What’s New in Quartus Prime v15.1? Anisha Nanda

Agenda Quartus Prime Design Suite – Product Details Customer Beta Registration Process Stratix 10 Early Access software Arria 10 Timing Model Update MAX 10 Update Quartus Hierarchical Design Timing Closure & TimeQuest BluePrint SoC Embedded Features IP Cores

Highlights First release of Quartus Prime Software – Pro Edition – Public Beta in v15.1

Full speed grade performance improvement in both editions – Arria 10 Default Flow: 7% – Arria 10 High Effort Flow & Physical Synthesis: 13%

Public release of BluePrint Platform Designer – Available in Pro Edition only

New Synthesis Engine – Expanded language (VHDL 2008 and SystemVerilog)

Quartus Software Gets a Refresh

Web Edition

Lite Edition (LE)

Subscription Edition

Standard Edition (SE) Pro Edition (PE)

4

Do customers need to buy Pro Edition? In v15.1, Free of charge since Pro Edition is a public beta In v16.0, Pro Edition pricing will be effective (May 2016)

Software Products

List Price Quartus II Subscription

Quartus Prime Standard

Pro

New

$2,995

$2,995

$3,995

Renewal

$2,495

$2,495

$3,395

Fixed

Effective $4,995 with v16.0 $4,295 Release

New

$3,995

$3,995

Renewal

$2,495

$3,295

New

$945

$1,995

$1,995

Renewal

$945

$1,695

$1,695

Float

ModelSim

5

Quartus Prime Licensing & Availability What license do I need? – Lite: No license file required – Standard: Requires a Standard license (quartus feature line) – Pro: Requires a Pro & Standard license (quartus_pro & quartus feature line)

How do I obtain a Pro Edition license? – Employee license via MOLSON

How can I provide my customer a Pro Edition license? – 60-day Customer evaluation license via MOLSON – Zero dollar order More details coming soon

6

Which Edition Do I Need? (LE vs SE vs PE) Lite Edition

Standard Edition ($)

Pro Edition ($)

CV, CIV, M10, MV, MII

SV, SIV, A10, AV, AII, CV, CIV, M10, MV, MII

A10 (S10 coming soon)

New Hybrid Placer





New Global Router





New TimeQuest





New Physical Synthesis





FastForward Compile

EA

16.0

Feature

1. Targeted Device

2. Spectra-Q Productivity Features

7

Device

BluePrint



New Synthesis



Rapid Recompile

Only 28nm



SignalTap Postfit OpenCL (A10)



Only 28nm



Incremental Optimization

EA

Partial Reconfiguration

EA

Hierarchical Design Flow

2016

Distributed Compile

2016

Which Edition Do I Need? Pick the edition that s the device you are using – Lite Edition - CV, CIV, M10, MV, MII, AII* – Standard Edition - SV, SIV, A10, AV, AII, CV, CIV, M10, MV, MII – Pro Edition - A10 (S10 coming soon)

Use Standard Edition if you have: – an existing A10 design using Subscription Edition – an active A10 design going to production in the next 6 months

Use the Pro Edition if you have : – A new A10 design – A design that requires features only available in Pro Edition, for example Partial Reconfiguration, OpenCL, and BluePrint

Quartus Prime Software v15.1: Higher Design Performance  Faster Timing Closure

7% Higher Fmax Arria 10 v15.1 vs v15.0

Out of the Box

1 Speed Grade Faster with Quartus Prime Software v15.1 10

Quartus Prime Software v15.1: Higher Design Performance  Faster Timing Closure

7% Higher 13% HigherFmax Fmax vs v15.0 Arriav15.1 10 v15.1 vs v15.0

Out of the Box High Effort & Physical Synthesis

1 Speed Grade Faster with Quartus Prime Software v15.1 11

Quartus Prime v15.1 OS Plan Windows 7 SP1 (64bit)

Windows 7 SP1 (32bit)

Windows 8.1 (64bit)

