to make sure that when there are > 20 edit (or population) events in a workflow, the code does not crash.


Issue No RES-1144

75

Description Priority WebConnect should the SSR approach to determining P2 the lead item for a cash release

Problem Reported Patch change onto HEAD. WebConnect should the option of using the SSR approach to determining the lead item for a cash release. This should be controlled by a SYST switch (defaulting to the existing TLM Online approach). The existing TLM online approach is to use the largest single item as the lead item. The approach used in SSR is as follows: 1. Accumulate the absolute amounts for the ledger-side and the statement-side for all items in the match. 2. Determine which side (ledger or statement) has the largest absolute amount. 3. Use the lead item (i.e. item with largest amount) from that side. Component Likely Impact Incident No Affected Database Schema Low 104944 Problem Solution Details The WebConnect release tool has been modified so that the setting of a SYST switch (NET_ITEM_SIDE_SSR) will cause WebConnect to use the SSR method to determine the lead item in the release group (and therefore net item type). The SSR method is as follows: 1. Accumulate the absolute amounts for the ledger-side and the statement-side for all items in the match. 2. Determine which side (ledger or statement) has the largest absolute amount. 3. Use the lead item (i.e. item with largest amount) from that side. The existing TLM online approach is to use the largest single item as the lead item. This will still be the default setting. Issue No RES-1145

Description Allow the s to recall net matches if the net item produced is still outstanding, but has seen other activity.

Priority P2

Problem Reported One of the issues for customer is the inability to recall net matches if the net item produced is still outstanding, but has seen other activity. In 2.6 we would have the option of the do-not-audit flag, but that is not available in 2.5SP1. This task is to build some switchable logic (i.e. SYST switch controlled) into Recall, so that in the situation where it knows it is recalling a Cash net match, it will only check the 'flag_2' status of the associated items (i.e. 'history' for the matched items and 'outstanding' for the created net item) instead of checking the 'event_group_id'. This way, the match can be recalled even if the net item has been edited or processed through a workflow tool, as long as it is still outstanding. Component Likely Impact Incident No Affected Database Schema Low 104944 Problem Solution Details A new SYST switch has been added to WebConnect that allows s to override the net item audit checks. If the SYST switch (ALWAYS_RECALL_NET) is switched on then the cash release recall process will ignore any subsequent audited actions on a net item created from the match. As long as the net item is still outstanding, the match will be recalled. Issue No Description Priority RES-1149 GEMS can crash if it finds a space in a security code P2 Problem Reported If there's a space in a security code at the fifth position and the rest of the security code is less than 12 characters long then GEMS can crash Component Likely Impact Incident No Affected GEMS Low 106293 Problem Solution Details Check string long enough before trying to process the twelfth character

76


Issue No RES-1158

Description It is possible to get two different negative stock_ids for the same stock

Priority P2

Problem Reported "Unknown stocks are loading with a different stock_id to existing stock_ids. Customer doesn't use aliasing, all stocks remain unknown, but if the stock exists it should be matched with that stock_id." Component Likely Impact Incident No Affected GEMS Low 100165 Problem Solution Details "Modify transaction handling when creating stocks" Issue No RES-1163

Description Priority AAS can get a primary key violation when running a Transaction if there are any matches which have non-zero P2 sec_match_no

Problem Reported The customer data has securities inheritance matches which means that you can have more than one match sharing the same sec_match_no. This brings with it the possibility that the same item can get extracted twice. There is some code which is supposed to spot any such duplicates and remove them but this code is failing, resulting in the duplicates making it through to the arc_item table. This causes a primary key violation and so the code crashes. The duplicate check fails because it uses a binary chop routine which assumes that the data is ordered. It turns out that this assumption is false, so the algorithm fails. The fix is to replace the binary chop algorithm with a simpler linear one, but only to actually check for duplicates when sec_match_no > 0. Since this is relatively rare in most cases the use of the slower linear search should be more than offset by the fact that we don't have to do it at all most of the time. Component Likely Impact Incident No Affected Archive Server Low 102993 Problem Solution Details Change AAS stored procedure so that it really does remove duplicate extracted items before trying to insert them into the arc_item table. Issue No RES-1166

Description AAS fails to extract data when running an Audit on oracle because the group being archived has many (>~ 10,000 rows) in it

Priority P2

Problem Reported Inside the code which handles the extract and delete jobs for an Audit , there is code which puts together a string which either contains a NOT IN() or an IN() clause. In both cases if there are many rows in the audit_trail group being archived, this clause may have more than 1000 in it. There is a limit of 1000 expressions in any IN() clause in Oracle (at least in 10g), so we must make sure we never hit this limit. Also, the string containing the SQL can have a maximum size of 32767 characters, so we must also make sure that we do not exceed this length. Component Likely Impact Incident No Affected Archive Server Low 103775 Problem Solution Details Make sure that the IN() or NOT IN() clause being used by the code is limited to 1000 expressions, and that the string containing the SQL is limited to 32767 characters.


Issue No RES-1176

Description GEMS copies stock_code to all items on a MT536 but it only copies the stock description for productised schemas

77

Priority P2

Problem Reported In an MT536 message the stock information is held at the message level. In productised messages, both the stock code and the stock description are copied to all items. In generic messages only the stock_code is copied Component Likely Impact Incident No Affected GEMS 64702 Problem Solution Details Copy the stock description as well as the stock code for generic messages Issue No RES-1177

Description Priority Gems fails to map all data from a feed file using kb mapping 'as "%[^\0]" if the column data contains the characters @ % ^ P2 or [. These characters are not mapped in to the system and all data after them is also not mapped.

