400kv Substation Training Report 5rd3a

-Shailendra Yadav EE-42(0705420096) 1

INTRODUCTION OF SUBSTATION It is situated at 26°34’2’’N & 80°32’57’’E coordinates in Dahi Chowki 6.64 km far from Unnao railway station. Constructed during 1994-98 by CGL. The whole substation is divided in three parts: 132kv switchyard 400/220kv switchyard 765kv switchyard (Under construction)

2

INCOMING & OUTGOING LINE OF SUBSTATION •Unnao to Lucknow (400KV & 220KV both separate) •Unnao to Bareily-1 (400KV) •Unnao to Bareily-2 (400KV) •Unnao to Agara (400KV) •Unnao to Panki Kanpur(400KV & 220KV both separate) •Unnao to Anpara (400KV) •Unnao to PGCIL Lucknow-1 (400KV) •Unnao to PGCIL Lucknow-2 (400KV) •One bus bar for 400/220KV 315MVA ICT-1 & ICT-2 line.

3

OUTDOOR EQUIPMENT USED IN SUBSTATION           

Two 100MVA 220/132KV transformer Two 315MVA 400/220KV transformer Shunt reactor Capacitor bank SF6 circuit breaker Isolators Lightning arresters Current transformer Capacitor voltage transformer Wave trap Isolators

4

ConservaterTank

Transformer

H.V. side bushing CT

COOLING SYSTEM (ONAN)

L.V. side bushing CTs 5

Radiator plates

Oil pump is used for circulating oil forcelly. Radiator plates are used for increasing surface area for natural air cooling.

Oil pump

Earthing plate

6

COOLING FANS

 we use Cooling fans for forced air cooling of transformer . Total six fans are used for each 100MVA and eight fans are used for each 315 MVA transformer. But all fans never start at same time . It start in pairs .

7

Tertiary terminal

Tertiary terminal mostly opened. The output voltage of tertiary terminal is 11KV in 100MVA transformer and 33KV in 315 MVA transformer OLTC chamber

Pressure relief valve box

8

TERMINALS ON TANK COVER

9

In these photos we can see fogging near transformer due to operation fire protection system.

10

BUCHHOLZ RELAY Buchholz relay is a safety device mounted on some oil-filled power transformers and reactors. It is used as a protective device sensitive to the effects of dielectric failure inside the equipment.

11

OTI & WTI OTI

WTI

OTI –oil temp. indicator measure temp. of oil filled in transformer. In OTI has two mercury bulb. WTI- winding temp. indicator measure winding temp of transformer. It has four mercury bulb. mercury bulb

12

CURRENT TRANSFORMER In electrical engineering, a current transformer (CT) is used for measurement of electric currents. Current transformers, together with voltage transformers (VT) (potential transformers (PT)), are known as instrument transformers. When current in a circuit is too high to directly apply to measuring instruments, a current transformer produces a reduced current accurately proportional to the current in the circuit, which can be conveniently connected to measuring and recording instruments.

13

PROTECTION DIAGRAM

14

CAPACITOR VOLTAGE TRANSFORMER A capacitor voltage transformer (CVT) is a transformer used in power systems to step-down extra high voltage signals and provide low voltage signals either for measurement or to operate a protective relay. The device has at least four terminals, a high-voltage terminal a ground terminal and at least one set of secondary terminals. CVTs are typically single-phase devices 15

Cross sectional view of CVT 1 - Primary terminal 2 - Cast aluminum bellow housing 3 - Stainless steel expansion bellow 4 - Compression spring 5 - Insulated voltage connection 6 - Capacitor elements 7 - Insulator (porcelain or composite) 8 - Voltage divider tap connection 9 - Cast-epoxy bushing 10 - HF terminal connection 11 - Ferro-resonance suppression device 12 - Secondary terminals 13 - Oil level sight-glass 14 - Aluminum terminal box 15 - Intermediate transformer 16 - Oil/air block 17 - Oil sampling device 18 - Compensating reactor 19 - Aluminum cover plate

16

PRINCIPLE CIRCUIT DIAGRAM OF CVT 1. High Voltage terminal 2. Compensation reactor 3. Intermediate voltage transformer 4. Ground terminal 5. Ferro-resonance suppression device 6. Damping resistor 7. Carrier (HF) terminal (optional) 8. Overvoltage protective device 9. Secondary terminals 10. Link, to be opened for test purposes

17

CIRCUIT BREAKER A circuit breaker is an automatically-operated electrical switch designed to protect an electrical circuit from damage caused by overload or short circuit. In this image we can see a SF6 circuit breaker with double break system.

18

ISOLATORS An isolators switch are used to completely deenergized an electrical circuit. High-voltage isolation switches are used in electrical substations to allow isolation of apparatus such as circuit breakers and transformers, and transmission lines, for maintenance.

Isolating rod

Earth link rod

19

PANTOGRAPH ISOLATORS In open state

In close state

20

Central rotating double break isolator

21

Wave trap  Wave trap are used in power system for carrier communication.  It trap the higher frequency above 50Hz.  It is the effort to utilize the same transmission line between two substation for the purpose of communications

22

23

LIGHTNING ARRESTOR The overvoltage protection is obtained by the use of lightning / surge arresters. Lightning Arresters or Surge Arresters are always connected in Shunt to the equipment to be protected, they provide a low impedance path for the surge current to the ground. Mostly in present days zinc oxide (ZnO) gapless arresters are in use. 24

INTERPOSING C.T. The interposing CTs are used for Power transformer Differential Protection circuit. In a delta/Star Power transformer, the cts will be connected star and delta formation, for eliminating Zero sequence current on star side. There will be mismatch of secondary current , to maintain equilibrium, interposing Cts will be connected to Delta formed CTs. 25

RELAYS

RES E/F +O/L Protection relay

Differential relay O/F protection +FFR Group A trip relay

Breaker failure relay O/C protection relays

CB trouble relay Group B trip relay

DR earth switch relay

26

Relay conti…. A outer view of Relay

Relay testing box

27

SHUNT REACTOR  Shunt Reactor is a thyristor controlled high impedance

transformer. A stable bus voltage can be maintained by providing variable reactive power based on the bus voltage deviations due to the load variations. 28

SHUNT CAPACITOR BANK Shunt capacitor banks are used to improve the quality of the electrical supply. provide capacitive reactive compensation. Power factor correction.

29

30

31