Quartus Prime (All Editions) NIOS II EDS, DSP Builder

Stand-Alone Programmer ModelSim-Altera (requires 32-bit libraries)

Red Hat 5.10 (64bit) Standard and Lite Editions Only

NEW in 15.1 Windows 8.0 Only

SoC Embedded Design Suite Altera SDK for OpenCL JNEye

32 and 64 bit

Pro Edition is not ed on RedHat 5.10 NEW for a 32-bit stand-alone programmer in Windows 7 ModelSim-Altera officially s Windows 8.0 only For more information Michael Wenzler in ACDS Central 12

Red Hat 6.5 (64bit)

Windows Server 2008 R2 SP1 (64bit)

Quartus Prime Documentation Public Documents 15.1 – Quartus Prime Handbook (Standard Edition) GUI enhancements, PR changes, Qsys walkthrough, new reports, RTL viewer changes, Auto periphery/core optimization, BSYN, assignments

– Quartus Prime Handbook (Pro Edition) All applicable Standard content, plus: Intro, migration, Spectra-Q engine, new GUI, new flows, new assignments, new reports, new scripting, SignalTap postfit routing preservation

– Altera Software Installation and Licensing Reflect changes to website and licensing for Pro Edition

– Quartus Prime Help Updated to document all new GUI

Early Access Documents 15.1+ – Stratix 10 Fast Forward Compile Guide HyperRetiming, HyperPipelining, Fast Forward Compilation, RTL Guidelines, Design Examples, GUI reference, Glossary 13

Customer Beta Registration Anisha Nanda

Request Beta Software to myAltera with your myAltera name and Click on ‘Beta Software Request’

Your Customer Enter your customer’s email address – Must be the same as their myAltera email address

Click on the Email Click on the link in the email to the software

the Customer Beta Software to myAltera with your myAltera name and Click on Beta Software

the Customer Beta Software Accept the ‘ & Conditions’ – Only need to do it once for each Quartus version

the required edition and device files of the Quartus Prime software You’re Done!

Stratix 10 Early Access Software Joe DeLaere

What’s Available for Stratix 10 Early Access in 15.1 Quartus Prime Standard 15.1 s Fast Forward Compile – Stratix 10 FMAX Performance exploration tool using HyperFlex Hyper-Retiming Hyper-Pipelining Hyper-Optimization

15.1 improvements over 15.0 – New Hyper-Optimization Advisor with step-by-step instructions and optimization help – New performance increases through chain & DSP, RAM block placement – New GUI and tooltips for ease of use

Not a full release for Stratix 10 – No IP (e.g. EMIF, transceiver) – No Device selection, utilization, or pin assignments 21

15.1 Stratix 10 Early Access Software Flow

Design Entry (RTL)

Standard Arria 10 Compile

Fast Forward Compile

Report Predicted Stratix 10 Fmax Report how to increase performance further

Same flow as 15.0 Fast Forward Compile 22

Stratix 10 Hyper-Optimization Advisor

Advisor walks through Stratix 10 Fast Forward Compile tools Connects s to training & documentation Teach s how to Hyper-Optimize their own designs

23

Fast Forward Compile Access requires additional free license on top of valid Quartus Prime Standard license – Request via [email protected] for your customers – Please ensure they have a valid subscription or evaluation license first

Documentation – New Fast Forward Compile Guide Integrates AN 714,715,716 and RTL design guide/cookbook

– New Fast Forward Compile Help Documentation – Walk through video and training on altera.com

Future releases of Fast Forward Compile post-15.1 will be built on Quartus Prime Pro Edition 24

Arria 10 Timing Model Updates Rama Venkata

Timing Model Usage Timing Model Maturity

Description

Usage

Pre-Layout

Initial estimate of timing performance, utilization and pipelining needs

Preliminary

Post-Layout

Initial timing closure Beta board prototypes (see next slide for derivative devices)

Preliminary+

Silicon correlated Pending volume silicon testing

Final

All testing complete

Advance

Begin final timing closure Complete final board design Ready for production

+

26

Arria 10 Timing Model v15.1 Update  Derivative devices (480, 320/270, 220/160) reuse architectural elements from

primary devices (1150/ 900 & and 660/ 570)  Timing models of derivative devices inherit two key benefits from reuse of architectural elements that are silicon correlated in primary devices 1) Derivative devices are technically labelled as P, but are much closer to F.