Problem Reported Gems fails to map all data from a feed file using kb mapping 'as "%[^\0]" if the column data contains the characters @ % ^ or [. These characters are not mapped in to the system and all data after them is also not mapped. Problem needs fixing in gems in two places: gemskit.sc HandleSpecialChars() Here we need to catch any instances of format %[^\0] and replace with %[^\001] before the main part of the function that replaces these escape character sequences. gems.sc SplitFields() This needs to modify the line that generates the format specifier TmpFormat variable to use the same octal escaped non printing character as above (i.e. \001). Therefore line sprintf(TmpFormat, "%s%s%c]", Field[FieldIdx].As[i], "%[^", GemsChar); becomes sprintf(TmpFormat, "%s%s%c]", Field[FieldIdx].As[i], "%[^", '\001' ); Component Likely Impact Incident No Affected GEMS Medium 59546 Problem Solution Details Ensure gems can load data fields that contain characters @, %, [ and ^. Previous operation truncated the data at when encountering one of these characters Issue No Description Priority RES-1178 Always populate number of items on a message as in SSR P2 Problem Reported Original Enhancement Request: A Message Maintenance dashboard has been built but the functionality is different to that of SSR. Can a view be built that would include the following 's request: (3) We need to have the function to be able to view details lines on all pages (or a selection of ) in one view. The currently functionality will only let us view detailed lines on specific selected rows. This is not considered practical as it mixes information from different universes. The fallback position is to ensure that number of parts is always populated correctly on message_header so that the customer can see if there are any items on the message Component Likely Impact Incident No Affected GEMS Low 63686 Problem Solution Details Ensure number of parts is always set even if the message goes to Operator Intervention because of an early error

78


Issue No RES-1187

Description Priority The delete job on oracle for a Transactions category job which is archiving 'Not matched' items is only deleting the first chunk P2 of data

Problem Reported Inside the p_stl_DeleteItem() stored procedure for oracle we have the variable v_item_row never being reset after the first chunk has been processed. This results in the WHILE v_item_row < ITEM_BANK_TAB.LAST LOOP test immediately exiting for any chunk other than the first one. This causes only one chunk's worth of data to be loaded into the ARC_ITEM_TAB array, and from there into the arc_item table, which is used to do the to the item table to delete the data. Component Likely Impact Incident No Affected Low 100600 Problem Solution Details Reset the v_item_row variable to make sure that all chunks of data are deleted from the job. Issue No RES-1189

Description arcxport can put together a badly-formed piece of SQL when dealing with the note table

Priority P2

Problem Reported The SQL being put together by arcxport is as follows: insert into archive_note (corr_acc_no,gin,datetime,note_type,seq,match_no,note_code,notetext,notetext_2,notetext_3,notetext_4,_id ,_id1) values (100005853,43,'28/12/2007 11:55:tool01',3,1,0,'','testing workflow tool','','','','IIMCOB','') Server: Msg 241, Level 16, State 1, Line 1 Syntax error converting datetime from character string. From this we can see that there is a date field which says '28/12/2007 11:55:tool01', and this is clearly invalid. Component Likely Impact Incident No Affected Archive Server Low 104800 Problem Solution Details There is an uninitialised char[512] variable in the code, and this is probably the cause of the error. This variable should be initialised (set to blank) each time it is used.


Issue No RES-1192

79

Description Priority Jobs in AAS are not clearing up data from the arc_xxxx tables P2 once they have been purged

Problem Reported When an job in AAS has been both extracted and purged, AAS is supposed to remove any rows from the arc_xxxx tables for that job. To identify jobs which it can clear up it uses the following cursor select arc_queue.job_number,category,investigations_flag,lock_flg,audit_purge from arc_queue,arc_can where status=20 and (lock_flg = 0 or lock_flg = :iserver_lock) and arc_queue.job_number=arc_can.job_number The problem here is that at the end of the extract phase there is a bug which prevents the required row from being inserted into the arc_can table, so the above cursor finds no jobs to clear up. The bug which causes this is at the end of the DoExtract() function, where the following function call: iRet = IfSuspend(); overwrites the iRet variable, which makes the code behave incorrectly. In particular, it does not call the function CreateArcCan() to create the row in arc_can for the job. The fix is to make the iRet variable not depend on the result of the call to IfSuspend(), although we must handle the return value from IfSuspend() appropriately. This code is there to handle what happens if the has manually set a job to 'suspend' or 'abort' when the extract was running. If this is the case, the job does not move onto the next phase, it should be set to 'suspended' or 'aborted' as appropriate. Component Likely Impact Incident No Affected Archive Server Low 104637 Problem Solution Details Fix code which is there to handle what happens if the has manually set the job to 'suspend' or 'abort' when the extract was running. Issue No RES-1201

Description Priority A match group consisting only of ls_type of (180, 190, 179, 191) may find the same unresolved or exported case via the stock_id P2 of the lead item and via the individual items in the match. If this is so we get an error if the same case is closed twice.

Problem Reported We are talking about the case_resolve() function in eventproc.sc in the TLM2.100 code stream. We are calling case_resolve and the iCase variable is zero. We have a match group which consists entirely of ls_type = 180 and 190 items. As far as I can tell, this means that the posonly variable evaluates to true. Therefore what happens is we try to find all cases given by the resolve_hold_case cursor: Immediately after this we try to find all cases which involved the individual items in the match group, using the resolve_item_case cursor: Any cases which are found by these cursors are loaded into separate arrays which are later stepped through and the cases resolved. The problem seems to be that we are getting the same case being found by both of these cursors, and this causes the resolve_one_case() function to fail when it tries to resolve the same case a second time. Component Likely Impact Incident No Affected Workflow Low 61751 Problem Solution Details Failing to resolve a particular case because it is already resolved is not a failure - maybe, rather than failing because it can't find the unresolved case it should read the case, including the status, & just return success if it is already resolved - only fail if it fails to find the case at all.

