Door And Window Details 354n3y

900

0.10



0.10

100

0.10

HEIGHT OF WINDOW CASING

DOOR OPENING

D3

W2

INTERIOR PORTION OF CHB WALL 0.10

2400

D2

W1

WINDOWS HT.

D1

DESCRIPTION

STEEL GATE

FINISH

1 A-0501

INTERIOR

EXTERIOR

FRONT FENCE, REAR FENCE AUTOMOTIVE PAINT FINISH

GATE SCHEDULE SCALE

1 : 30 M.

A-0501

SCALE

3

1 : 30 M.

A-0501

1 : 5 M.

INTERIOR

EXTERIOR

INTERIOR

RETRACTABLE DOOR SWIPE (AUTOMATIC)

INTERIOR

6 MM UNDERCUT

EXTERIOR FINISH FLOOR LINE

SILICON SEALANT

INTERIOR EXTERIOR

GLAZING WEDGE GLAZING ( WINDOW SCHEDULE)

DETAIL SCALE

6 1 : 5 M.

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH20 CONTINUOUS

SILICON SEALANT WITH BACKER ROD

MM. DRIPMOLD ALUMINUM FRAME MOHAIR

INTERIOR

INTERIOR

GLAZING WEDGE

BUBBLE SEAL GLAZING BREAD GLAZING WEDGE SILICON SEALANT

GLAZING ( WINDOW SCHEDULE)

GLAZING ( WINDOW SCHEDULE)

A-0501

DETAIL SCALE

1 : 5 M.

EXTERIOR

EXTERIOR

EXTERIOR

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH SILICON SEALANT

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED STAINLESSFINISH STEEL SCREW WITH NYLON PLUG SLIDER SASH

WITH BACKER ROD SILICON SEALANT GLAZING ( WINDOW SCHEDULE) GLAZING BREAD ALUMINUM FRAME

MOHAIR ALUMINUM FRAME SILICON SEALANT WITH BACKER ROD

INTERIOR

DISCLAIMER: Drawings and specifications and other contract documents duly signed, stamped or sealed, as instruments of service, are the intellectual property and documents of the Architect, whether the object for which they are made is executed o not. It shall be unlawful for any person to duplicate or to make copies of said documents for use in the repetition of and for other projects or buildings, whether executed partly or in whole, without the written consent of architector author of said documents. (R.A. 9266, Sec. 33)

PROJECT TITLE: HAUXWELL HOUSE EXTENSION LOCATION:

LOT 6 & 11 BLOCK 31 AMORE PHASE 1

INTERIOR

STAYS SILICON SEALANT GLAZING ( WINDOW SCHEDULE) GLAZING WEDGE GLAZING BREAD ALUMINUM FRAME

HANDLE

STAINLESS STEEL SCREW WITH NYLON PLUG

EXTERIOR CAST-IN-PLACE CONCRETE MOULDING IN PAINTED STAINLESSFINISH STEEL SCREW WITH NYLON PLUG BUBBLE SEAL

GLAZING ( WINDOW SCHEDULE) GLAZING WEDGE

GLAZING WEDGE

INTERIOR

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH20 CONTINUOUS MM. DRIPMOLD

DOOR SILL AT FLOOR (INTERIOR)

DOOR SILL AT FLOOR (EXTERIOR) A-0501

1 : 5 M.

EXTERIOR

GLAZING BREAD

5

SCALE

EXTERIOR

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH CONTINUOUS 20 MM. DRIPMOLD ALUMINUM FRAME

6 MM. UNDERCUT INTERIOR FINISH FLOOR LINE

A-0501

DETAIL

WALL FINISH ( SPECS.)

CAST-IN-PLACE LINTEL BEAM ( STRUCTURAL) STAINLESS STEEL SCREW WITH NYLON PLUG

DOOR ( MATERIAL AT DOOR SCHEDULE)

WOOD DOOR JAMB AND CHB WALL DETAIL

4

SCALE

KILN-DRIED SOLID WOOD DOOR JAMB IN WOOD STAIN FINISH CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH

DETAIL

WALL FINISH ( SPECS.)

DOOR ( MATERIAL AT DOOR SCHEDULE)

EXTERIOR

KILN-DRIED SOLID WOOD DOOR JAMB IN WOOD STAIN FINISH DOOR ( MATERIAL AT DOOR SCHEDULE)

WOOD DOOR JAMB HEADER AND CHB WALL DETAIL

SCHEDULE OF CASINGS

2

PORTION OF CONTINUOUS DOOR CASING IN WOOD STAIN AND VARNISH FINISH

DOOR JAMB

2

NO. OF SETS LOCATION

TYPICAL ELEVATION FOR DOOR CASING

G-01

DESIGNATION

DOOR ( MATERIAL AT DOOR SCHEDULE)

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH CONTINUOUS 20 MM. DRIPMOLD

TYPICAL ELEVATION FOR WINDOW CASING

100



HINGE ( SPECS.)

WALL FINISH ( SPECS.)

FINISH FLOOR LINE 100

PORTION OF CHB WALL

CAST-IN-PLACE LINTEL BEAM ( STRUCTURAL)

W3

WALL FINISH ( SPECS.)

INTERIOR

SILICON SEALANT WITH BACKER ROD WALL FINISH ( SPECS.)

OWNER:

GLAZING ( WINDOW SCHEDULE) GLAZING WEDGE SILICON SEALANT GLAZING BREAD ALUMINUM FRAME

INTERIOR

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH CONTINUOUS 20 MM. DRIPMOLD

EXTERIOR

ROLLER MOHAIR

INTERIOR

SILICON SEALANT WITH BACKER ROD

STAINLESS STEEL SCREW WITH NYLON PLUG

CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH CONTINUOUS 20 MM. DRIPMOLD

SILICON SEALANT WITH BACKER ROD

DOOR AND WINDOW DETAILS

EXTERIOR

BUBBLE SEAL

ALUMINUM FRAME SILICON SEALANT WITH BACKER ROD STAINLESS STEEL SCREW WITH NYLON PLUG CAST-IN-PLACE CONCRETE MOULDING IN PAINTED FINISH CONTINUOUS 20 MM. DRIPMOLD

ALUMINUM FRAME

SHEET CONTENTS:

MR. & MRS. STEVE HAUXWELL

GLAZING ( WINDOW SCHEDULE) GLAZING BREAD GLAZING WEDGE SILICON SEALANT

GLAZING ( WINDOW SCHEDULE) GLAZING WEDGE

CAD BY:

DLL

CHECKED BY:

DLL

DATE DRAWN:

02-18-13

DATE PRINTED:

03-20-13

SHEET NO.:

A-0501