Because, results from silicon correlation of primary devices are built into derivative devices timing models. 2) Skip P+ & directly move from Preliminary to Final. Or, benefit from much shorter P+ phase. All devices transitioned to Preliminary in 15.1

Derivative Devices

Device LE Count 1150/ 900 660/ 570 480 320/ 270 220/ 160

15.0 P P A A A

15.1 P+ P+ P P P

16.0 F P+ P+ P P

16.1 F F F F F

Note: Military grade devices are “P” status in v15,1 & v16.0, and go directly to “F” in v16.1. 27

MAX 10 Update Rich Howell

28

What’s new for MAX 10 in 15.1? General: –

OPN updates: C8 temp / speed grade OPNs added for device consistency F variants removed

–

Final Timing Models: v15.1: 10M04, 10M08 v15.1 U1: 10M40 and 10M50

–

Final Power Model (PPPA and EPE) v15.1: 10M02, 10M04, 10M08, 10M16, 10M40, and 10M50 v15.1 U1: 10M25

SEU: Heart-beat indicator for EDCRC IP : Advanced DDR3 feature –

ECC (DDR3/2), Advanced Bank Management, Data Reordering, Self Refresh, Auto Power Down, Dynamic Input Buffer disable

Embedded IP and Software driver – – – – 29

NIOS: Flash accelerator for operating from UFM (was beta in v15.0) 16550 UART Max 10 I2C Master/Slave peripheral QSPI x1 in Max 10 (Linux drivers)

Quartus Hierarchical Design Rama Venkata

30

Quartus Prime with Spectra-Q

1. New design database infrastructure – Foundation laid for new hierarchical flows in v16.0 and beyond – New database + hierarchical infrastructure – Fundamental infrastructure for Quartus Pro

2. Significant back-end tools and algorithms 3. Unified high level design compiler

31

NEW

LogicLock Plus Regions (in Pro Edition only) LogicLock Plus improves traditional LogicLock – Includes new Routing Region constraints in 16.0 – Hierarchical flow use models in 2016

LogicLock Plus

LogicLock

Quartus Prime Edition

Quartus Pro Edition only

Standard only

Assign Partitions to Regions Export & Import partition into a Region

No (Yes - using Spectra-Q -in 16.0/ 16.1)

Yes (using Quartus Incremental Compile)

Constrain Placement to a Region

Yes

Yes

No (Yes in 16.0)

No

Yes

Yes

Constrain Routing to a Region Edit, Delete, Modify Region 32

Arria10 Rapid Recompile Quartus Prime now s Rapid Recompile for Arria 10 – Only in Pro Edition

Up to 75% reduction in compile time with Rapid Recompile

Speedup (Rapid Recompile versus Full Compile)

Flow

HDL Change SignalTap: Changing PostFit tap points

33

Synthesis

Fit

Total

2.2x

2.7x

~2x

Not Applicable

3.6x

~3.6x

Targeted hold time optimization Early access in v15.1 Pro Edition. No INI variable needed, but does not include: – Complete GUI , – Documentation

Targeted hold time optimization for Post-Route Hold Fixup – Run after ‘Implement’, or after ‘Finalize’ – Previously: Apply over-constraints and recompile

Map/Syn

Floorplan

Place

“quartus_sh --implement”

34

Route

Post Route (Hold Fix)

Finalize

“quartus_fit --post-route=hold_fixup”

Beta Feature in Pro Edition: Post Implement Hold Fix-Up 0

-5

Hold TNS (ns)

-10

-15

-20

Hold Total Negative Slack (TNS) measured across 50+ designs over broad end-application segments -25

-30

Algorithm capable of fixing a lot of violations -35 Series1 Before 35

Fixup

Series2 After

Fixup

Beta in v15.1 Pro Edition.