80


Issue No RES-1202

Description SQL Error -207 AT 1414 ErrorText |

Priority P2

Problem Reported 1 running a Static called Static_test (all tables direct to Archive DB) ARCXPORT01 Tue Nov 04 14:30:32 2008 : No rows inserted into table #arc_keys from table entt| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Start of exportStaticTableToDatabase ARCXPORT01 Tue Nov 04 14:30:32 2008 : About to process table EVENT_DETAIL| ARCXPORT01 Tue Nov 04 14:30:32 2008 : szColumnList = event_id,attribute_id,data_string1,data ARCXPORT01 Tue Nov 04 14:30:32 2008 : _string2,event_desc,event_name,event_type,object_id,do ARCXPORT01 Tue Nov 04 14:30:32 2008 : _not_audit| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Dropped table #arc_keys| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Loaded 29 rows into table #arc_keys from table event_d ARCXPORT01 Tue Nov 04 14:30:32 2008 : etail| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Loaded 29 rows into table #arc_chunk for table event_d ARCXPORT01 Tue Nov 04 14:30:32 2008 : etail| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Executing query delete archive_event_detail from archi ARCXPORT01 Tue Nov 04 14:30:32 2008 : ve_event_detail arc, #arc_chunk loc where arc.event_id ARCXPORT01 Tue Nov 04 14:30:32 2008 : = loc.event_id| ARCXPORT01 Tue Nov 04 14:30:32 2008 : 27 duplicate rows deleted from table archive_event_det ARCXPORT01 Tue Nov 04 14:30:32 2008 : ail| ARCXPORT01 Tue Nov 04 14:30:32 2008 : Executing query insert into archive_event_detail (even ARCXPORT01 Tue Nov 04 14:30:32 2008 : t_id,attribute_id,data_string1,data_string2,event_desc ARCXPORT01 Tue Nov 04 14:30:32 2008 : ,event_name,event_type,object_id,do_not_audit) (select ARCXPORT01 Tue Nov 04 14:30:32 2008 : loc.event_id,loc.attribute_id,loc.data_string1,loc.da ARCXPORT01 Tue Nov 04 14:30:32 2008 : ta_string2,loc.event_desc,loc.event_name,loc.event_typ ARCXPORT01 Tue Nov 04 14:30:32 2008 : e,loc.object_id,loc.do_not_audit from event_detail loc ARCXPORT01 Tue Nov 04 14:30:32 2008 : , #arc_chunk arc where arc.event_id = loc.event_id)| ARCXPORT01 Tue Nov 04 14:30:32 2008 : SQL Error 207 AT 1414 ErrorText | Component Likely Impact Incident No Affected Archive Server Low 106230 Problem Solution Details Modify archive_views script for Oracle and SQLServer so that archive_event_detail view includes the do_not_audit column Issue No RES-1203

Description AAS can cause a primary key violation in the IAMT table when doing a purge or a delete

Priority P2

Problem Reported If more than one job extracts the same item (undesirable but perfectly possible), you can get a primary key violation in the IAMT table when that item is purged or deleted by the second of these jobs. This is because the code does not check that the item has already been deleted before doing the insert into IAMT. Component Likely Impact Incident No Affected Archive Server Low 106362 Problem Solution Details Only do an insert into the IAMT table when an item is actually being deleted.


Issue No RES-1204

Description If gems locks the bank table it is possible for the workflow server to break the primary key on workflow_queue

81

Priority P2

Problem Reported ABORTED-SQLCODE -1 AT 92 ErrText = ORA-0: ORA-00001: unique constraint (TLMDBO.WORKFLOW_QUEUE_IND_KEY) violated| For the primary key violation on workflow to occur we need the following: 1. Gems submits a job to workflow_queue with a lock_flg of 0. 2. Server instance N picks up the job and sets its lock_flg to 100+N. 2. While the first job has a status of 100+N gems submits a second identical job to the workflow_queue with a lock_flg of 0. 3. Then, the first job goes to 500+N because gems has locked bank for the . 4. Workflow starts to process the second job so sets its lock_flg to 100+N. 5. Gems still has bank locked for the so workflow tries to set lock_flg for the second job to 500+N and we get a primary key violation. Component Likely Impact Incident No Affected Workflow Low 63745 Problem Solution Details If workflow instance N is about to set lock_flg of a job to 500+N on workflow_queue, it should check to see if there is an identical row already there. If there is, the second job should be deleted. Issue No RES-1207

Description Pre-match aggregation in propose not coping correctly with multiple grouping columns

Priority P2

Problem Reported The pre-match aggregation logic in propose is only ever using a single grouping column even if multiple grouping columns have been defined. The logic is storing all the grouping data, but it allocates a new group-ref array element each time (instead of concatenating the data) & then points the reference array to the last element, losing the linkage to data from previous grouping columns for the same item. Component Likely Impact Incident No Affected Workflow Low 100341 Problem Solution Details Modify workflow code so it can correctly handle more than one grouping (non-matching) column within an aggregate population row in a . Issue No Description Priority RES-1208 Aggregation of dates in populations isn't working P2 Problem Reported If you have a population in a which is an aggregate population and the column to aggregate on is a date, you should be able to perform the following operations: COUNT MAX MIN PRINCIPAL There is a bug in the code which means that even though the aggregation will be done, the result will not be substituted back into the reference array. Component Likely Impact Incident No Affected Workflow Low 100341 Problem Solution Details Fix workflow code so that aggregation can be preformed upon date fields within aggregate-type populations.

82


Issue No RES-1210

Description The workflow server fails if you have a reference mask attached to a grouping column

Priority P2

Problem Reported The verbose logs show the following: <16:01:27.075:0> Combined Reference exceeds overall length The reference mask just extracts the first 10 characters from the reference. We can see that they are using a reference mask on a grouping column. The mask will not produce multiple references. The fact that we weren't incrementing this counter meant that we were always adding the reference to the same element of the (grouprefarr+giGroupInd)->combref The structure was overfilling. Component Likely Impact Incident No Affected Workflow Low 103687 Problem Solution Details Increment counter in code to denote that a grouping column is in use, even when reference masks are being used on that grouping column. Issue No RES-1220

Description Priority Productised cash s with redenominated currencies are P2 producing balance mismatch errors

Problem Reported If a message comes in on a productised cash with redenominated currency, then GEMS is putting the wrong currency on the balances. This was introduced in 2.6SP1 patch 9. Component Likely Impact Incident No Affected Low 106389 Problem Solution Details Re-instate check for existing currency_header currency which was removed as part of earlier patch but put check round it so it is only called for productised cash sub-s, instead of all cash sub-s Issue No RES-972

