Cara Konfigurasi Gpon-revisi 4f173d

[harlan@cacti-bdg ~]$ telnet 172.21.193.25 Trying 172.21.193.25... Connected to 172.21.193.25. Escape character is '^]'. ************************************************ Welcome to ZXAN product C300 of ZTE Corporation ************************************************ name:zte : GPON02-D3-PDL-2#sho gpon onu uncfg ( melihat gpon yang belum di config) OnuIndex Sn State --------------------------------------------------------------------gpon-onu_1/3/8:1 ZTEGC01C1FEE unknown gpon-onu_1/4/3:1 ZTEGC01C1DCD unknown gpon-onu_1/5/3:1 ZTEGC0389B40 unknown Berikut cara mengkonfig gpon di port gpon onu 1/5/3:1 ada ada 3 langkah. 1.configure di interface gpon 2.configure di pon managemen gpon 3.configure di ont langkah 1. configure di interface sbb: GPON02-D3-PDL-2#con t Enter configuration commands, one per line. End with CTRL/Z. GPON02-D3-PDL-2(config)#int gpo GPON02-D3-PDL-2(config)#int gpon-ol GPON02-D3-PDL-2(config)#int gpon-olt_1/5/3 GPON02-D3-PDL-2(config-if)#onu 1 type ZTEG-F821 sn ZTEG90006D09 (sampai langkah ini disebut ) .[Successful] GPON02-D3-PDL-2(config-if)#exit GPON02-D3-PDL-2(config)#int gp GPON02-D3-PDL-2(config)#int gpon-on GPON02-D3-PDL-2(config)#int gpon-onu_1/5/3:1 GPON02-D3-PDL-2(config-if)#name BTS_TSEL_MANSONPINE GPON02-D3-PDL-2(config-if)# description Kota Baru Parahyangan, Bandung, West Ba ndung, West Java 40553 GPON02-D3-PDL-2(config-if)# tcont 1 name node_B profile UP-100M GPON02-D3-PDL-2(config-if)#tcont 1 gap mode2 GPON02-D3-PDL-2(config-if)#gemport 1 name node_B unicast tcont 1 dir both queue 1 GPON02-D3-PDL-2(config-if)# gemport 1 traffic-limit downstream DOWN-100M GPON02-D3-PDL-2(config-if)# switchport mode hybrid vport 1 GPON02-D3-PDL-2(config-if)# switchport vlan 305,3362,3603 tag vport 1 GPON02-D3-PDL-2(config-if)#exit Langkah 2. Konfigure di Pon Managemen gpon GPON02-D3-PDL-2(config)#pon-onu-mng gpon-onu_1/5/3:1 GPON02-D3-PDL-2(gpon-onu-mng)#gemport 1 flow 1 GPON02-D3-PDL-2(gpon-onu-mng)# switch switch_0/1 stp disable GPON02-D3-PDL-2(gpon-onu-mng)# switch switch_0/1 local-switch disable GPON02-D3-PDL-2(gpon-onu-mng)# switchport-bind switch_0/1 iphost 1 GPON02-D3-PDL-2(gpon-onu-mng)# ip-host 1 ip 172.21.193.28 mask 255.255.255.192 gateway 172.21.193.65 GPON02-D3-PDL-2(gpon-onu-mng)# vlan-filter-mode iphost 1 tag-filter vid-filter