Check Pointing  Check pointing in Quartus Pro 1) Saves compile time by ~20% with “Inner loop” compilation flow a) First, iterate with 3-corner STA b) Next, run finalize for HS/LP optimization and 4-corner STA/ASM 2) Faster timing closure with intermediate Post-plan & Post-place timing analysis  Planned  estimated clock delays (no data delays)  Placed  uses placer’s estimated data delays

TimeQuest menu: “Netlist”  ”Create Timing Netlist” Command line: quartus_sta --snapshot=[planned|placed]

36

More Check Pointing Features in Pro Edition

Per-stage reports available – Stages: Map, Plan, Place, Route, Finalize

‘Plan’ data available before P&R

37

Timing Closure & TimeQuest Rama Venkata

Periphery-Core Optimization – Standard and Pro Editions Early place & route for paths between periphery & core – Previous releases required detailed wire or delay window constraints – Determines delay window automatically – Prioritizes, and commits routing for these paths over others – Optimizations summarized in Fitter Report QSF:PERIPHERY_TO_CORE_PLACEMENT_AND_ROUTING_OPTIMIZATION Can be applied globally (Advanced Fitter setting) or to particular entities Auto: Will pre-place & route P2C/C2P paths with tight windows On: Optimizes all identified paths, Off: Prevents any optimization

39

Multi-corner Visualization (Q15.1) Easy switch between timing corners Generate reports across all corners –

Not just in GUI, in scripts too

Summary reports available –

40

One list of worst-case paths from all corners

Hierarchical Reports Visualization tool (Q15.1)

Click to run report_timing to see details of paths The worst-case slack and the number of paths from/to that point of the hierarchy Click +/- to drill down the hierarchies 41

Click a link to rerun the report to/from that hierarchy

Clock-Domain-Crossings Verification Quickly paths that are deemed asynchronous transfers/clocks Validate paths affected by set_clock_groups SDC command. Run “report_exceptions -report_clock_groups” – Adds a section of the report for each set_clock_groups – Summary and detailed-paths-list views are available

42

BluePrint Rama Venkata

What’s New in BluePrint in Quartus Prime v15.1? Accessing BluePrint – Quartus Pro BluePrint publicly visible from the Quartus Tools menu No license or INI required to run BluePrint

– Quartus Standard INI hidden version of BluePrint available for use in Quartus Standard INI will be provided only to existing A10 customers unable to migrate BluePrint will not be available in Quartus Standard after 15.1

Major interface improvements

44

15.1 BluePrint Features - Package View Improvements Package view updated based on /field – Styled to look like PinPlanner, pin special functions added as tool tips, option to enable bank colors, flip between package top/bottom

45

15.1 BluePrint Features - Reports Improvements Improve experience using BluePrint reports – Updates to BluePrint backend and GUI report widget (RPWQ) – Several new reports have been added to BluePrint including Clocks Report – Reports are hyperlinked to allow integrated selection with floorplans

46

Blueprint flow now directly accessible from the home screen – Flow steps are buttons, and design/progress info updated dynamically during planning

More integrated selection – Selection of design element in design tree will Select associated location graphical views Show information in info property view—for both design element and location

– Selection of location in graphical view will Select associated design element in design tree Show information in info property view—for both design element and location

Double-click “Placement” column to “zoom-to” Selection history – Available via forward / back buttons on info property view

Mouse rollover – Rollover in design tree highlights locations, associated design elements (and descendants) in graphical views – Rollover in info properties view highlights locations, associated design elements (and descendants) in graphical views

47

SoC Embedded Software

SoC EDS SoC EDS 15.1 has incremental improvements and bug fixes. Improved productivity with A10 SoC FPGAS – – – –

s A10 SoC FPGA Quartus Prime workflows HW Libs available Baremetal example for A10 SoC FPGAs Golden Hardware Reference Design for Quartus Prime