Description Implement delayed initiations via the workflow_queue table directly instead of going via job_schedule and using the schedule server

Priority P3

Problem Reported In SPR49023 we implemented a solution which would allow initiations called by gems to be delayed by a configurable amount of time. The solution involved gems inserting a row into the job_schedule table which specified when the initiation was to be processed. At this time the schedule server would insert the job into workflow_queue for the workflow server to process. Certain difficulties with this approach have since arisen, as described in H62794 and H62900, leading to the following proposed solution: We will add a new column called proposal_time to the workflow_queue table. The workflow server will henceforth only process jobs which have a proposal_time which is blank or in the past. When gems is processing a delayed initiation it inserts the job directly into workflow_queue, with proposal_time being equal to the current time plus the required delay. All other functionality to do with gems firing automatic proposal of jobs is maintained with this new solution. Component Likely Impact Incident No Affected GEMS 62900 Problem Solution Details We will add a new column called proposal_time to the workflow_queue table. The workflow server will henceforth only process jobs which have a proposal_time which is blank or in the past. When gems is processing a delayed initiation it inserts the job directly into workflow_queue, with proposal_time being equal to the current time plus the required delay.


Issue No RES-1015


83

Priority P3

Problem Reported Customer requires the ability to toggle whether the net item being created in release has an editable value date. This will be driven by a new syst switch. EDIT_NET_VALUE_DATE Default to 1 (true). Component Likely Impact Incident No Affected Database Schema Low 104327 Problem Solution Details Added syst flag. Issue No Description Priority RES-1029 Modified indexes required on vadj P2 Problem Reported Performance problem with Currency Value Adjusted Balances dashboard requires new index on vadj. index changes required amount to: ALTER TABLE VADJ DROP CONSTRAINT VADJ_IND_KEY; DROP INDEX VADJ_IND_KEY; ALTER TABLE vadj ADD CONSTRAINT vadj_ind_key PRIMARY KEY (corr_acc_no, value_date, gin) USING INDEX TABLESPACE tlm_index; CREATE INDEX vadjixa ON vadj (corr_acc_no, short_no, vtype, value_date, currency) TABLESPACE tlm_index; Component Likely Impact Incident No Affected Low 103683 Problem Solution Details Indexes altered on vadj and eadj Issue No RES-1032


Priority P3

Problem Reported Customer requires the ability to toggle whether the net item being created in release has an editable value date. This will be driven by a new syst switch. EDIT_NET_VALUE_DATE Default to 1 (true). Component Likely Impact Incident No Affected Database Schema Low 104327 Problem Solution Details Added syst flag.

84


Issue No RES-1049

Description Add a new SYST setting to set a maximum number of Trial Balance sets

Priority P3

Problem Reported Add the following SYST setting to the Smart Data: INSERT INTO syst (syst_name, syst_value, syst_mtype, description, syst_title, syst_type) VALUES ('TRIAL_BAL_SET_LIMIT', 1000, 3, 'Maximum allowed s in a Trial Balance search', 'Trial Balance set search limit', -4) Component Likely Impact Incident No Affected Low 103428 Problem Solution Details A maximum number of sets can be specified in the new SYST setting: 'Trial Balance set search limit'. The default value is 1000. If the SYST value is missing then it is unrestricted. If a Trial Balance search will be calculating Trial Differences for more s that the maximum (even if some sets are subsequently filtered out), then the will be prompted to change the search criteria. This prevents excessively large searches being run that will harm the application server performance. Issue No Description Priority RES-1054 Enh to GEMS for ISIN and field 35: P2 Problem Reported CUSTOMER ISSUE: We're having some problems in the load of swift files for securities positions. The problem comes when the field :35B: contains errors in the file. This is a well-formed :35B: field :35B:ISIN PTSMCAOE0000 SOMEC/94 :90B: [...] GEMS checks that there is a blank on 5th position on the field an loads the next 12 chars (PTSMCAOE0000) on sfield_8 of database (ISIN). Then loads the following line on sfield_9 (ISIN description), all OK. sfield_8 = PTSMCAOE0000 sfield_9 = SOMEC/94 Now, this is what happens when we receive a wrong file: :35B:SGO-SANTOS GUIM. OLIVEIRA :90B: [...] There is no ISIN, we receive the description on :35B: and GEMS loads it on sfield_8. We think that GEMS should left sfield_8 with blank instead of taking the description like an ISIN. It also loads the same on sfield_9 as description. sfield_8 = SGOSANTOS GUIM. OLIVEIRA sfield_9 = SGO-SANTOS GUIM. OLIVEIRA Another example, we receive a file with the next: :35B:DOWA HOLDINGS CO.,LTD.SHARE SUBSCRI PTION RIGHT (COUNTRY:JAPAN ) :90B: [...] In this case GEMS loads HOLDINGS CO. on sfield_8, we suppose that in this case GEMS checks that there is a blank on 5th position and takes the next 12 chars as the ISIN. Then loads the next two lines on sfield_9 as a description. Once again we think that GEMS should left the ISIN with blank as there is no word "ISIN" on the field. sfield_8 = HOLDINGS CO. sfield_9 = PTION RIGHT (COUNTRY:JAPAN ) Line of the file host affected: invswift local:/opt/apps/cdc/tlm/var/ft/in/TITULOS_INVESTMENT invswift.trg:static norm BSCH_Ref_Internal /opt/apps/cdc/tlm/var/ft/hold/TITULOS_INVESTMENT GEMS FD_PURESWF_MapISOSec nocr tlmdbo@dtlmr/dbodes: Component Likely Impact Incident No Affected GEMS Low 104223 Problem Solution Details If msghdr.free_int is set to 1 (using split into If msghdr.free_int as "@1" in the kb file) then the stock code mapping functions will look for specifically "ISIN " at the beginning of the the stock code line, instead of looking for any four characters followed by a space


Issue No RES-1173

Description There are several ways in which the workflow server can exit from the proprule() function with a -1 return value. We need to distinguish between these.

