Easergy PS100 Backup Power supply for Electrical substations Overview 01/2012

Content > Why PS 100 ? > Examples of architectures > PS 100 Main features and benefits > HMI & lay out > Communication and Monitoring > References & Logistic > Documentation > Conclusions

Schneider Electric - Easergy –PS100 presentation – Feb 2012 v4

2

Why PS 100 ? ● The “PS 100” unit supplies back-up operating power for : • MV switchgear electrical mechanism ( motors and coils ) • Transmission equipment ( e.g radio ) • Protection relays , Fault age indicators or others IEDs • And all others devices in MV/LV substations (LV breakers, PLC concentrator..) ● The “PS 100” has been designed for supplying power in distributed architectures ( SC110A, Flair 23VD, VIP410, Sepam…) to fit in LV cubicles of SM6, Premset * … * New MV switchgear range (ex- Matrix project)

● The “PS 100” will offer a new elegant solution in application in current MV/LV substations without RTU ( Remote Terminal Unit) - is integrated in Advan6 wave 3 - in repetitive MV/LV substation with SM6, MH 24+, FBX & RM6 (3 or 4 functions)

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

3

e.g : RM6 or M24,SM6 in MV/LV SS protection transformer power PS100

VIP410 or Sepam 10

Functions : Transformer Protection, DGPT2, DMCR or thermal protection activating coil tripping of Fuse switch combination or Circuit breaker

or

IM Switch units wo electrical mechanism Schneider Electric - Easergy – 01/2013 /PS100 Introduction

Circuit breaker unit with autonomous protection or Sepam

Fuse switch Combination unit 4

e.g : SM6 in CIB SS ( in commercial and industrial building)

protection transformer power PS100

VIP410 or Sepam 10

Functions : Transformer Protection, DGPT2, DMCR or thermal protection activating coil tripping of Fuse switch combination or Circuit breaker

or

IM Switch units wo electrical mechanism Schneider Electric - Easergy – 01/2013 /PS100 Introduction

Circuit breaker unit with autonomous protection or Sepam

Fuse switch Combination unit 5

e.g : RM6 or M24+ or SM6 in MV/LV SS Monitoring & protection transformer L500 Third Party

R200 220Vac

IEC 101 IEC 104 DNP3 over radio, GSM, GPRS,…

Functions : Coil / Transformer Protection by Fuse switch combination or Circuit breaker Feeder automation - FPI LV monitoring Load management Alarms management

PS100

RS 485 48Vcc

12V

IM Switch units (wo Electrical mechanism)

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

Fuse switch Combination or circuit breaker unit 6

e.g : Premset or FBX+ RMU in Utilities Full feeder automation in distributed architecture

DMS MDM

Functions : Transformer Protection Feeder automation - FPI - Switchgear control by Switch controller SC110A or SC105 - Sectionalizer - LV monitoring Load management Alarms management

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

R200

PS100

F23D

SC110A

PM800 VIP

IEC 101 IEC 104 DNP3 over radio, GSM, GPRS, …

PLC connection

Smart meters

7

PS 100 Main features High-availability back-up power supply for medium voltage substations

Uninterrupted power supply 24 or 48 V dc LV main power supply 100-250 V ac or 110 V dc

90W + 300W 1mn Uninterrupted power supply 12 Vdc

25 W PS100

Charging or supplying

Communication devices • RTU • Modem • Radio

Power supply Information Schneider Electric - Easergy – 01/2013 /PS100 Introduction

12 Vdc battery

8

PS 100 Main features IP 20 / IK 7 Dimensions : 125 x 165 x 160 mm & 2,6 kg

Installation on Din rail mounting

Battery size : 38 AH 170 x 165 x 197 mm

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

9

PS 100 : HMI & lay out 250 Vac main power supply terminals

Battery & Sector state outputs 2 rotary switches for Modbus address configuration Display

AC power supply OFF Battery fault

Reset button

Status of the unit 24 or 48V ON 12V ON

2 RJ45 connectors for Data transmission

Communication life indicator

12 -24 or 48 V Vcc outputs Schneider Electric - Easergy – 01/2013 /PS100 Introduction