Improvements to DS-5 AE: – Install multiple DS-5 AE on same host

Other updates – Cygwin Embedded Command Shell upgraded to version 2.0.1 – Angstrom RootFS upgraded to v2014.12 – ARM baremetal gcc toolchain upgraded to gcc version 4.9.2

49

Hardware Libraries HWLIBs

QSPI modified to enable alternate QSPI Flash devices for all SoC devices

Full Arria 10 SoC HWLIB in 15.1 SoCEDS

– New: FPGA Mgr, ECC Mgr, Clock Mgr, Reset Mgr – All fully tested on Arria 10 SoC – Customer beta available September 21

UEFI Bootloader now provided for non-GPL option instead of Minimal Preloader (MPL) due to larger OCRAM – Also makes use of Arria 10 SoC HWLIBs 50

Linux and U-Boot Latest stable kernel v 4.2

LTSI (Long Term ) kernel v3.10 until the end of the year. LTSI v 4.1 starting Q1 2016 U-Boot v2014.10 Yocto Project v1.7 /Angstrom Distribution 2014.12 until the end of the year

Yocto Project v1.9 /Angstrom 2015.12 starting Q1 2016

51

SoC Software Virtual Platform Schedule At-a-Glance 2015 Jun

Jul

Aug

Sept

2016 Oct

Nov

Dec

Jan

Feb

Mar

Apr

May

S-10 SoC VP w/Linux Additional Production Releases every 2 Months

S-10 SoC VP w/ Linux Initial Production Release

S-10 SoC VP w/ Linux Beta Release (Limited features)

A-10 SoC VP w/ Linux Production Release (Dual Core, USB, I2C, QSPI Linux Host)

A-10 SoC VP w/ Linux Beta Release (Limited features)

52

New IP Features Juwayriyah Hussain

Agenda General IP productivity improvements – Completed/validated out of the box IP evaluation New Example Design GUI Dynamically generated out-of-the-box evaluation

– IP infrastructure updates New synthesis engine New IP upgrade status bar in Project Navigator

– EMIF Debug Toolkit features upgrade

Individual IP Updates – EMIF, PCIe, Ethernet, etc.

54

Example Design Productivity Improvements Dynamically generated and configurable hardware example designs embedded in IP Parameter Editor GUI – Available for EMIF, 40G-100G Ethernet, PCIe, 10G Ethernet, and JESD204B

Can be targeted to predefined devKits Altera Debug Master Endpoint (E) GUI Update

55

IP Infrastructure Improvements Quartus Prime Pro uses new synthesis engine Spectra-Q – This new engine uses industry standard Verilog configurations – A new library scheme for standalone IP has been introduced to avoid ambiguous entity definitions

IP licenses are forward and backward compatible – Pro license will mirror standard version license

IP Upgrade will block the compilation of IP generated using Quartus II or Quartus Prime Standard – s will be able to automatically regenerate their IP

56

IP Integration Improvements IP upgrade notification – added visual indication in Project Navigator to notify s of required and recommended upgrades – Required IP upgrades: Red – Recommended: Yellow

57

Individual IP Upgrades EMIF – PHYLite

Hybrid Memory Cube Controller (HMCC) PCI Express Interlaken SerialLite III Ethernet JESD204B New DSP FEC Cores VIDEO IP

58

EMIF Debug Toolkit Enhancements 

Improved Debug and Diagnostics 

2D Eye Diagram for EMIF Debug Toolkit  DDR4 and QDRIV



59



Improved API for On-Chip Debug Toolkit



Automated memory ODT sweep



Driver-margining

Configurable Traffic Generator 2.0 – New GUI options 

Flexibility to enable broader traffic patterns



Dynamic configuration to adjust patterns without regeneration or recompilation



Configuration via EMIF Debug Toolkit (GUI or Tcl interface)