85

Priority P2

Problem Reported There are several ways for the proprule to exit with a -1 return value. When this happens we always get a message in the logfile of the form: BAD RETURN FROM PROPRULE: <xxxxxxxxx> h_return<-1> We need to be able to say exactly which condition produced the error. To do this, simply make sure that all conditions which produce this error always put something in the log. There are essentially only two mechanisms which need to have this done - bank being locked, and workflow_queue not updatable. Component Likely Impact Incident No Affected Workflow Low 102385 Problem Solution Details Modify workflow code so that it outputs additional information about a common error message in the logs. Issue No RES-1174

Description Add new functionality to bb.sc to output the contents of the schema if there is a failure in the get_object_id() function

Priority P2

Problem Reported We have a customer who is getting many occurrences of the following error message in the upper-case workflow logs: WORKSP0111 Mon Jan 5 11:04:32 2009 ERROR RETRIEVING OBJECT ID. : <10050> Pop <1> Item Gin <5441721> ls_type <90> WORKSP0111 Mon Jan 5 11:04:32 2009 BAD RETURN FROM PROPRULE: <100000126> h_return<1> We have not been able to diagnose the cause of the error so we have decided to add some new functionality to bb.sc which calls the existing function output_bb() whenever there is an error inside get_object_id(). This function will output all schema-related arrays currently help in memory. Component Likely Impact Incident No Affected Toolbox Low 102513 Problem Solution Details Add new code out output all schema-related data in memory at the time an error occurs in the get_object_id() function. Issue No RES-1175

Description Server Manager does not handle spaces in the default installation path

Priority P2

Problem Reported The default installation folder is now specified as C:\Program Files\ etc The space causes the file C:\program to be created in root directory. This causes Windows and Server Manager many problems when restarting or using some of the Windows Services. Component Likely Impact Incident No Affected Server Manager Low 60254 Problem Solution Details N/A - Issues were already fixed in TLM2.6 under SDS-41

86


Issue No RES-1185

Description Default case counterparty to counterparty of lead item when no extended customer data

Priority P2

Problem Reported When a case is created, default the case counterparty to match the counterparty on the lead item when there is no customer extended data present. If there is cust_data, use the counterparty information from this instead. Component Likely Impact Incident No Affected Toolbox Low 61504 Problem Solution Details Set the counterparty to match the item counterparty and overwrite with customer extended data if present on a third party case. Issue No RES-1188

Description Priority Edit components can be processed in an order which is different to the order in which they are displayed on screen in P2 the edit event.

Problem Reported The edit components for an edit event aren't being processed in the correct order. The first component is the one involving filter 'VR-FNMA LOAN', which has id = 10014. The log shows that we are processing filter 10015 first, and this is filter 'VR-SERVICER LOAN', which is associated with the second component. If we run the following SQL to see which edit components are associated with population event 10312, we get: select olk.key_type, olk.object_list_id, ol.id, ec.item_filter_id, operator, position, source_attribute from object_list_key olk, object_list ol, edit_component ec where olk.object_list_id = ol.object_list_id and ol.id = ec.id and olk.object_list_role = 33 and olk.key_value in (10312) order by olk.key_value; which gives us KEY_TYPE OBJECT_LIST_ID ID ITEM_FILTER_ID OPERATOR POSITION SOURCE_ATTRIBUTE ------------------------------- -------------- ---------- -------------- ---------- ---------- ---------------EDIT_EVENT_COMPONENT_LIST 15815 11348 10015 2286 2 5163 EDIT_EVENT_COMPONENT_LIST 15815 11349 10014 2287 1 5163 So even though the components list a position for each one, they seem to be processed in order of ol.id rather than position. The logfile bears this out: <16:53:15.176:0> PROCESSING EDIT EVENT: id = 10312 <16:53:15.176:0> In read_lists for role <33> <16:53:15.176:0> In add_new_list Index = <0> <16:53:15.176:0> Input List <15815> Key1 <10312> Key2 <0> Key3 <0> <16:53:15.176:0> Array pointer is NULL <16:53:15.176:0> List <15815> added. Role <33> Key1 <10312> Key2 <0> Key3 <0> <16:53:15.177:0> Get properties for list <15815> <16:53:15.177:0> List <15815> - First element - List <15815> ID <11348> - No of elements <2> <16:53:15.177:0> Ordered list of lists (Role <33>) <16:53:15.177:0> List <15815> Sequence No <99> Therefore what happens is we process the second component first, followed by the first. The component which is actually processed first will always use OP_EQUALS as its operator, since there is no prior component to supply the operator. Our problem is that the second component to be processed takes its operator from the first component to be processed. In our case, the first component to be processed is the second component as it appears in the event, and this has an operator of + by default. It looks like this data was produced by CI having done an import of a workflow which was setup somewhere alse. Whenever you create an edit event from scratch theh components seems to be ordered in the same sense as object_list.id. Steve Flower said: We do need workflow processing to be able to process the components in the same order that the sees them on screen. The only really safe way to do this will be to use the position to order the components - so I think workflow will need to change the way it reads the data, though I think that is going to be a messy little change inside the list-reading routines. Component Likely Impact Incident No Affected Workflow Low 62157 Problem Solution Details Change the workflow/toolbox code so that the workflow server always processes edit components in the same order as how they are displayed onscreen in the edit event.