untag-filter discard GPON02-D3-PDL-2(gpon-onu-mng)# vlan-filter iphost 1 priority 7 vid 305 GPON02-D3-PDL-2(gpon-onu-mng)# vlan-filter iphost 1 priority 7 vid 3362 GPON02-D3-PDL-2(gpon-onu-mng)# vlan-filter iphost 1 priority 7 vid 3603 GPON02-D3-PDL-2(gpon-onu-mng)#end melihat hasil konfigurasi di interface : GPON02-D3-PDL-2#sho run int gpon-onu_1/5/3:1 Building configuration... ! interface gpon-onu_1/5/3:1 name BTS_TSEL_MANSONPINE description Kota Baru Parahyangan, Bandung, West Bandung, West Java 40553 tcont 1 name node_B profile UP-100M gemport 1 name node_B unicast tcont 1 dir both queue 1 gemport 1 traffic-limit downstream DOWN-100M switchport mode hybrid vport 1 switchport vlan 305,3362,3603 tag vport 1 ! end Melihat hasil konfigurasi di pon managemennya : GPON02-D3-PDL-2#sho onu run con gpon-onu_1/5/3:1 pon-onu-mng gpon-onu_1/5/3:1 gemport 1 flow 1 switch switch_0/1 stp disable switch switch_0/1 local-switch disable switchport-bind switch_0/1 iphost 1 ip-host 1 ip 172.21.193.28 mask 255.255.255.192 gateway 172.21.193.65 vlan-filter-mode iphost 1 tag-filter vid-filter untag-filter discard vlan-filter iphost 1 priority 7 vid 305 vlan-filter iphost 1 priority 7 vid 3362 vlan-filter iphost 1 priority 7 vid 3603 ! Melihhat hasil descripsinya : GPON02-D3-PDL-2#show gpon onu det gpon-onu_1/5/3:1 ONU interface: gpon-onu_1/5/3:1 Name: BTS_TSEL_MANSONPINE Type: ZTEG-F821 State: ready state: enable Phase state: OffLine Authentication mode: SN SN Bind: enable with SN check Serial number: ZTEG90006D09 mode: none : Device ID: Description: Kota Baru Parahyangan, Bandung, West Bandung, West Java 4 0553 Vport mode: gemport DBA Mode: Hybrid ONU Status: enable

OMCI BW Profile: enable Line Profile: N/A Service Profile: N/A Alarm Profile: N/A Performance Profile: N/A ONU Distance: N/A Online Duration: 0h 0m 0s FEC: none -----------------------------------------Auth Time OfflineTime 1 0000-00-00 00:00:00 0000-00-00 00:00:00 2 0000-00-00 00:00:00 0000-00-00 00:00:00 3 0000-00-00 00:00:00 0000-00-00 00:00:00 4 0000-00-00 00:00:00 0000-00-00 00:00:00 5 0000-00-00 00:00:00 0000-00-00 00:00:00 6 0000-00-00 00:00:00 0000-00-00 00:00:00 7 0000-00-00 00:00:00 0000-00-00 00:00:00 8 0000-00-00 00:00:00 0000-00-00 00:00:00 9 0000-00-00 00:00:00 0000-00-00 00:00:00 10 0000-00-00 00:00:00 0000-00-00 00:00:00 Langkah 3 Konfigurasi di ONTnya : langkahnya sbb 1. masuk ke ont dengan telnet ke ip ONTnya GPON02-D3-PDL-2#telnet 172.21.193.28 Trying 172.21.193.28 ...Open Attention: Telnet Escape character is ctrl+']' ************************************************ Welcome to ZXAN product of ZTE Corporation ************************************************ name:zte :zte MANSONPINE#sho run int fei_0/1/1 Building configuration... ! interface fei_0/1/1 negotiation auto flowcontrol disable no max-mac-learn switchport mode hybrid switchport default vlan 30 switchport vlan 1-29,31-4093 tag igmp max-group 255 igmp fast-leave enable igmp tag-stripe disable igmp mvlan-translate enable igmp cvlan 0 loopback-detection disable ! end MANSONPINE#sho int fei_0/1/1 fei_0/1/1 is up, line protocol is up