EMIF Upgrades New features and protocols – Hardware verified DDR x4 LRDIMM – Added backside DB buffer calibration QDR II & QDR+Xtreme QDRIV – Pushed performance from 800 MHz to 1066 MHz

Abstract PHY – new GUI option – Targets 3-5x improvement in simulation time (w/ existing driver traffic) – Maintain latency & efficiency of existing skip cal simulation External bus will not have visible activity

– Note: Only subsequent simulations will see speedup First simulation runs skip cal sim to cache calibration settings (and ends after calibration) Subsequent simulations will read calibration cache and invoke faster Abstract PHY sim

Non-destructive Calibration – require INI – Adds refreshes during calibration to maintain DRAM contents – Not currently ed for HPS EMIF

60

Hybrid Memory Cube Controller (HMCC) Upgrades XCVR E and new out-of-the-box hardware example designs Arria 10 timing closure – 12.5G @ E1 with 10% margin (with seed sweep) – 10G @ E2 with 15% margin (with seed sweep)

MTAPS (Multi Transaction All Packet Size) – Up to 4 port access to HMC IP interface – Enables full bandwidth utilization – Full width core only 1 link (16 Lanes)

61

Dynamic Reconfiguration of PHYLite Timing analysis of dynamic reconfiguration of PHYLite – selects algorithm type and TimeQuest analyzes accordingly – Hybrid timing analysis approach of SV and A10 EMIF – Easy for us to document, and for customer to understand and use Explanation of Algorithm types

Custom Slack Recoverable 62

Dropdown box to choose

PHYLite Debug Kit Example Design APIs for customers to tweak PHYLite dynamic configurations – Provide customers a design that works on HW – NIOS-II connected to PHYLite design NIOS controls the reconfiguration knobs Easier for customers to debug and control PHYLite reconfigurability feature

– Include C functions or APIs to modify PHYLite configurations C code running on the NIOS-II

– Main program that tests modifying the delay chains

63

LVDS Dynamic Phase Shift (DPS) Example Design Allows customers live control over the PLL clock shifts in an LVDS design through a flexible TCL script interface Applications – RX Non-DPA capture debugging Repeatedly shift the capture clock until best operational phase is found

– C2P/P2C timing debug Try different core clock phase shifts to debug suspected timing failure

Example TCL script is provided – Applies a phase shift to a demo clock every 5 seconds – Demo clock can be scoped to see that the script is functional – Code Sample:

64

PCI Express – Performance & Productivity Unleashed New PCI Express IP features for Arria 10 – Data Mover (aka DMA) enhancements Now 8-bit tag field available: up to 256 tags available – Higher # of tags yields higher throughput

Added RX buffer completion monitor capability

– Rootport use extended to 256-bit AVMM interface (preliminary) – PCIe Link Inspector tool available to simplify debug (preliminary) – SR-IOV PF / VF bumped up to 4 PF / 4K VF Early access: enabled via hidden parameter – file Service Request (SR).

Hardware example design (push-button generation!) – Numerous configurations covered ( interface, generation, lane width) – Hardware platform: Arria 10 FPGA Development Kit

New easy-to-use PCI Express GUI

65

PCI Express IP GUI Snapshot s for simplified flow & navigation

Easy configuration 66

Interlaken / Interlaken Look-Aside – Expanded Simplicity Interlaken MegaCores (50G and 100G) – Altera Debug Master Endpoint (E) added to Interlaken Arria 10 devices: access to Native PHY, XCVR and other PLLs now has additional access points to perform test and debug

– Hardware example design (push-button generation!) All 4 configurations covered – 8 x 6.25 Gbps, 24 x 6.25 Gbps, 12 x 10.3125 Gbps, 12 x 12.5 Gbps

Hardware platform: Arria 10 Transceiver Signal Integrity Development Kit

Customizations continue to roll in for Arria 10 – Interlaken / Interlaken Look-Aside customizations for Arria 10 available through Non-Device PEP process – Simply file a Non-Device PEP Submission Form Located on Molson – https://go.altera.com/extranet2001/products/ip/ipep/ipep-index.html