10

Autonomy ● Autonomy up to 24 hours ● Depend on ● Mainly the permanent Load (PL) ● the “Energy backup” (Pb) ● The type of battery (38Ah, 24Ah) ● Temperature ● Battery age

● The non permanent load is estimated to 16 Open&Close cycles of Switchgear. (Ps) I.e : 4 operating Sepam10 (4x8=32 W) allows 12 hours of autonomy

● PS100 Autonomy

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

11

PS100 supply capacity ● 3 examples of maximum number of devices for 1 PS100:

CB with protection relay and motorization

Switch with Fault detector and motorization

● 1 PS100 supplies up to 2 protection relays or 16 switches

ATS with 2 SW or 2CB

2

4

0

1

15

0

0

8

1

● With 3 or 4 protection relays, it is recommended to use 2 PS100 with redundancy ● With an Automatic Transfer Switch device, it is recommended to use a second PS100 for protection relays. ● For more than 4 Protection relays , PS100 isn’t usable

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

12

Benefits Optimized battery backup

● Only one battery to simplify the replacement ● The PS100 needs only one battery, simplifying replacement vs traditional backup power supplies require a set of 2 or 4 batteries to produce 12V or 48V, with complicated replacement and adjustment of the battery pack. ● Battery can be purchased easily, anywhere in the world : sealed lead 12V battery ,10 years life

● To prevent power network cuts ● Enables output voltage backup in case of cuts up to 24 hours

● PS100 protects and optimizes the battery duration ● Ensures its charge with a regulated and temperature-compensated charger ● Checks the battery and prevents the battery deep discharge level ● Measures battery ageing and alarms before battery end of life Schneider Electric - Easergy – 01/2013 /PS100 Introduction

13

Benefits High availability ● PS100 is robust to the harsh environment of electrical substation ● Reliability is a key point for Electrical substations : Insulation: 10 kV, - 40°C to +70°C operating temperature... ● Electronic protection against over voltage, overloads and short circuit ● Automatic restart after fault

● Additional “Energy back up” to restart the installation after a prolonged network cut ● an optional Energy back up can be enabled with a local push button to provide energy for restarting the protection relays and electrical control of MV switchgears at installation restarting. ● Forecast backup reservation : 300 W - 1mm ●

Modbus communication port forwards monitoring data to allow optimized maintenance operations.

● A limitation, dedicated for radio units, is set up to avoid the battery deep discharge

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

14

Benefits Redundancy to increase availability and power

Power supply paralleling

- more availability

- or additional power Schneider Electric - Easergy – 01/2013 /PS100 Introduction

15

Communication and monitoring Protocol

Modbus

RS 485- configuration of Modbus address by means of 2 rotary switches

Connector

RJ45

2

Data transmission

Measuring & status Data with date and time

 AC supply presence  Battery state ( disconnected, failure, available capacity, optional back-up reservation)  PS100 Global Status (Ready /internal Fault)  12V & 48V or 24V output failure  Threshold Serious discharge, threshold Energy back-up  Charge indicator, diagnosis information  Reset

Settings

 AC voltage loss threshold , DC serious battery discharge threshold  Battery Test frequency  Energy Back-up enable / disable

Command

 Restart 12/48 V ( Energy Back-up)  Run led test  Run battery test

Time stamped events

 100 events ( clock resolution 1ms )

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

16

References DESIGNATION

REFERENCE

FEATURE

PS100-24V

EMS58580

Back-up Power supply - 12V, 24V output

PS100-48V

EMS58581

Back-up Power supply - 12V, 48V output

Bat 24AH

EMS58582

Long life battery - 12V - 24A.h

Bat38AH

EMS58583

Long life battery - 12V - 38A.h

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

17

e.g : integration PS 100 in IP 31 cabinet

Schneider Electric - Easergy – 01/2013 /PS100 Introduction

18

Documentation guide – Manuel d’utilisation Leaflet – Notice technique Sales - Memo vente