Issue No RES-1198

Description Implement delayed initiations via the workflow_queue table directly instead of going via job_schedule and using the schedule server

87

Priority P2

Problem Reported Additional work required for delayed initiations. We will add a new column called proposal_time to the workflow_queue table. The workflow server will henceforth only process jobs which have a proposal_time which is blank or in the past. When gems is processing a delayed initiation it inserts the job directly into workflow_queue, with proposal_time being equal to the current time plus the required delay. All other functionality to do with gems firing automatic proposal of jobs is maintained with this new solution. Component Likely Impact Incident No Affected GEMS Low 62900 Problem Solution Details We will add a new column called proposal_time to the workflow_queue table. The workflow server will henceforth only process jobs which have a proposal_time which is blank or in the past. When gems is processing a delayed initiation it inserts the job directly into workflow_queue, with proposal_time being equal to the current time plus the required delay. Issue No RES-1209

Description Workflow engine's processing order is based on priority and corr_acc_no. It should use the workflow propose time field to allow for FIFO (first in, first out) processing

Priority P2

Problem Reported Enhancement for workflow processing to have workflow leverage the workflow propose time field to allow for FIFO (first in, first out) processing, instead of processing by corr_acc_no. This should be the same whether the data is automatically submitted or manually submitted for proposal. Component Likely Impact Incident No Affected Workflow Low 100111 Problem Solution Details At present the ordering criteria for jobs to be selected from workflow_queue is by lock_flg desc, priority, corr_acc_no. This will be changed to lock_flg desc, priority, proposal_time asc

88


Issue No RES-1169

Description Enhancement Request for a new KB function to multiple the original value by 100

Priority P2

Problem Reported PS would like to propose a simple solution for 8 decimal place matching without changing the global setting. Basically, a factor (:92A::CUFC) is a number between 0 and 1. If this number is multiplied by 100, then we will get a new number between 0 and 100, but only up to 6 decimal places. This new number could used for matching/calculation/comparison and give the same matching output. The only thing we need is that Development provide a very simple KB function that return the original amount times 100. Then GEMS could call this KB function to convert the original amount to a new value and store the new value (up to 6 decimal places) in an amount field while loading. Component Likely Impact Incident No Affected GEMS Low 104537 Problem Solution Details Add a new function Gms_MultiplyByFloat. This will multiply the value ed in by the value in msghdr.free_float. The way to use this is to put a default value into msghdr.free_float and then map the value required, calling the function. For example split into msghdr.free_float as "@100", item.amount_17 as "%lf" using Gms_MultiplyByFloat Issue No RES-1183

Description Could it be possible into AAS 3.2 adding a new "Date" for a Transaction for match type "Not Matched" to filter the items to archive?

Priority P2

Problem Reported The problem is the following one: If we create a Transaction for Matched Items, the system checks for the trns.match_date and then goes through the items associated to every match selected in order to choose the data that can be archived or not. The Client for several products is not using queues to match items, when a match is generated only the match_no (set as the max(gin) ) is updated into the item table. That means they won't have any entry into the table trns for those matches, that doesn't allow the possibility to archive those products filtering for matching date. The only way in that case is to create a Transaction with a "Not Matched" match type, using the System Entry Date or the Statement Date at Item Level, that avoids the possibility to archive for matched groups. For Example: Item1 : sys_entry_date = 20-10-2008, Match_no= 200 ,flag_2=1 Item2 : sys_entry_date = 20-02-2009, Match_no= 200, flag_2=1 Transaction with a Date Range based on a sys_entry_date into a Range from 20-09-2008 to 20-01-2009. If we run a job associated to the Transaction above on 22-02-2009, it will only archive item 1 and will keep item 2 on the Active DB. Could it be possible into AAS 3.2 adding a new "Date" for a Transaction for match type "Not Matched" to filter the items to archive? Could it be possible to obtain it by changing the Stored Procedure (i.e. "p_stla_ExtractItem") or does it have any other impact? As general question, in order to put some others criteria for archiving or changing the existing ones, could it be possible by changing the stored procedures provided for the AAS system? Component Likely Impact Incident No Affected Archive Server 103216 Problem Solution Details Allow the use of a new SYST setting to define a date column to drive the archiving process when we have Match Type = 'Not Matched'.


89

Issue No Description Priority RES-1186 Resolved cases are not working in the customer’s system P2 Problem Reported Resolved cases are not working in the customer’s system Component Likely Impact Incident No Affected Toolbox Low 104326 Problem Solution Details Change the 'Resolve Case' Event so that if we have an exported case for which the X_EXPORT_TYPE syst setting is not set to 'STANDARD', set cast.status to 'WAITING' rather than 'ACKNOWLEDGED'. Issue No RES-1199

Description Modify initiation events to insert the current 'Event Date' attribute into workflow_queue.event_date instead of today's date

Priority P2

Problem Reported The workflow server defines its 'Event Date' attribute to be equal to the current value of workflow_queue.event_date. It is required that when a workflow server processes an initiation event, the value of workflow_queue.event_date it inserts is also equal to the current 'Event Date' attribute, so that it is ed on to successive initiaitons. However, initiation events currently insert today's date into workflow_queue.event_date when they insert their row into workflow_queue. Therefore if a first initiation had an 'Event Date' which was taken from the statement date of the message feed as processed by gems, this date will be lost in any successive initiations called by initiation events if its 'Event Date' is different from today's date. We will therefore modify the initiation event so that it inserts the value of the current 'Event Date' attribute into workflow_queue.event_date. Component Likely Impact Incident No Affected Workflow Low 63629 Problem Solution Details Modify the initiation event so that it inserts the value of the current 'Event Date' attribute into workflow_queue.event_date. Issue No RES-1200

Description Priority Enable the aas file aas_archive_database.properties P2 to reside on the database server

Problem Reported There are two issues installing/running AAS 3.2 for TLM2.5 SP1. 1. Seems that the stl_advarc_package.sql does not cater for Oracle LDAP connection strings when using the aas_archive_database.properties file to get the connection parameters. An LDAP connection string cannot be entered in the requested URL format in the aas_archive_database.properties. To overcome this, we had to hard code the connection string in the stl_advarc_package.sql to enable a connection. 2. Customer policy is to not allow applications to run on the Oracle database server. This meant that the aas_archive_database.properties file cannot be located. To overcome this, we had to hardcode the file location in the stl_advarc_package.sql to overwrite the mandatory $TLM_HOME/cfg location. No $TLM_HOME exists on the database server. These changes have overcome the immediate issues but would need to be addressed by STL for a able resolution. Component Likely Impact Incident No Affected Low 106190 Problem Solution Details A new SYST setting called 'ARCHIVE_PROP_PATH' has been created to allow the custom definition of the location of the file aas_archive_database.properties which is used by AAS on Oracle.