67

SerialLite III Streaming Two separate cores now available in the IP Catalog – One s Stratix V / Arria V GZ, other s Arria 10

Throughput optimization by reducing to one cycle between bursts – Helps improve throughput & reduces overhead

Reset scheme changed to synchronous – Enhanced implementations improve the elimination of potential indeterminate behaviors – Entering and exiting of reset is synchronous – Transparent to existing and new customers

Demonstration designs on Altera Molson – Link to Arria 10 (ES2) SerialLite III Streaming configurations 24 x 12.5 Gbps (Arria 10 FPGA Development Kit) 12 x 12.5 Gbps (Arria 10 Transceiver Signal Integrity Development Kit)

68

Ethernet 1 / 2.5 / 10G MAC + PHY – New IP demonstrated 46% area improvement and 54% latency improvement over legacy 2.5G IP. – 2.5G Ethernet offers 2.5x bandwidth performance over 1G with dynamic reconfiguration. No changes to physical system i.e. wires, devices, etc.

Unified 1588 features for 10/40/100 G MAC IP Timing closure – 10% margin on A10 mid speed production

Low Latency 10G and 40G/100G new out-of-the-box hardware example designs

69

JESD204B up to 13.5 Gbps for Arria 10 Arria V SoC new out-of-the box example design – ARM based control plane

Dynamically generated example design – Includes NIOS-based control plan design

70

New Altera FEC IP Cores - Overview New HSRS (High-Speed Reed-Solomon) – 10Gb/s – 400Gb/s – High-throughput and compact, for example 100Gb/s @ <9K ALM

New LDPC (Low Density Parity Check) – – – –

DVB-S2 encoder WiMedia 1.5 encoder/decoder DOCSIS 3.1 decoder GSFC-STD-9100 decoder

New BCH (Bose, Chaudhuri and Hocquenghem) – NAND Flash – Up to ~25 Gb/s throughput

New TURBO – s UMTS & LTE

71

Forward Error Correction Applications

RSII+Viterbi Viterbi

Turbo

10-6

10-9

Wifi, WiMAX 802.11n/ac

DVB-S

(target)

802.16e 10-400G Ethernet

DVB-S2 10-12

NAND Flash

100Mb/s

RSII

72

HSRS

UMTS LTE

BER

LDPC, Turbo

LDPC+BCH

1Gb/s

BCH LDPC+BCH

10Gb/s

100Gb/s

Throughput

1Tb/s

Video IP Interfaces SDI – RX_format for 6G/12G-SDI redefined to have each stream reports its own detected rx_format. For example, when receiving 2160p60 in 12G-SDI, all 4 streams are expected to report 1080p60

– Improved jitter tolerance when receiving SD-SDI – New out-of-the-box hardware example design for multi-rate

DisplayPort – Resolution up to 4Kp60 – MST. 1, 2, 3 and 4 streams on Stratix V and Arria 10. MST 2 streams on Arria V

HDMI – Resolution up to 4Kp60 – Both progressive and interlace – HDMI mode and DVI mode

73

Video and Image Processing Suite End of life IPs (reminder) – Clipper IP (replaced by Clipper II) – Test Pattern Generator IP (replaced by Test Pattern Generator II)

Pushed out 3-release plan 4K/UHD IP updates Quartus Prime – Standard version ed – Pro version is not ed (POR for 16.0)

Device

Altera video and image processing suite 4K/UHD to be demonstrated at IBC 2015 (Stand 2.A50)

– Arria 10 continues on limited IP subset only See guide for details

74

Additional Resources

Looking for More Information? What’s New in 15.1 Training – coming soon on MOLSON Migrating to Quartus Prime Software - Pro Edition Training Spectra-Q Training (ASU) BluePrint Training (ASU) Customer: BluePrint online training (Link) Please visit the Spectra-Q page on MOLSON for more information on: – – – –

Spectra-Q Partial Reconfiguration BluePrint Spectra-Q Synthesis

Thank You
