Technical data on the vehicle Make Model Year Engine Variant

Toyota Carina E 2.0 turbodiesel 1995-1998 2C-T Saloon

Date: 08-08-2011 Owner Registration No. VIN 1. Reg. Date Data

Technical item Engine Engine ID code

2C-T

Number of cylinders

R4

Number of valves

8, OHC

Capacity/ (bore/ stroke)

1975 cm³ (86,0/ 85,0)

Compression ratio

23,0: 1

Max. output kW (din hp)/ rpm

61 (83)/ 4000

Max. torque NM/ rpm

174/ 2000 - 3000

Engine code location

Engine block

Vehicle Identification Number location

Fire wall right side

Production year code in VIN

Model year in rims

Valve clearance, inlet (cold/ hot)

0.20 - 0.30 cold (Approx. 20° C)

i

Valve clearance, exhaust (cold/ hot)

0.25 - 0.35 cold (Approx. 20° C)

i

Valve angle/ seat angle

44,5°/ 45°

Compression pressure, bar

29,5 (Min. 24,5)

Oil pressure/ rpm, bar

5,0/ 3000 (Min. 2,5/ 3000)

Radiator cap, bar/ thermostat °C

0,75 - 1,05/ 80° - 85° C

Clutch freeplay, mm

5 - 15 at pedal

Repair time: Clutch renewal

4 hours and 25 minutes

Timing belt: Renewal interval

100,000 km (From 1/1 - 96)/ 7 years

Repair time: Timing belt renewal

2 hours and 24 minutes

Noise measurement, dB(A) at rpm

75/ 3000

i

i

i

Engine management Diagnostic connector

Left strut tower

Pump/ pump type

Nippon Denso/ Rotor

Injector/ injector type

ND/ pintle

Crank position °/ engine piston, mm

0°/ TDC

Pump position, mm

0.55 - 0.61 after BDC

i

Adjustment method

Dial micrometer/ Notch

i

Feed pump pressure, bar

2,7 - 3,3

Injector opening pressure, new, bar

150 - 160

Injector opening pressure, used, bar

135 - 155

Injection order

1 - 3 - 4 - 2 (Cylinder 1 at timing gear)

Injection timing mark location

Belt pulley

i

Electrical system Battery

12 V 60 Ah

Starter motor current (cranking), A

90 A

Voltage relay, Volt at/ amp.

13,9 - 15,1/

Terminal definitions DIN 72 552 Alternator max, A

80

Glow plug - power consumption

11

Glow plug voltage/ drop resistor

12 V/ 740 ohm

Wheel alignment Load

Unloaded

Front vehicle height

198 mm

Rear vehicle height

255 mm

Toe-in, °

0° 06' ± 12'

Camber°

÷ 0° 20' ± 45'

i

Data

Technical item Wheel alignment Camber, max. difference on R and L side

45'

Caster°

1° 00' ± 45'

Caster, max. difference on R and L side

45'

KPI/SAI°

13° 25' ± 45'

Rear camber°

÷ 0° 55' ± 45' (St. car ÷ 0° 20')

i

Rear toe-in °

0° 24' ± 12'

i

Tyre size

185/ 65 R 14 86 H

Tyre pressure, front/ rear, bar

2,2/ 2,2

Free play in suspension parts

Factory data

Wheel offset, mm

45'

Top speed

170 - 175

i

i

Tightening torques Tightening, NM

Torque standards

Cylinder head bolts, stage 1, Nm

44 Nm oiled

Cylinder head bolts, stage 2, Nm

+ 90°

Cylinder head bolts, stage 3, Nm

+ 90°

Cylinder head bolts, stage 4, Nm

(No retightening)

Repair time: Cylinder head gasket

5 hours and 35 minutes

Main bearings, Nm

103 oiled

Connection rod bearings, Nm

64 oiled

Flywheel, Nm

88

Crankshaft pulley/ vibration damp. Nm

196/

Camshaft pulley/ bearings, Nm

88/ 18

Pump pulley/ idle wheel, Nm

64/ 37

Timing belt tensioner, Nm

37

Nozzle retainer/ Nozzle in cylinder head

29/ 64

Glow plug

13

Wheel nuts/ bolts, Nm

103

Wheel hub, front/ rear, Nm

216/ 123

Repair time: Renew one rear wheel bearing

42 minutes

Repair time: Renew one front wheel bearing

1 hour and 55 minutes

i

Brakes Front, min. thickness (new)

26.0 mm (28.0 mm)

Rear, min. thickness (new)

201,0 mm (200,0 mm)

Repair time: Front brake disc renewal (2 pc.)

45 minutes

Repair time: Rear brake drum renewal (2 pc.)

1 hour and 15 minutes

Capacities Engine oil/ - incl. filter, litre

4,4/ 5,1 (APi. CD)

Manual transmission, litre

2,6 (APi. GL-3 Dexron II)

i

Automatic transmission, litre

3,3 (Dexron II)

i

Power steering, litre

0,8 (Dexron II)

Cooling system, litre

6,9 (50% LLC Ethylenglycol 90%)

Fuel tank, litre

60

A/C fluid, type/ gram

R134a/ 750 ± 50

A/C oil, type/ cm³

Dens Oil 8/

MOT Towing weights kg: w/ w.out brakes

1300/ 500

Environmental parametres Idle speed, rpm

750 - 850

Max rpm (exhaust test)

5100 - 5200

i

Technical item

Data

Remarks