Cause

Description is none Keepalive set:10 sec The port negotiation is enable The port is electric Duplex full VLAN mode is hybrid, pvid 30 BW 100000 Kbits Last clearing of "show interface" counters never 120 seconds input rate : 257524 Bps, 120 seconds output rate: 482070 Bps, Interface peak rate : input 1402700 Bps, output Interface utilization: input 2%, output Input: Packets : 56214601555 Bytes : Unicasts : 56214530293 Multicasts: Broadcasts : 71140 Undersize : Oversize : 0 CRC-ERROR : Dropped : 0 Fragments : Jabber : 0 MacRxErr : ErrorCount : 0 ErrorRate : DroppedRate : 0% Output: Packets : 40957009419 Bytes : Unicasts : 40954038327 Multicasts: Broadcasts : 2971092 Collision : LateCollision: 391468 Dropped : DroppedRate : 0% Total: 64B : 34795267699 65-127B : 128-255B : 3830271299 256-511B : 512-1023B : 196593760 1024-2018B:

3135 pps 2156 pps 3863007 Bps 3% 4750722146352 122 0 0 0 0 0% 7565928235968 0 846456 0 16964041363 365956451 62470982

2. Masuk ke interface yang akan di Pakai (port 1 / fe_0/1/1) MANSONPINE#conf t Enter configuration commands, one per line. End with CTRL/Z. MANSONPINE(config)#int fei_0/1/1 MANSONPINE(config-if)#sho run int fei_0/1/1 Building configuration... ! interface fei_0/1/1 negotiation auto flowcontrol disable no max-mac-learn switchport mode hybrid switchport default vlan 30 switchport vlan 1-29,31-4093 tag igmp max-group 255 igmp fast-leave enable igmp tag-stripe disable igmp mvlan-translate enable igmp cvlan 0 loopback-detection disable ! end MANSONPINE(config-if)#exit MANSONPINE(config)#exit Lihat Hasilnya apa sudah ada mac-dress Yang kedetec

MANSONPINE#sho mac Total mac address : 31 Mac address Vlan id State Port Vc -------------------------------------------------------------------1833.9d3c.5d3f 3603 Dynamic gei_0/2/1 fcc8.97b8.05ce 305 Dynamic gei_0/2/1 d46a.a873.9246 3603 Dynamic fei_0/1/1 c8f9.f98c.4abf 3362 Dynamic gei_0/2/1 0017.cba5.ed1b 305 Dynamic gei_0/2/1 1833.9d3c.5d3f 3362 Dynamic gei_0/2/1 fcc8.97b8.0343 305 Dynamic gei_0/2/1 b415.13f8.04ac 3603 Dynamic gei_0/2/1 fcc8.97a1.acd0 305 Dynamic gei_0/2/1 fcc8.97a1.84af 305 Dynamic gei_0/2/1 fcc8.97a1.b712 305 Dynamic gei_0/2/1 fcc8.97a1.c259 305 Dynamic gei_0/2/1 0000.0c07.ac24 3603 Dynamic gei_0/2/1 b4b3.62ff.7300 305 Dynamic gei_0/2/1 fcc8.97b8.1564 305 Dynamic gei_0/2/1 d46a.a875.9887 3362 Dynamic gei_0/2/1 00d0.d09e.2f02 305 Dynamic gei_0/2/1 200b.c79f.88aa 3603 Dynamic gei_0/2/1 d46a.a877.8637 3603 Dynamic gei_0/2/1 0000.5e00.01bf 305 Dynamic gei_0/2/1 c8f9.f98c.4abf 3603 Dynamic gei_0/2/1 d46a.a875.9887 3603 Dynamic gei_0/2/1 fcc8.97ba.1b93 305 Dynamic gei_0/2/1 fcc8.97a1.aca3 305 Dynamic gei_0/2/1 d46a.a873.9246 3362 Dynamic fei_0/1/1 0000.0c07.ac24 3362 Dynamic gei_0/2/1 200b.c79f.88aa 3362 Dynamic gei_0/2/1 cccc.810e.1913 3603 Dynamic gei_0/2/1 d46a.a877.23d3 3362 Dynamic gei_0/2/1 0001.0c0d.0004 4094 Dynamic fei_0/4/2 00d0.d000.0001 4094 Dynamic gei_0/2/1 MANSONPINE#exit Connection closed GPON02-D3-PDL-2#