90


Issue No Description Priority RES-1206 Allow tolerance matching to work with pre-match aggregation P2 Problem Reported Currently the pre-match aggregation of data can't work with declared tolerances on the match columns - the aggregated amount is only substituted back into the reference array after the tolerance processing has happened. We need the tolerance match logic to be able to work on aggregated data, generating two versions of the calculated amounts/dates as they are put back into the reference array. Component Likely Impact Incident No Affected Workflow Low 63365 Problem Solution Details Allow tolerances to apply to aggregated results

7.5

SmartStudio

Issue No Description Priority SMA-2967 Performance changes to latent networks P2 Problem Reported Improve the speed of the application start-up and make it more resilient to network failures. Component Likely Impact Incident No Affected Client , Server Low 105759 Problem Solution Details Performance improvements have been made which should affect the loading of SmartStudio clients on slow networks. Issue No SMA-2938

Description SmartStudio has no concept of Private Views, and so there is an upgrade issue between 2.6 and 2.7

Priority P2

Problem Reported There is an issue where WebConnect still has the concept of Private and Public views, whereas SmartStudio does not, and this causes confusion where private views are available within WebConnect, but cannot be seen in SmartStudio. We need to establish an upgrade mechanism to migrate private views over to public views. This can be done either by making use of the current SmartStudio data migration solution, or via the standard upgrade scripts. Component Likely Impact Incident No Affected Client Low 105758 Problem Solution Details An optional upgrade script has been added which will convert private views into public views.


91

8 Known Issues Known issues are bug fixes found during testing of the current version of each component, which do not fully address an issue and have been failed by Quality Assurance. These outstanding issues have a straightforward recommended workaround, or are felt to be of limited impact to the majority of s. They will be addressed in a future release.

8.1

WebConnect

Issue No WBC-3686

Description Priority Problem with Chart Controls having apostrophes in P2 name

Problem Reported Customer had a problem with some upgraded dashboards (from their 2.1SP1 environment) not opening. They noticed that a common factor seemed to be the use of apostrophes in the name of the control - they listed the issue against a Chart control, but it may affect others. It seemed that when they removed the apostrophe the control worked OK. Recommendation Avoid using apostrophes and any other special characters in control names. Issue No WBC-3721

Description Exception error when drilling down to child dashboard if drilldown was previously cancelled when auto launched.

Priority P2

Problem Reported Build Version: 2.7 SP1 build 8 Pre requisite - a parent dashboard with grid control has a child dashboard with a grid control with the following set: each time Launch of parent Parameter mappings to Dashboards' menu then Signed Amount CASH DASH1' dashboard. Click on the Search button at the Parent dashboard when prompted. At the Child search prompt, click on the Cancel button. Now manually select a row in Parent dashboard, right-click and select child drilldown. WebConnect returns an error. Recommendation Do not cancel the search prompt. If this problem occurs, close and reopen the parent dashboard, then perform the drilldown again. Issue No WBC-3734

Description Priority Audit trail for Case Resolved shows as Case Raised (when using Case Resolved on Set-based Release P2 Workflow)

Problem Reported In Recon attach Case80_resolve to Set-based Release Workflow (on Set = SMOKE_535) [use a workflow rule of Count(GIN) > 0]. Open dbd = Securities Ad-Hoc Item Search (Web) with Set = SMOKE_535 Release Group [21, 16, 2, 3, 52, 57]. Cases 990 & 991 correctly Resolved. However the audit trail then shows Case Raised. Recommendation None. This issue requires further investigation and will be addressed in a future release.

92


Issue No WBC-3733

Description Case Resolve is not executed or audited when fired against items

Priority P2

Problem Reported Open dbd = Securities Ad-Hoc Item Search (Web) with Set = SMOKE_535 Execute the Case80_tool on Group [21, 16, 2, 3, 52, 57]. It is expected that this will: 1. Be audited on the items. 2. The cases 990 & 991 will be resolved. Neither of these happen. However, if you attached Case80_resolve to Set-based Release Workflow (on Set = SMOKE_535) [use a workflow rule of Count(GIN) > 0] then the cases are resolved. There is still an issue with the audit trail when this is done (please see WBC-3734) Recommendation None. This issue requires further investigation and will be addressed in a future release. Issue No WBC-3762

Description Priority Child Form refreshes as empty after inserting a row P2 on the parent

Problem Reported 1. Created a message routing parent grid that drilled down to a child form 2. The child form is set on Subsequent Refresh of Parent 3. When I insert a message routing row on the grid and click save, the child form is refreshed. - However, it displays as empty. Same also occurs when a row is deleted in the parent. Recommendation Following an update of a parent grid, if a child form goes blank refresh the child form manually so that it displays the correct data. If the Refresh child on subsequent refresh of parent option is set for the dashboards, manually refreshing the parent will also refresh the child. Issue No WBC-3771

Description Message Routing: java.lang.NullPointerException creating two message routing rows

Priority P2

Problem Reported Issue creating two message routing rows. Create row 1 as an Action = Ignore for From Message Feed Type = Our Cash Settlements (see attached) Create row 2 the same but as an Action = Delete for From Message Feed Type = Their Cash Settlements Save Now edit row 2 to have Action = Ignore and the error occurs on Save Recommendation Only occurs with message routing. Always refresh your dashboard after saving an insert or edit. Issue No WBC-3773

Description Message Routing - Validation in WebConnect different to Recon

Priority P2

Problem Reported 1. In WebConnect I can create the following message routing record: Feed: 123 Action: Delete From Type: Their FX Option To type: Broker Call In Recon , I am stopped from entering a To Type if the Action is either Delete or Ignore. Recommendation Ensure that you do not enter a To Type if the Action is either Delete or Ignore.


Issue No WBC-3751

93

Description Priority Release of items where Reference 1 is not defined is P3 treated differently in Sybase (cf. Sqlserver)

Problem Reported Using identical data on Sybase and Sqlserver. Running the Smoke test, Smoke test - Net to Net matching (optional): Load the data: LDGRFEED 940LDGRFEED :25:TEST_NETTINGL_1 :28C:1/001 :60F:C040501EUR0, :61:040501040501D1000000,TRAN//TEST :61:040501040501D500000,TRAN//TEST :61:040501040501C1000,TRAN//TEST :62F:D040501EUR1499000, $ STMTFEED 940STATFEED :25:TEST_NETTINGS_1 :28C:1/001 :60F:D040701EUR1499000, :61:040701040701C400000,TRAN//TEST :61:040701040701C503000,TRAN//TEST :61:040701040701C589000,TRAN//TEST :62F:D040701EUR7000, $ to suitable Our Cash Settlement (Ledger) and Their Cash Settlement message (Statement) feeds on a new Cash Set, currency = EUR. Set the Set > Financial Parameters > Charge Limit (Debit and Credit) to 100. In > Access and Limits: Set the Limit Cash - Credit Netting = 100 Set the Limit Cash - Debit Netting = 100 Check that the syst setting of allow the creation of statement net items (CREATE_STMNT_ITEMS) is set to 1. If you have to change it, you will need to restart the app server. Make sure you know the id and of another which has the default access and limits set to high. This will be needed to give supervisor approval for the creation of any netting items > 100. Data Feeds Test Steps Action 1. Release item GIN = 2 (amount = 400,000) with item GIN = 3 (amount = 1,000,000). When Release Interaction screen is displayed, set Netting item type to Ledger Netting item if necessary. Enter id and of supervisor . Enter value for reference1. On Sybase the is *not prompted* for Reference 1, on Sqlserver this is mandatory Recommendation None, however, that this is an unlikely scenario as Reference 1 is usually populated.

8.2

Design Studio

Issue No DST-1297

Description Priority Error "Invalid expiry date or next change P2 date" when changing lead authority for a .

Problem Reported TLM Design Studio Version DS 2.7 Build 2.7.37 Error "Invalid expiry date or next change date" when changing lead authority for a . Changed to p2 because i can't save changes. Recommendation This is only an issue for s who have ' expiry date/next change date' configured. Issue No DST-1301

Description Priority Problem in Product Version Audit where incorrect data is displayed within the Database Installation P3 History tab

Problem Reported There is an issue within the Database Installation History tab, where patch files are being shown as applied to an incorrect patch. This however, should not have an impact on the component determining compatibility with the database overall. Recommendation For more accurate data, see the contents of the product_version_audit table.

94


Issue No DST-1307

Description Custom system messages set in front end write to emsg not ds_emsg

Priority P3

Problem Reported Custom system messages set in front end write to emsg not ds_emsg. CMsgs.loadEmsgs reads all messages with id < 10000 from ds_emsg but altering the message using the front end edits the version stored on emsg and therefore has no apparent effect. Recommendation None. This issue requires further investigation and will be addressed in a future release.

8.3

SmartData Services

Issue No SDS-405

Description Priority No default value binding for soft_lock_key attribute P2 for Sybase database.

Problem Reported The dbcreate_smartdata.sql script for Sybase database does not contain default value binding for soft_lock_key attribute of role_header table. This issue does not allow to do CI import on Sybase database. Recommendation None. This issue requires further investigation and will be addressed in a future release. Issue No SDS-423

Description Priority Error "No match for TLM Version 'TLM2.800' on syst found in configuration file" when trying to log P2 into the latest CI 3.4 build.

Problem Reported Error "No match for TLM Version 'TLM2.800' on syst found in configuration file" when trying to to the latest CI 3.4 build. Recommendation None. This issue requires further investigation and will be addressed in a future release. Issue No SDS-429

Description TLM2.7SP1 - csvload - trace/memory messages displayed after load

Priority P2

Problem Reported When csvload is used on our suse10 server (may be other platforms but only suse10 used so far) error messages are displayed after the load has successfully complete. We already have a note in the guide informing s to ignore the "glibc detected " message but we have encountered the additional errors. Also, when csvload was run against smartdata refdata and the error was displayed, csvload did not terminate correctly, it just hung. when loading refdata for recon the trace was displayed but it did terminate cleanly. Recommendation You can ignore these errors, csvload does load the files successfully.


8.4

95

Recon Services

Issue No RES-1264

Description Item Reference 1 is mandatory for Manual Input (GMI), but you can load data with GEMS that has no Item Reference 1

Priority P3

Problem Reported The feed is: LDGRFEED 940LDGRFEED :25:TEST_NETTINGL_1 :28C:1/001 :60F:C040501EUR0, :61:040501040501D1000000,TRAN//TEST :61:040501040501D500000,TRAN//TEST :61:040501040501C1000,TRAN//TEST :62F:D040501EUR1499000, $ STMTFEED 940STATFEED :25:TEST_NETTINGS_1 :28C:1/001 :60F:D040701EUR1499000, :61:040701040701C400000,TRAN//TEST :61:040701040701C503000,TRAN//TEST :61:040701040701C589000,TRAN//TEST :62F:D040701EUR7000, $ The test where it is loaded is: Smoke test - Net to Net matching (optional) The assumption is that it is highly unlikely a customer has no Item Reference 1 defined - as this field is Mandatory for SWIFT. Recommendation None, however, that this is an unlikely scenario as Reference 1 is usually populated.

Tlm Recs 2.7 Sp1 3c226n

Overview 3e4r5l

More details w3441

Related Documents 3m3m1z

Tlm Recs 2.7 Sp1 3c226n

Tlm 705h4a

Saved Recs 5mr4i

Saved Recs 5mr4i

Tlm Measurements zy2l

Systemc Tlm j3o5a

More Documents from "Shankar Narayanan" 4f3r6t

Standards For It Park 1h1w61

Tlm Recs 2.7 Sp1 3c226n

Automatic Welding Machine 1u6v6a

Malayalam Alphabet, Pronunciation And Language 214f19

Telugu Alphabet, Pronunciation And Language 1i167

Lalitha Navarathna Malai - Lyrics _ Devotional Mp3 62g39
